🏷️ Basic Information

Make:

Ford

Model:

Five Hundred

Year:

2006

Engine:

3.0L Duratec V6 (3.0L AJ)

Transmission:

6-speed Automatic (6F50)

Drivetrain:

Front-Wheel Drive (FWD) or All-Wheel Drive (AWD)

Chassis Code:

Ford D3 Platform

👋 Introduction

Market Position:

The Ford Five Hundred was positioned as a premium, full-size sedan aimed at families and those seeking comfort, space, and a smooth ride. It competed with vehicles like the Toyota Avalon, Buick Lucerne, and Chrysler 300.

Competitive Analysis:

The Five Hundred offered a spacious interior and a comfortable ride, often praised for its quiet cabin. Its AWD option was a significant differentiator in its segment. However, it faced challenges with its powertrain (initially perceived as underpowered by some reviewers) and styling, which was considered somewhat conservative by some.

Key Features:

Spacious interior, comfortable and quiet ride, available AWD, strong safety credentials, intuitive controls. The manual provides factory-level access to maintain and repair these features.

📋 Manual Details

Coverage Areas:

All Models & All Repairs A-Z

Page Count:

Estimated 1500-2000+ pages (typical for comprehensive factory service manuals)

Manual Type:

Factory Service Manual / Repair Manual

Language:

English

Format:

PDF

📖 Manual Coverage

Systems Covered:

Maintenance, Engine Mechanical, Engine Control System, Fuel Service, Emission Control, Intake, Exhaust, Cooling, Lube, Ignition, Starting, Charging, Automatic Transmission, Transfer Case, Drive Shaft, Differential, Axle, Suspension, Tire & Wheel, Brake Control, Brakes, Parking Brake, Steering Column, Power Steering, Air Conditioning, Supplemental Restraint System (SRS), Seat Belts, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Locks, Meter, Audio/Visual, Horn, Windshield/Glass/Mirrors, Instrument Panel, Seats, Engine Hood/Doors, Exterior & Interior Trim, Electrical Systems, Multiplex/CAN Communication

Procedures Included:

Step-by-step repair instructions, diagnostic procedures, troubleshooting guides, fluid and lubricant specifications, torques specifications, wiring schematics, component identification, overhaul procedures, routine maintenance, replacement procedures

Technical Depth:

Factory-level detailed diagnostics, repair, and maintenance for all vehicle systems. Comprehensive coverage from basic fluid checks to complete engine and transmission rebuilds. Includes detailed explanations of system operation and diagnostic trouble codes (DTCs).

📊 Manual Specifications

File Format:

Adobe PDF, compatible with Adobe Reader

Print Quality:

High-resolution, printable pages with clear diagrams and illustrations. Ability to enlarge images for detailed viewing.

Binding Type:

Digital (PDF - no physical binding)

Paper Type:

N/A (Digital format, printable on user-selected paper type)

⚙️ Engine Specifications

Primary Engine:

3.0L Duratec V6 (AJ)

Horsepower:

203 hp @ 6000 rpm

Torque:

207 lb-ft @ 4000 rpm

Fuel System:

Electronic Fuel Injection (EFI)

Engine Management:

Ford's Powertrain Control Module (PCM) utilizing OBD-II diagnostics.

Bore X Stroke:

3.50 in x 3.15 in (89.0 mm x 80.0 mm)

Compression Ratio:

9.7:1

Firing Order:

1-4-2-5-3-6

🔧 Transmission

Standard:

6-speed Automatic (6F50)

Optional:

Not applicable for this model year as 6-speed auto was standard.

Features:

Traction Control (TC), Electronic Stability Program (ESP) integration, Manual Override (SelectShift - though early implementation was basic).

Transmission Fluid:

Mercon LV (Refer to manual for exact specification and capacity)

📐 Dimensions

Length:

200.7 in (5098 mm)

Width:

74.0 in (1880 mm)

Height:

57.9 in (1471 mm)

Wheelbase:

112.7 in (2863 mm)

Passenger Volume:

106.0 cu ft (3.00 m³)

Trunk Volume:

16.2 cu ft (0.46 m³)

Curb Weight FWD:

Approx. 3,618 lbs (1641 kg)

Curb Weight AWD:

Approx. 3,783 lbs (1716 kg)

🛡️ Safety Features

NHTSA Front Crash Rating:

5-Star (Driver and Passenger)

NHTSA Side Impact Rating:

5-Star (Front and Rear Passengers)

IIHS Rollover Rating:

Good

Active Features:

Anti-lock Braking System (ABS), Traction Control (TC), Electronic Stability Program (ESP)

Passive Features:

Frontal airbags, Front side-impact airbags, Side-curtain airbags (front and rear), Pretensioning seat belts, LATCH child seat anchors

💡 Technology Features

Infotainment System:

Available Audiophile AM/FM stereo with CD player, MP3 capability, and subwoofer. Optional Sirius Satellite Radio. Ford's SYNC system was not available on this model year.

Driver Assistance:

Standard features included ABS, Traction Control, and ESP. Optional features like rear parking sensors were available.

Connectivity:

Basic connectivity via auxiliary input for audio devices. Limited compared to modern vehicles.

🔧 Maintenance

Oil Change Interval:

Every 5,000 miles or 6 months (refer to manual for specific mileage/driving conditions; synthetic oil may allow longer intervals)

Engine Air Filter Replacement:

Every 15,000-30,000 miles or as needed based on driving conditions (refer to manual)

Cabin Air Filter Replacement:

Every 15,000-20,000 miles or annually (refer to manual)

Transmission Fluid Change:

Every 100,000 miles (severe service may require more frequent changes; consult manual for exact procedures and fluid type)

Engine Oil Type:

SAE 5W-20 (API Certified, meeting Ford specification WSS-M2C153-H)

Coolant Type:

Ford Gold Coolant (or equivalent meeting WSS-M97B51-A1, typically a 50/50 mix with distilled water)

Brake Fluid Type:

DOT 3 (or higher, meeting specification WSS-M6C65-A2)

Known Issues:

Some reports of premature wear in front suspension components (e.g., control arm bushings, sway bar links), potential transmission issues (though generally reliable), and occasional electrical gremlins. The manual is crucial for diagnosing and repairing these.

Spark Plugs:

Typically iridium-tipped spark plugs (e.g., Motorcraft PZT14F) with a recommended replacement interval of 100,000 miles.

📚 Vehicle History

Brand Heritage:

Ford has a long history of producing reliable and popular vehicles, with a strong presence in the American automotive market for over a century.

Model Evolution:

The Five Hundred was introduced for the 2005 model year as Ford's flagship sedan, replacing the Ford Crown Victoria in many respects (though the Crown Vic continued briefly). It was based on the Volvo-engineered D3 platform. It was redesigned and renamed the Ford Taurus in 2008.

Production Location:

Ford's Chicago Assembly Plant, Illinois, USA

Production Years:

2005-2007

🏆 Awards & Recognition

Recognitions:

While specific major awards for the 2006 model year are not widely cited, the Ford Five Hundred consistently received positive marks for safety, particularly from the IIHS and NHTSA.

Ratings:

Good safety ratings from IIHS and NHTSA for frontal and side impact, contributing to its appeal as a family sedan.
