Segment:
Compact car (C-segment)
Key Competitors 2001:
Honda Civic, Toyota Corolla, Chevrolet Cavalier, Mazda Protege, Volkswagen Golf
Focus Strengths:
European-inspired design, responsive handling, comfortable ride, spacious interior for its class
Body Styles:
2-door coupe, 4-door sedan, 5-door hatchback
Engines Availability Na:
1.6L (SPI), 2.0L (Zetec)
Powertrain:
Engine (2.0L SPI DOHC, 2.0L Zetec DOHC), Transmission (5-speed manual, 4-speed automatic), Drivetrain (FWD)
Chassis:
Suspension (Front MacPherson strut, Rear independent multi-link), Steering (Power rack and pinion), Brakes (Front discs, Rear drums/discs depending on spec)
Electrical:
Body Control Module (BCM), Powertrain Control Module (PCM), Lighting, Instrumentation, Audio System, HVAC Controls, Anti-theft System
Body And Interior:
Body panels, Doors, Hood, Trunk, Glass, Seats, Trim, Restraint systems (Airbags)
Maintenance:
Oil changes, Filter replacements, Spark plug replacement, Fluid checks and top-offs, Belt inspection/replacement
Troubleshooting:
Diagnostic Trouble Codes (DTCs), Symptom-based diagnosis, Electrical system diagnosis, Engine performance issues
Repair:
Engine component removal/installation, Transmission overhaul, Brake caliper/rotor replacement, Suspension arm/bushings, CV joint replacement, Radiator replacement
Diagnostics:
OBD-II diagnostics, Sensor testing, Actuator testing, Wiring diagram interpretation
Depth:
Comprehensive, covering routine maintenance to major component overhaul and diagnostics. Includes detailed wiring diagrams and component locations.
Engine Code Zetec:
Zetec-E
Displacement Zetec:
2.0 liters (1988 cc)
Configuration Zetec:
Inline-4 cylinder, DOHC, 16 valves
Bore X Stroke Zetec:
84.8 mm x 88.0 mm
Compression Ratio Zetec:
10.0:1
Horsepower Zetec:
110-111 hp @ 5300 rpm (NA spec)
Torque Zetec:
125 lb-ft @ 4000 rpm (NA spec)
Displacement Spi:
2.0 liters (1988 cc)
Configuration Spi:
Inline-4 cylinder, SOHC, 8 valves
Horsepower Spi:
100-105 hp @ 5000 rpm (NA spec)
Torque Spi:
120 lb-ft @ 3400 rpm (NA spec)
0-60 Mph Approx Zetec:
9.0-10.0 seconds
Injection Type:
Electronic Fuel Injection (EFI), Sequential Multi-Port Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline (87 octane recommended)
Coolant Type:
Ford Premium Engine Coolant (Green) or equivalent
Coolant Capacity:
7.0-7.5 quarts (6.6-7.1 liters)
Type Manual:
MTX-75 5-speed manual
Type Automatic:
4-speed automatic (AX4S/AX4N family)
Clutch Type:
Dry single plate, hydraulic actuation
Automatic Transmission Fluid Spec:
Mercon V (or equivalent, check specific application)
Manual Transmission Fluid Spec
Fluid Type:
API GL-4 SAE 75W-90 synthetic gear oil (check specific manual for exact spec)
Length Sedan:
169.7 inches (4310 mm)
Width Excluding Mirrors:
66.5 inches (1690 mm)
Height Sedan:
57.1 inches (1450 mm)
Wheelbase:
101.3 inches (2573 mm)
Trunk Volume Sedan:
13.9 cubic feet (394 liters)
Curb Weight Approx Manual:
2700-2800 lbs (1225-1270 kg)
Gross Vehicle Weight Rating Gvwr Approx:
3700-3800 lbs (1680-1725 kg)
Standard Wheel Size:
15 inch steel or alloy
Standard Tire Size:
195/60R15
Lug Nut Torque:
100-120 Nm (74-89 lb-ft)
NHTSA Front Impact Driver:
Good (for 2001 model year ratings of similar vehicles)
NHTSA Front Impact Passenger:
Good (for 2001 model year ratings of similar vehicles)
IIHS Moderate Overlap Frontal Offset:
Acceptable (for 2001 model year ratings of similar vehicles)
ABS:
Available on select trims, standard on higher trims
Airbags Driver Passenger:
Standard dual front airbags
Seatbelts:
3-point front and rear seatbelts, pretensioners for front seats
Child Seat Anchors:
LATCH system (Lower Anchors and Tethers for Children)
Audio System Options:
AM/FM stereo with CD player, cassette player, and optional premium sound system.
Display:
Basic digital or analog displays for radio, clock, and climate control.
Cruise Control:
Available on most trims
Auxiliary Input:
Not standard, may be an aftermarket addition
Oil Change Interval Typical:
5,000 miles (8,000 km) or 6 months, whichever comes first (under normal driving conditions)
Engine Oil Filter Replacement:
Replace with each oil change
Air Filter Replacement:
Every 30,000 miles (48,000 km) or as needed based on inspection
Spark Plug Replacement Zetec:
Approximately 100,000 miles (160,000 km) for platinum or iridium plugs
Coolant Flush Interval:
Every 50,000 miles (80,000 km) or 5 years
Engine Oil Spec:
SAE 5W-30 or 5W-20 (refer to owner's manual for specific recommendations, API certified)
Engine Oil Capacity:
4.3 quarts (4.1 liters) with filter for 2.0L Zetec
Power Steering Fluid Spec:
Mercon V ATF or Ford specification WSS-M2C195-A
Common Problems Zetec:
Ignition coil failures, coolant leaks (especially from plastic thermostat housing), occasional transmission issues (automatic).
Common Problems Spi:
Less common issues, but potential for oil leaks and minor electrical gremlins.
Body Issues:
Rust on wheel wells and rocker panels in certain climates, interior trim rattles.
Ford History:
Ford Motor Company, founded by Henry Ford, revolutionized automotive manufacturing with the assembly line and the Model T. Known for innovation and mass production.
Focus Introduction Global:
Introduced globally in 1998 as a replacement for the Ford Escort.
Focus North American Launch:
Launched in North America for the 2000 model year, succeeding the Escort ZX2.
2001 Model Year Updates:
Minor updates including potentially new option packages and feature availability. This year marks the early production of the Mk1 platform in North America.
Manufacturing Plants Na:
Wayne, Michigan, USA; Hermosillo, Mexico
