GM Hummer H3 Workshop Service Repair Manual 2006-2009

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: General Motors (GM) Model: Hummer H3 Generation Generation Designation: First Generation (2006-2010) Production Years Covered By Manual: 2006, 2007, 2008, 2009 Codes Vehicle Identification Number...

16 people are viewing this right now

类型: Truck

斯库: 515160

标签: 2006 2007 2008 2009 Cars Featured Gm H3 Hummer Hummer H3 Truck

产品多属性

Description

🏷️ Basic Information

Identification

Make:

General Motors (GM)

Model:

Hummer H3

Generation

Generation Designation:

First Generation (2006-2010)

Production Years Covered By Manual:

2006, 2007, 2008, 2009

Codes

Vehicle Identification Number Vin Prefix:

👋 Introduction

Market Position

Target Audience:

Hummer H3 owners and independent repair shops seeking comprehensive repair and maintenance information

Competitive Analysis

Value Proposition:

Provides factory-level repair data equivalent to dealership service manuals, enabling significant cost savings on repairs and maintenance

Key Features

Manual Advantage:

Facilitates effortless repair of simple to complex issues with clear, step-by-step instructions and visual aids

Content Breadth:

Covers everything needed to repair, maintain, rebuild, refurbish, or restore the vehicle

📋 Manual Details

Coverage Areas

Primary Coverage:

Comprehensive factory service and repair for the GM Hummer H3

Model Variants Covered:

All Hummer H3 models and all engine types

Page Count

Total Pages:

Over 5000 pages

Manual Type

Manual Type:

Workshop Service Repair Manual

Language

Language:

English

Format

Digital Format:

📖 Manual Coverage

Systems Covered

Powertrain:

Engine overhaul and rebuilding, transmission removal/installation, in-car transmission servicing

Chassis:

Brakes (servicing procedures, troubleshooting), front end and alignment, suspension, U-joints and CV-joints

Body And Interior:

Sunroof

Electrical And Diagnostics:

Wiring diagrams, trouble codes, computer diagnostic trouble tree charts, troubleshooting and diagnostics

HVAC:

Air conditioning service and capacities

Procedures Included

Maintenance:

Factory maintenance schedules and charts, routine servicing

Repair:

Step-by-step repair procedures for simple to complicated repairs

Engine Service:

Timing belt replacement, serpentine belt routings with diagrams, timing belt service procedures

Diagnostic Procedures:

Engine performance analysis, computer diagnostic codes, driving concerns troubleshooting

Technical Depth

Depth Of Information:

Complete factory level detail, suitable for professional technicians and DIY enthusiasts

Data Availability:

Detailed illustrations, diagrams, specifications, and wiring schematics

📊 Manual Specifications

File Format

Format Details:

Adobe PDF, fully indexed and bookmarked by topic, searchable text

Print Quality

Print Capability:

Perfect quality for printing entire manual or selected pages

Zoom Functionality

Visual Aid Capability:

Zoomable diagrams and pictures for detailed part viewing

Compatibility

Device Compatibility:

All versions of Windows & Mac, APP ISO, iPhone, iPad, Android

Software Requirements

Required Software:

Adobe PDF Reader & WinZip

Delivery

Download Method:

Instant download upon payment completion

⚙️ Engine Specifications

Primary Engine

Engine Type Standard:

3.5L Vortec Inline-5 Cylinder (LL8)

Engine Type Optional Early:

3.7L Vortec Inline-5 Cylinder (LLM)

Engine Type Optional Late:

5.3L Vortec V8 (LH6)

Performance

3.5L Horsepower:

205 hp @ 5600 rpm

3.5L Torque:

220 lb-ft @ 2800 rpm

3.7L Horsepower:

242 hp @ 5600 rpm

3.7L Torque:

242 lb-ft @ 4600 rpm

5.3L Horsepower:

300 hp @ 5200 rpm

5.3L Torque:

320 lb-ft @ 4000 rpm

Fuel System

Fuel Delivery:

Multi-port Fuel Injection (MPFI)

Engine Service Procedures

Engine Overhaul Detail:

Comprehensive procedures for complete engine disassembly, inspection, and reassembly

🔧 Transmission

Standard

Transmission Type Standard:

4-speed automatic (4L60-E)

Optional

Transmission Type Optional:

5-speed manual (NV1500, standard on early 3.5L models)

Features

Transmission Overhaul Coverage:

In-car servicing and complete removal/installation procedures for both automatic and manual transmissions

📐 Dimensions

Exterior

Wheelbase:

113.0 inches

Overall Length:

189.7 inches

Overall Width:

81.1 inches (excluding mirrors)

Overall Height:

77.1 inches

Weights

Curb Weight Approx:

4,500 - 5,000 lbs (depending on configuration)

Towing Capacity:

Up to 6,000 lbs

🛡️ Safety Features

Ratings

NHTSA Front Impact:

5-star driver and passenger (2006 models)

NHTSA Side Impact:

5-star driver and rear passenger (2006 models)

Active Features

Traction Control:

Standard electronic traction control system (ETC)

Stability Control:

Available StabiliTrak stability control (on some models)

Passive Features

Airbags:

Front airbags, available side curtain airbags

💡 Technology Features

Infotainment

Infotainment System:

Basic AM/FM stereo with CD player, optional premium sound system, optional navigation (late models)

Driver Assistance

Driver Assistance Features:

ABS, electronic traction control, optional StabiliTrak

Connectivity

Connectivity Options:

Auxiliary input jack (early models), Bluetooth connectivity (optional on later models)

🔧 Maintenance

Service Intervals

Oil Change Interval:

Refer to manual for specific intervals based on driving conditions (typically 7,500 miles / 12 months)

Transmission Fluid Service:

Refer to manual, often around 60,000-100,000 miles or as per severity of use

Fluid Specifications

Engine Oil Specification:

GM dexos1™ Synthetic or equivalent SAE 5W-30 viscosity (check manual for exact specs)

Transmission Fluid Specification:

Dexron-VI Automatic Transmission Fluid (ATF) for 4L60-E; specified gear oil for manual transmission

Coolant Type:

GM Super Coolant (Orange) or equivalent (15-50% Ethylene Glycol / Water Mix)

Known Issues

Common Wear Items:

CV joint boots, sway bar links, wheel bearings, catalytic converters (especially on higher mileage vehicles)

Engine Specific Considerations:

Potential for timing chain stretch on higher mileage 3.7L engines; some V8 models may experience AFM (Active Fuel Management) issues if equipped.

Transmission Notes:

4L60-E automatic transmission can be durable but requires regular fluid changes to prevent wear. Manual transmissions generally robust.

📚 Vehicle History

Brand Heritage

Hummer Brand Origin:

Derived from the military HMMWV (High Mobility Multipurpose Wheeled Vehicle)

Model Evolution

H3 Development Context:

Developed as a more compact and civilian-friendly Hummer, sharing GM's GMT355 truck platform (Colorado/Canyon)

Production

Manufacturing Location:

Shreveport, Louisiana, USA

Production Period:

2005-2010

🏆 Awards & Recognition

Recognitions

Design Award:

Considered iconic for its rugged, off-road styling and distinctive appearance

Ratings

Off Road Capability Rating:

Highly rated for off-road prowess due to ground clearance, short overhangs, and available 4WD systems
