🏷️ Basic Information

Make:

Holden

Model:

Torana / Sunbird LX

Sub Model:

SLR, SLR5000, SS, A9X, Sunbird

Chassis Codes:

LX

Parts Catalog Number 1:

M38269

Parts Catalog Number 2:

M37757

Publication Date:

June 1980

👋 Introduction

Positioning:

Essential resource for owners and mechanics of Holden Torana and Sunbird LX models seeking parts information, restoration, or maintenance.

Analysis:

This catalog fills a critical need for genuine and aftermarket part identification for these classic Australian muscle cars and their popular variants. Its comprehensive nature with exploded diagrams and part numbers is superior to generic parts listings.

Features:

Extensive coverage of all LX Torana and Sunbird variants, detailed illustrations, part number cross-referencing, and a user-friendly digital format.

📋 Manual Details

Covered Models:

Torana (SL, SLR, SLR5000, SS, A9X), Sunbird (LX)

Covered Body Styles:

Sedan, Hatchback

Covered Engines:

4 Cylinder, 6 Cylinder, V8

Total Pages:

800+

Type:

Illustrated Parts Catalog

Content Type:

Parts and Accessories Catalogue, Text and Illustrated Catalogues

Language:

English

File Format:

Zipped PDF

Accessibility:

Works on all computers

Print Capability:

Print out what you need

📖 Manual Coverage

Powertrain:

Engine, Clutch, Transmissions, Rear Axle

Cooling Lubrication:

Cooling System, Oiling System

Fuel Exhaust:

Fuel System, Exhaust System

Electrical:

Electrical System, Ignition System

Chassis:

Brakes, Suspension, Steering, Springs, Bumpers

Body Interior:

Sheet Metal, Accessories, Air Conditioning, Heater, Windshield, Doors, Hardware, Glass, Body Mouldings, Seat Parts, Headlinings, Trim, Carpets, Mats

Parts Identification:

Exploded diagrams, Part numbers

Parts Interchange:

Interchangeability between models highlighted

Catalog Search:

Alphabetical Parts Index, Numerical Parts Index

Depth:

Comprehensive coverage from nuts and bolts to major assemblies

📊 Manual Specifications

File Type:

PDF

Searchability:

Likely text-searchable within PDF, depending on scan quality

Print Features:

Printable sections, allowing users to print specific pages or chapters

Binding Type:

Not applicable (digital format)

Paper Type:

Not applicable (digital format)

Navigation Features:

Bookmarked Chapters for easy navigation

⚙️ Engine Specifications

Engine Options:

4-cylinder, 6-cylinder, V8 (various displacements including 202ci, 253ci, 308ci)

Note:

Specific performance figures (HP/Torque) vary significantly by engine and tuning, but the A9X and SLR5000 models were performance-oriented variants.

Fuel Delivery:

Carbureted (e.g., Stromberg, Holley) and potentially fuel injection on some later or modified variants, though primarily carbureted for factory LX.

Common V8 Codes:

LH 253, LC 308 (V8s used were commonly the Holden 253 and 308 cubic inch engines)

🔧 Transmission

Transmission Types:

Manual (3-speed, 4-speed) and Automatic (3-speed Trimatic)

Performance Transmissions:

Often fitted with performance-oriented manual gearboxes, especially on SLR and A9X models.

Gearbox Coverage:

The catalog covers all components and variations of manual and automatic transmissions offered.

📐 Dimensions

Wheelbase:

Approx. 100 inches (2540 mm) for Torana sedan, slightly different for hatchbacks.

Curb Weight Range:

Approx. 1100-1300 kg depending on engine and configuration.

Gvm Rating:

Varies by model and axle configuration, detailed in specific vehicle service manuals.

🛡️ Safety Features

Safety Standards:

Manufactured to Australian Design Rules (ADRs) of the era, featuring standard seatbelts and basic crash structures.

Braking System:

Front disc brakes (often power assisted on V8s and performance models), rear drum brakes. A9X featured ventilated front discs and rear discs.

Restraints:

Lap-sash seatbelts for front occupants, lap belts for rear occupants.

Body Structure:

Integrated body-chassis construction, designed for torsional rigidity.

💡 Technology Features

Original Features:

AM/FM Radio, Cassette player (optional on some models).

Driver Aids:

None from a modern perspective. Power steering was an option on some models.

Connectivity Features:

No electronic connectivity features.

🔧 Maintenance

Oil Change Interval:

Typically every 5,000 km or 3 months for vehicles of this era, but consult specific workshop manuals for precise recommendations based on engine type and usage.

Engine Oil Viscosity:

Commonly SAE 20W-50 or 10W-30, depending on climate and engine condition. Refer to the manual for specific engine recommendations.

Coolant Type:

Ethylene glycol-based coolant, typically a 50/50 mix with water. Specific Holden recommendations apply.

Brake Fluid Type:

DOT 3 or DOT 4 brake fluid is generally recommended.

Common Wear Items:

Bushings (suspension, steering), brake components, cooling system hoses, ignition system components, exhaust system wear.

Body Corrosion:

Prone to rust in common areas such as wheel arches, sills, door bottoms, and around windows, typical for vehicles of this age.

Note:

This catalog is invaluable for identifying and sourcing specific Holden parts, many of which are no longer in production and are sourced from specialist suppliers or through part interchange.

📚 Vehicle History

Manufacturer:

Holden, an Australian automotive marque with a long history of local manufacturing and performance vehicle development.

Torana Lineage:

The Torana evolved through several generations, with the LX being the final iteration of the LH/LX platform, renowned for its performance variants like the SLR5000 and the homologation special A9X.

Production Period Lx:

1976-1978 for the LX Torana range.

Sunbird Integration:

The Sunbird was often positioned as a more compact and economical model, sharing some platform elements with the Torana, particularly in later iterations like the LX Sunbird.

A9X Significance:

The A9X was a homologation special developed for Group C touring car racing, featuring significant mechanical upgrades, including four-wheel disc brakes.

🏆 Awards & Recognition

Performance Legacy:

The Torana A9X is highly regarded in Australian motorsport history, particularly for its successes at Bathurst.

Collectibility:

High collectibility for all variants, especially the SLR5000 and A9X models, making this parts catalog a key resource for collectors and restorers.
