Model Segment:
Retro-styled naked sportbike, appealing to riders seeking classic aesthetics with modern performance and reliability.
Competitors:
BMW R NineT, Triumph Bonneville T120, Moto Guzzi V7, Kawasaki Z900RS.
Model Highlights:
Inline-four engine, classic styling with a modern twist, comfortable ergonomics, robust build quality, available ABS (on 'A' and 'SA' variants).
Manual Coverage Summary:
Comprehensive service and repair information for the 2013-2016 Honda CB1100, CB1100A, and CB1100SA motorcycles, covering all major mechanical, electrical, and bodywork systems.
Page Count:
Over 600 pages
Manual Type:
Digital Factory Service Manual
Language:
English (presumed based on product description and typical market distribution)
Engine Systems:
Engine removal/installation, cylinder head and valves, cylinder and piston, lubrication system, fuel system (PGM-FI), alternator and starter clutch, crankshaft, transmission, balancer.
Chassis Systems:
Frame, body panels, exhaust system, front wheel, front suspension, steering, rear wheel, rear suspension.
Braking Systems:
Hydraulic brake system, Anti-Lock Brake System (ABS) for applicable models.
Electrical Components:
Battery, charging system, ignition system, electric starter, lights, meters, switches, wiring diagrams.
Maintenance Procedures:
Scheduled maintenance, lubrication, fluid changes, filter replacements, inspections, adjustments.
Repair Procedures:
Detailed step-by-step instructions for disassembly, assembly, and repair of all major components and systems.
Troubleshooting Diagnostics:
Systematic troubleshooting guides, diagnostic procedures, symptom analysis, and corrective actions for common and uncommon issues.
Depth Of Information:
Factory-level detail suitable for professional technicians and experienced DIY mechanics, covering everything from basic maintenance to complete engine rebuilds and advanced electrical diagnostics.
PDF Features:
Unlocked, printable, copyable to multiple devices, bookmarked, and searchable.
Print Readability:
High-quality digital reproduction suitable for printing, with clear diagrams and text.
Binding:
N/A (Digital Format)
Paper Type:
N/A (Digital Format)
Engine Type:
Air-cooled, 4-stroke, DOHC, 16-valve inline-four
Displacement:
1140 cc (1142 cm³)
Bore X Stroke:
74.0 mm x 64.9 mm
Power Output:
Approximately 95 PS (94 bhp / 70 kW) at 7,500 rpm (figures may vary by market).
Torque Output:
Approximately 104 Nm (76.7 lb-ft) at 6,000 rpm (figures may vary by market).
Fuel Delivery:
PGM-FI (Programmed Fuel Injection) with electronic throttle control (throttle-by-wire).
Fuel Type:
Unleaded gasoline
Fuel Tank Capacity:
14.6 Liters (3.87 US gal)
Cooling Method:
Air-cooled
Lubrication System:
Wet sump
Engine Oil Capacity:
3.4 Liters (3.6 US qt) with oil filter change.
Safety Certifications:
Complies with relevant safety standards for motorcycles in target markets (e.g., DOT, ECE where applicable).
Anti Lock Brakes:
Available on CB1100A and CB1100SA models, providing enhanced braking control.
Lighting:
Halogen headlight, LED taillight, and standard front/rear turn signals.
Instrumentation:
Classic dual analog gauges (speedometer and tachometer) with a multi-function LCD display for odometer, trip meters, fuel gauge, clock, and gear position indicator.
ABS Availability:
Available on specific trim levels (CB1100A, CB1100SA) to enhance safety during braking.
Connectivity Features:
N/A (Focus is on mechanical and electrical systems, not modern infotainment connectivity).
Oil Change Interval:
Recommended every 12,000 km (7,500 miles) or 12 months, whichever comes first (refer to manual for exact specifications).
Major Service Interval:
Valve clearance checks and adjustments typically recommended every 24,000 km (15,000 miles) or as specified in the manual.
Engine Oil Grade:
SAE 10W-30 API SG or higher (synthetic blend or full synthetic recommended for optimal performance).
Coolant Type:
N/A (Air-cooled engine)
Common Wear Items:
Tires, brake pads, chain and sprockets, clutch plates (subject to riding style and maintenance).
Potential Minor Issues:
Occasional reports of minor electrical connection issues or feedback from the fuel injection system, typically resolved by routine checks and manual-guided diagnostics.
Honda Motorcycle Legacy:
Honda has a long and distinguished history in motorcycle manufacturing, renowned for reliability, engineering innovation, and rider-focused design.
Cb Series Lineage:
The CB1100 builds upon Honda's iconic CB lineage, harkening back to the golden era of motorcycles with its inline-four engine and classic styling, while incorporating modern technology.
Manufacturing Location:
Japan
Initial Release:
The CB1100 was initially released in Japan in 2010 and subsequently introduced to other markets, including North America, for the 2013 model year.
