Market Segment:
Compact hatchback, known for affordability and practicality in emerging markets like India and South Africa.
Key Competitors 2010:
Hyundai i10, Maruti Suzuki Swift, Volkswagen Polo Vivo, Chevrolet U-VA.
Design Philosophy:
Based on the Ford Fiesta Mk6 platform, offering a blend of European styling with practicality suited for developing markets. Emphasizes fuel efficiency and cost-effectiveness.
Target Audience:
First-time car buyers, budget-conscious families, individuals seeking a reliable and economical small car.
Diy Benefits:
Empowers owners to perform their own maintenance and repairs, saving significant costs on labor and improving vehicle longevity. Provides peace of mind and self-sufficiency.
Coverage Scope:
Comprehensive service, repair, maintenance, and troubleshooting for the Ford Figo 2010.
Specific Coverage:
General Maintenance, Troubleshooting, Engine Service/Repair, Transmission Service/Repair, Brake System, Wiring Diagram, Electrical System, Suspension, Periodic Lubrication, Steering, Cooling System, Fuel Injection/Fuel System, Emission System, Engine Control System, Chassis/Body, Restraint System, Axle.
Estimated Page Count:
Detailed page count not specified, but typically comprehensive factory service manuals range from 1,500 to 3,000+ pages.
Manual Type:
Factory Service Manual / Workshop Manual / Repair Manual
Powertrain:
Engine (including disassembly, assembly, diagnostics, repair), Transmission (manual and automatic, if applicable, with repair procedures), Fuel System (injection, pumps, lines, diagnostics), Ignition System, Emission Control System.
Chassis:
Suspension (front and rear, components, alignment), Steering System (components, power steering, diagnostics), Brake System (hydraulic, ABS, disc/drum repair), Wheels and Tires, Drive Axles.
Electrical And Body:
Electrical System (complete wiring diagrams, component testing), Lighting System, Instrumentation, Audio System, HVAC System, Body Panels, Doors, Seats, Restraint System (Airbags, Seatbelts), Chassis and Body Repair.
Diagnostic Procedures:
Troubleshooting guides, symptom-based diagnostics, fault code interpretation (OBD-II if applicable), component testing procedures.
Repair Procedures:
Step-by-step instructions for disassembly, repair, reassembly, and adjustment of all major vehicle systems and components.
Maintenance Procedures:
Scheduled maintenance tasks, fluid checks and changes, filter replacements, lubrication points and schedules, inspection procedures.
Depth Of Information:
Detailed technical specifications, torque values, tolerances, diagnostic flowcharts, repair times, and component-specific data. Covers everything from routine maintenance to complete engine and transmission rebuilds.
Engine Options 2010:
1.4L Duratorq TDCi Diesel (DV4) and 1.6L Duratec Ti-VCT Petrol (Sigma).
1.4L Tdci:
Approx. 68 hp (50 kW) at 4000 rpm, 160 Nm (118 lb-ft) torque at 2000 rpm.
1.6L Duratec Ti-Vct:
Approx. 100 hp (74 kW) at 6500 rpm, 146 Nm (108 lb-ft) torque at 4000 rpm.
Fuel Delivery Diesel:
Common Rail Direct Injection (CRDi)
Fuel Delivery Petrol:
Electronic Fuel Injection (EFI) with Variable Valve Timing (Ti-VCT)
ECU Type:
Likely Siemens VDO or Bosch ECU for engine management and diagnostics.
Transmission Type Diesel:
5-speed Manual Transmission (MTX 75 variant or similar).
Transmission Type Petrol:
5-speed Manual Transmission (MTX 75 variant or similar).
Optional Transmission:
A 4-speed automatic transmission was available in some markets, likely a Jatco 4F15E or similar.
Clutch Type:
Hydraulically actuated diaphragm spring clutch.
Length:
Approx. 3950 mm (155.5 inches)
Width:
Approx. 1650 mm (65.0 inches)
Height:
Approx. 1470 mm (57.9 inches)
Curb Weight Diesel:
Approx. 1100-1150 kg (2425-2535 lbs)
Curb Weight Petrol:
Approx. 1050-1100 kg (2315-2425 lbs)
Latin Ncap Rating:
Zero stars for adult occupancy in its original Latin NCAP test (2013).
Active Safety:
Optional ABS with EBD, optional front disc brakes.
Passive Safety:
Driver and front passenger airbags (standard on higher trims, optional on base models), front and rear seatbelt pre-tensioners.
Infotainment System:
Basic Ford CD/MP3 player with radio, auxiliary input. Higher trims may have steering-mounted audio controls.
Driver Assistance Features:
Limited. Parking sensors were an optional accessory. No advanced driver-assistance systems (ADAS) were offered.
Connectivity Options:
Auxiliary input for audio devices. Bluetooth was typically not standard in 2010 models.
Oil Change Interval Petrol:
Typically every 10,000 km (6,200 miles) or 12 months, whichever comes first.
Oil Change Interval Diesel:
Typically every 7,500-10,000 km (4,600-6,200 miles) or 12 months, whichever comes first, depending on driving conditions.
Air Filter Replacement:
Recommended every 20,000-40,000 km (12,500-25,000 miles) or as needed based on conditions.
Spark Plug Replacement Petrol:
Typically every 60,000-100,000 km (37,000-62,000 miles) for standard plugs, longer for iridium/platinum.
Engine Oil Petrol:
API SJ or higher, SAE 5W-30 or 5W-40 (refer to manual for specific recommendations).
Engine Oil Diesel:
API CF or higher, SAE 5W-30 or 5W-40 (Ford specification WSS-M2C913-B or similar).
Coolant:
Ethylene Glycol based coolant, meeting Ford specification WSS-M97B44-D or equivalent. Typically a 50/50 mix with distilled water.
Brake Fluid:
DOT 3 or DOT 4 brake fluid.
Transmission Fluid Manual:
API GL-4, SAE 75W-90 synthetic gear oil.
Transmission Fluid Automatic:
Mercon V or equivalent ATF fluid.
Common Problems:
Early models sometimes experienced clutch wear issues, some reports of suspension component wear, and potential issues with the EGR valve in diesel models under heavy city driving.
Electrical Quirks:
Intermittent electrical faults or issues with power windows have been reported in some instances.
Ford Small Car Legacy:
Ford has a long history of producing successful small cars globally, with models like the Fiesta and Escort influencing the Figo's design and engineering.
Figo Development:
Developed specifically for emerging markets, adapting the global Fiesta platform for local manufacturing and cost efficiencies. First launched in India in 2010.
Manufacturing Locations:
Primarily manufactured in India (Chennai) and South Africa (Pretoria) for respective regional markets.
