🏷️ Basic Information

Make:

Harley-Davidson

Model:

Breakout

Model Variant:

FXSB & CVO Breakout FXSBSE

Model Years Covered:

2013, 2014, 2015

👋 Introduction

Market Position:

The Harley-Davidson Breakout series occupies a niche in the cruiser market, emphasizing aggressive styling, a powerful engine, and a custom look. This manual caters to owners who value maintaining and customizing these distinctive motorcycles.

Competitive Analysis:

Competes with other American V-twin cruisers offering a similar blend of performance, style, and customizability from brands like Indian Motorcycle. Its extended wheelbase and fat rear tire set it apart visually.

Key Features:

Powerful V-twin engine, distinctive styling with a long wheelbase and wide rear tire, advanced CVO model options with premium finishes and features.

📋 Manual Details

Coverage Areas:

All service and repair procedures, A-Z

Manual Type:

Complete Workshop Service Repair Manual

Format:

Downloadable Digital File

File Format Details:

PDF (Requires Adobe Reader)

Language:

English

Page Count:

Not Specified (Comprehensive)

📖 Manual Coverage

Systems Covered:

Engine, Transmission, Electrical System, Fuel System, Ignition System, Lubrication System, Cooling System, Braking System, Suspension, Chassis, Bodywork, Frame, Wheels, Tires, Handlebars, Controls, Lighting, Instrumentation, Security System

Procedures Included:

Routine Maintenance, Scheduled Service, Engine Overhaul, Transmission Repair, Electrical Troubleshooting, Fuel System Diagnosis and Repair, Brake Service, Suspension Adjustments and Replacement, Frame Inspection, Body Panel Removal and Installation, Wiring Diagrams, Diagnostic Procedures, Special Tool Usage, Torque Specifications

Technical Depth:

In-depth, step-by-step instructions with diagrams and illustrations for all service and repair jobs, suitable for DIY enthusiasts and professional mechanics.

📊 Manual Specifications

File Format:

PDF

Print Quality:

High Quality (Suitable for printing)

Binding Type:

N/A (Digital Download)

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Engine Type:

Air-cooled, Twin Cam 103™

Displacement:

1690 cc (103 cu. in.)

Bore X Stroke:

3.875 in. x 4.380 in. (98.4 mm x 111.3 mm)

Torque:

Approx. 100 ft-lbs @ 3500 RPM (Varies slightly by year and specific tuning)

Engine Type:

Twin Cam 110™ withوأضاف

Displacement:

1802 cc (110 cu. in.)

Torque:

Approx. 115-120 ft-lbs @ 3750 RPM (Varies by specific CVO package and tuning)

Fuel System:

Electronic Sequential Port Fuel Injection (ESPFI)

Ignition System:

High-performance, ignition module with curve mapping

Exhaust System:

2-into-2 shotgun exhaust

🔧 Transmission

Transmission Type:

6-speed Cruise Drive®

Clutch:

Clutch, wet, multi-plate, hydraulic actuation

Gear Ratios:

1st: 9.312, 2nd: 6.460, 3rd: 4.793, 4th: 3.882, 5th: 3.304, 6th: 2.790

Final Drive:

Belt Drive, 32/66 ratio

Transmission Fluid:

Formula+ Transmission Lubricant (or equivalent Harley-Davidson recommended fluid)

📐 Dimensions

Length:

Approx. 96.2 in. (2445 mm)

Seat Height Laden:

Approx. 26.0 in. (660 mm)

Ground Clearance:

Approx. 4.3 in. (110 mm)

Dry Weight:

FXSB: Approx. 672 lbs (305 kg), CVO FXSBSE: Approx. 700 lbs (317 kg)

Gvwr:

Not Specified (Owner’s Manual or VIN Decoder)

Front Tire:

130/60B21 63H

Rear Tire:

240/40R18 79V

Wheel Type:

Cast aluminum

🛡️ Safety Features

Safety Ratings:

Motorcycles are not subject to formal NHTSA crash test ratings. Safety is achieved through rider skill and adherence to operational guidelines.

Active Features:

Anti-lock Braking System (ABS) available as an option or standard on certain trims/years, hydraulic disc brakes front and rear.

Passive Features:

Strong frame construction, stable chassis geometry, integrated lighting system.

💡 Technology Features

Infotainment System:

Base models typically feature a minimalist dashboard with analog speedometer and indicator lights. CVO models may offer more integrated digital displays or sound systems depending on the specific package.

Driver Assistance:

ABS is the primary electronic rider aid available. No advanced driver-assistance systems (ADAS) are present on these models.

Connectivity:

Limited connectivity; typically no integrated Bluetooth or smartphone mirroring on base models. CVO models might offer premium audio with basic connectivity options.

🔧 Maintenance

Initial Service:

First service typically at 1,000 miles (1600 km)

Subsequent Services:

Routine checks every 5,000 miles (8,000 km); major services including fluid changes and inspections typically every 10,000 miles (16,000 km).

Engine Oil:

Harley-Davidson Genuine V-Twin 20W50 or equivalent synthetic motorcycle oil (Check manual for specific grade and API service classification).

Primary Chain Case Oil:

Harley-Davidson Genuine Primary Chain Case Oil or Syn3 Synthetic Motorcycle Oil (Check manual for capacity and type).

Brake Fluid:

DOT 4 (Check manual for specific specifications for front and rear systems).

Fork Oil:

Harley-Davidson Genuine Front Fork Oil or equivalent damping fluid (Specific viscosity as per manual).

Engine Oil Capacity:

Approx. 4 quarts (3.8 liters) with filter change (Check manual for exact capacity).

Known Issues:

Potential issues include early belt wear, occasional electrical gremlins (especially in CVO models with more complex electronics), and normal Twin Cam engine wear patterns. This manual provides diagnostic steps for these and other common concerns.

📚 Vehicle History

Brand Heritage:

Harley-Davidson boasts a rich heritage dating back to 1903, synonymous with American-made V-twin motorcycles, freedom, and a distinctive riding culture.

Model Evolution:

The Breakout was introduced in 2013 as part of the Softail family, aiming to capture the custom motorcycle market with its unique styling elements, notably the wide rear tire and drag-style handlebars. The CVO (Custom Vehicle Operations) versions offered premium features and exclusivity.

Production Years Covered:

2013, 2014, 2015

Manufacturing Location:

USA

🏆 Awards & Recognition

Recognitions:

While specific awards for the FXSB/FXSBSE models are not widely publicized as standalone achievements, they are part of Harley-Davidson's successful cruiser lineup, recognized for their styling and performance within the V-twin segment.

Customer Satisfaction:

Generally high customer satisfaction due to the Harley-Davidson brand loyalty and the unique appeal of the Breakout's design. Owner reviews often praise the engine performance and styling.
