Vehicle Segment:
Compact Crossover SUV
Target Audience:
Families, individuals seeking versatility and a higher driving position
Key Competitors:
Nissan Qashqai, Volkswagen Tiguan, Peugeot 3008, Mazda CX-5
Powertrain Options:
Range of EcoBoost gasoline engines and TDCi diesel engines, including AWD options
Interior Space:
Generous interior space for its class, practical cargo area
Technology Availability:
Available with Ford's SYNC infotainment system, advanced driver-assistance features
Coverage:
Comprehensive service, repair, maintenance, and diagnostics
Estimated Pages:
Likely 2000+ pages (typical for factory service manuals)
Type:
Factory Service and Repair Manual
Format:
PDF (Digital Download)
Engine:
All engine variants (e.g., 1.5L EcoBoost, 1.6L EcoBoost, 2.0L EcoBoost, 2.0L TDCi Diesel)
Transmission:
Automatic (PowerShift) and Manual Transmissions
Brakes:
Hydraulic Brake System, ABS, Electronic Brakeforce Distribution (EBD), Traction Control (TCS), Stability Control (ESC)
Suspension:
Front and Rear Suspension, Steering System, Power Steering
Electrical:
Complete Electrical System, Wiring Schematics, Lighting, Power Accessories, Body Control Modules (BCM), Powertrain Control Modules (PCM)
Body:
Exterior Body Panels, Doors, Windows, Interior Trim, Seats, Restraint Systems (Airbags, Seatbelts)
HVAC:
Heating, Ventilation, and Air Conditioning (HVAC) System
Fuel System:
Fuel delivery, injection, and emissions control
Cooling System:
Radiator, coolant flow, thermostat, cooling fans
Ignition System:
Spark plugs, coils, ignition timing
Charging Starting:
Alternator, battery, starter motor
Multiplex Communication:
CAN bus communication, network diagnostics
Maintenance:
Routine maintenance (oil changes, filter replacements, fluid checks) and scheduled maintenance intervals
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs), symptom-based diagnostics
Repair:
Step-by-step repair procedures for all major and minor components
Overhaul:
Engine and transmission overhaul procedures
Installation:
Component replacement and installation procedures
Adjustment:
Component adjustments (e.g., clutch, brakes)
Depth:
Factory-level detail, suitable for professional technicians and advanced DIYers
Printability:
Fully printable, allowing individual page or section printing
Binding:
N/A (Digital Format)
Paper Quality:
N/A (Digital Format - user printable)
Text Search:
Searchable text for quick information retrieval
Operating Systems:
Compatible with all versions of Windows and Mac
Reader Software:
Requires Adobe PDF Reader (free) and WinZip or equivalent (free)
Common Gasoline Engines:
1.5L EcoBoost (150 PS, 180 PS), 1.6L EcoBoost (176 PS), 2.0L EcoBoost (240 PS)
Common Diesel Engines:
2.0L TDCi (140 PS, 163 PS, 180 PS)
Eco Boost Features:
Turbocharged, direct injection for improved efficiency and power
Fuel Delivery:
Electronic Fuel Injection (EFI)
Coolant Type:
Ford Super Plus Premium Antifreeze/Coolant (Orange) or equivalent meeting WSS-M97B44-D
Engine Oil Type:
Typically SAE 5W-30 meeting Ford WSS-M2C913-D or WSS-M2C948-B for EcoBoost engines
Manual Transmission:
6-speed manual transmission
Automatic Transmission:
6-speed PowerShift (dual-clutch automatic)
AWD System:
Intelligent All-Wheel Drive (i-AWD) available on select models
Power Shift Fluid:
Ford Powershift Fluid (6-speed Dual Clutch Transmission Fluid), e.g., XT-11-QDC
Length:
Approximately 4556 mm (varies slightly by model year/trim)
Width:
Approximately 1838 mm (excluding mirrors)
Height:
Approximately 1689 mm (excluding roof rails)
Curb Weight:
Ranges from approximately 1500 kg to 1700 kg depending on engine and drivetrain
Euro Ncap Rating:
5-star Euro NCAP (2013)
Electronic Stability Control:
Standard ESP with Traction Control (TCS) and Hill Launch Assist (HLA)
Brake Assist:
Emergency Brake Assist (EBA)
Airbags:
Front, side, and curtain airbags
Seat Belts:
Pre-tensioning seatbelts with load limiters
Sync System:
Covers Ford SYNC 1, SYNC 2, and SYNC 3 infotainment systems, including audio, Bluetooth, and navigation functionalities.
Adaptive Cruise Control:
Procedures for servicing and calibrating Adaptive Cruise Control systems.
Parking Assist:
Details on Automatic Park Assist and front/rear parking sensors.
Usb Connectivity:
Information on USB ports for media playback and device charging.
Bi Xenon Headlights:
Coverage for Bi-Xenon headlights and Active Cornering Lights where equipped.
Oil Change Interval:
Typically 12,500 miles (20,000 km) or 1 year, whichever comes first (check specific engine requirements)
Air Filter Replacement:
Recommended every 30,000 miles (48,000 km) or as needed based on operating conditions
Cabin Filter Replacement:
Recommended annually or every 15,000 miles (24,000 km)
Brake Fluid Type:
DOT 4 Motorcraft High Performance DOT 4 Brake Fluid or equivalent meeting WSS-M6C65-A1
Coolant Capacity:
Approximately 7.5 - 8.0 liters (check owner's manual for exact capacity)
Transmission Fluid Capacity Manual:
Approximately 2.0 - 2.3 liters (check specific transmission)
Powershift Transmission Quirks:
Some early PowerShift transmissions experienced occasional judder or hesitation. The manual addresses diagnostic and repair procedures.
Eco Boost Timing Chain:
While generally reliable, the manual covers inspection and potential replacement procedures for timing chain components on EcoBoost engines.
Drivetrain Maintenance:
The manual provides guidance on servicing the AWD system, including differential fluid changes where applicable.
Ford SUV History:
Ford has a long history in the SUV segment with models like the EcoSport, Escape/Maverick, Explorer, and Edge
First Generation:
The first generation Kuga (2008-2012) was based on the Ford Focus platform
Second Generation Launch:
The second generation (2012-2019) introduced a new design and was built on the global C-segment platform, sharing components with the Ford Focus and C-Max
Manufacturing Locations:
Primarily manufactured in Saarlouis, Germany, and Valencia, Spain
