🏷️ Basic Information

Make:

Ford

Model:

Escape

Year:

2005

Platform Code:

CD2 (Mazda GF platform based)

Vin Code Digit 1:

1

Vin Code Digit 4:

V

👋 Introduction

Vehicle Segment:

Compact SUV / Crossover

Key Competitors 2005:

Honda CR-V, Toyota RAV4, Mazda Tribute, Nissan Xterra, Chevrolet Equinox

Vehicle Appeal:

Affordable pricing, available AWD, comfortable ride, practical interior space, V6 engine option.

Target Audience:

Professional automotive technicians, experienced DIY enthusiasts, and owners seeking comprehensive repair and maintenance knowledge.

Benefits:

Empowers users with the same information used by dealership service departments, enabling accurate diagnosis and repair, reducing reliance on costly external services.

📋 Manual Details

Major Systems:

Engine, Transmission, Drivetrain, Suspension, Steering, Brakes, Electrical, HVAC, Body, Emissions, Diagnostics, Maintenance

Estimated Pages:

1500+

Type:

Full Service and Repair Manual

Language:

English

Format:

PDF (Portable Document Format)

📖 Manual Coverage

Engine Mechanical:

2.3L Duratec I4, 3.0L Vulcan V6 (including teardown, assembly, overhaul, torque specifications, cylinder head, pistons, crankshaft, camshafts, timing components)

Engine Management:

Fuel injection, ignition system, emissions control systems (EGR, PCV, evaporative emissions), engine control module (ECM) operation and diagnostics

Transmission:

4-speed automatic transmission (AX4N/4F50N), manual transmission (M5R1) - including overhaul, fluid specifications, diagnosis, and shift control

Drivetrain:

All-wheel drive (AWD) system, front-wheel drive (FWD), transfer case operation, rear differential, driveshafts, CV joints

Suspension Steering:

Front independent suspension (MacPherson strut), rear independent suspension, power steering system, steering rack, wheel alignment specifications

Brakes:

Front disc brakes, rear drum brakes (standard on some models), ABS system operation, hydraulic lines, parking brake, brake rotor and pad replacement

Electrical System:

12V battery, charging system (alternator), starting system, lighting system, power windows, power locks, wipers, horn, fuses, relays, and detailed wiring diagrams

Body Chassis:

Body panel removal and installation, doors, hood, tailgate, interior trim, bumpers, glass, frame structure

HVAC:

Air conditioning system operation, refrigerant handling, blower motor, heater core, A/C compressor, climate control modules

Routine Maintenance:

Oil changes, filter replacements, spark plug replacement, fluid level checks and top-offs, tire rotation, brake inspections

Troubleshooting:

System-specific diagnostic flowcharts, common fault code interpretation (OBD-II), symptom-based troubleshooting guides

Repair Rebuild:

Component-level repair and replacement procedures, from minor adjustments to major overhauls (e.g., engine rebuild, transmission overhaul, brake caliper replacement)

Diagnostics:

On-Board Diagnostics (OBD-II) system, diagnostic trouble codes (DTCs), scan tool usage, sensor testing, actuator testing

Wiring Diagrams:

Comprehensive electrical schematics for all major systems, including component location and wire color codes

Depth:

Expert-level detail suitable for professional technicians, with clear, step-by-step instructions for DIY mechanics. Covers diagnostics, repair, and overhaul procedures.

📊 Manual Specifications

File Type:

PDF

Compatibility:

All versions of Windows and Mac OS

Printability:

Full printable pages

Binding:

Digital (Instant Download)

Paper Quality:

N/A (Digital)

Reader Software:

Adobe Acrobat Reader

Archive Software:

WinRAR (or equivalent unzipping utility)

⚙️ Engine Specifications

Engine Code 1:

2.3L DOHC Duratec I4

Displacement 1:

2295 cc

Horsepower 1:

145 hp @ 6000 rpm

Torque 1:

155 lb-ft @ 4000 rpm

Engine Code 2:

3.0L SOHC Vulcan V6

Displacement 2:

2986 cc

Horsepower 2:

181 hp @ 5250 rpm

Torque 2:

200 lb-ft @ 3750 rpm

Fuel Delivery:

Electronic Fuel Injection (EFI)

Fuel Type:

Unleaded gasoline (87 octane recommended)

🔧 Transmission

Transmission Type 1:

5-speed manual (M5R1)

Transmission Type 2:

4-speed automatic (AX4N/4F50N)

AWD Integration:

Available with either transmission for All-Wheel Drive models.

📐 Dimensions

Length:

178.7 in (4539 mm)

Width:

71.7 in (1821 mm)

Height:

67.3 in (1709 mm)

Wheelbase:

103.1 in (2619 mm)

Cargo Volume Behind Rear Seat:

34.7 cu ft (982 L)

Cargo Volume With Rear Seat Folded:

67.2 cu ft (1903 L)

Curb Weight FWD I4:

3447 lbs (1564 kg)

Curb Weight AWD V6:

3782 lbs (1715 kg)

🛡️ Safety Features

NHTSA Frontal Driver Impact:

★★★★★ (5-Star)

NHTSA Frontal Passenger Impact:

★★★★★ (5-Star)

IIHS Front Offset Crash Rating:

Good

ABS:

Standard Anti-lock Braking System

Traction Control:

Available Traction Control System (TCS)

Airbags Front:

Dual front airbags

Airbags Side:

Optional front-seat side airbags

Seatbelts:

Height-adjustable front seatbelts with pretensioners

💡 Technology Features

Audio System:

Optional premium audio systems, CD player, available satellite radio.

Cruise Control:

Standard cruise control.

Power Accessories:

Power windows, power door locks, power mirrors.

🔧 Maintenance

Oil Change Interval:

Every 5,000 miles (8,000 km) or 6 months, whichever comes first, using synthetic blend or full synthetic oil.

Engine Air Filter:

Inspect every 15,000 miles (24,000 km), replace as needed.

Cabin Air Filter:

Inspect every 15,000 miles (24,000 km), replace as needed (if equipped).

Spark Plugs Duratec:

100,000 miles (160,000 km) with iridium-tipped spark plugs.

Spark Plugs Vulcan:

60,000 miles (96,000 km) with copper-core spark plugs.

Transmission Fluid Change:

Every 100,000 miles (160,000 km) for automatic transmission, or under severe driving conditions.

Engine Oil Type Duratec:

SAE 5W-20, meeting Ford specification WSS-M2C153-H.

Engine Oil Type Vulcan:

SAE 5W-30, meeting Ford specification WSS-M2C186-A.

Coolant Type:

Ford Premium Engine Coolant (Orange), meeting specification WSS-M97B44-D.

Automatic Transmission Fluid:

MERCON V (or equivalent)

Power Steering Fluid:

Ford Power Steering Fluid (Blue), meeting specification WSS-M2C195-A.

Common Problems:

Ignition coil failure, dashboard cracking, ABS sensor issues, rear trailing arm bushings wear, catalytic converter failure (especially with V6), transmission solenoid issues.

📚 Vehicle History

Ford SUV History:

Ford's long history in SUV production includes the Bronco, Explorer, and Expedition, establishing expertise in the segment.

Generation:

First Generation (2001-2007)

Facelift Year:

2005 received a mid-cycle refresh with updated styling, interior features, and engine refinements.

Manufacturing Plant:

Kansas City Assembly Plant, Claycomo, Missouri, USA

🏆 Awards & Recognition

IIHS Top Safety Pick:

While not consistently a 'Top Safety Pick' in every iteration, its safety scores were generally strong for its class and year.
