🏷️ Basic Information

Make:

Honda

Model:

CTX1300

Model Variant:

CTX1300 (Standard/Deluxe)

Model Years Covered:

2014, 2015, 2016, 2017

Chassis Codes:

SC73 (for 2014-2015 models), SC73A (for 2016-2017 models)

👋 Introduction

Target Audience:

Owners of Honda CTX1300 motorcycles seeking comprehensive repair and maintenance information, independent repair shops, professional mechanics

Value Proposition:

Provides factory-level diagnostic and repair data, saving significant costs compared to dealership service; lifetime access and comprehensive coverage offer superior value over limited subscriptions or basic guides.

Manual Features:

Instant download, lifetime access, printable pages, multi-device compatibility, full factory coverage, detailed visuals.

📋 Manual Details

Manual Type:

Factory Service Repair Workshop Manual

Language:

English

Format:

PDF Download

Platform Compatibility:

Windows, MAC Computers, Tablets, Smartphones

Licensing:

Lifetime Use, No Expiry, No Renewal Fees

Download Access:

Instant Download

📖 Manual Coverage

Engine:

Complete engine disassembly, assembly, tuning, and troubleshooting

Fuel System:

Fuel injection system, fuel pump, injectors, throttle body, fuel filter replacement

Ignition System:

Spark plugs, ignition coils, timing, troubleshooting

Transmission:

Manual 5-speed transmission, clutch service, internal components, gear oil specifications

Chassis And Frame:

Frame inspection, adjustments, steering head bearings

Suspension:

Front fork service (oil change, seals), rear shock absorber inspection and replacement

Brakes:

Front and rear brake caliper service, brake fluid replacement, bleeding procedures, ABS system (if applicable)

Electrical System:

Battery service, charging system, starter motor, lighting, horn, wiring diagrams, ECU diagnostics

Cooling System:

Radiator, coolant type and capacity, thermostat, fan operation

Exhaust System:

Muffler, catalytic converter inspection, gasket replacement

Wheels And Tires:

Tire pressure, tire replacement, wheel balancing, wheel bearing service

Bodywork And Trim:

Fairing removal and installation, seat service, luggage system components

Maintenance:

Scheduled maintenance, oil changes, filter replacements, brake checks, chain adjustment (if applicable), valve clearance checks

Troubleshooting:

Diagnostic procedures for all major systems, common fault diagnosis

Repair:

Step-by-step repair instructions for all components and systems, including full engine rebuilds

Disassembly And Assembly:

Detailed instructions for removing and reinstalling all parts and sub-assemblies

Wiring Diagrams:

Comprehensive electrical schematics for all circuits

Technical Specifications:

Torque values, measurements, clearances, fluid capacities, electrical specifications

Depth Of Coverage:

Professional-grade, comprehensive coverage suitable for factory-trained technicians and experienced DIY mechanics

Visual Aids:

Hundreds of detailed photos, illustrations, and exploded diagrams

📊 Manual Specifications

File Type:

PDF

Searchability:

Likely text-searchable (common for professional PDFs)

Print Capability:

Printable by the user (single pages or entire manual)

Binding:

Not Applicable (Digital Download)

Paper Quality:

Not Applicable (Digital Download)

⚙️ Engine Specifications

Engine Type:

Liquid-cooled, V-4

Displacement:

1261 cc (76.9 cu in)

Bore X Stroke:

81 mm x 62 mm

Valve Train:

2 valves per cylinder, SOHC (Single Overhead Camshaft)

Horsepower Est:

Approx. 83 hp @ 6000 rpm (typical for this engine configuration)

Torque Est:

Approx. 77 lb-ft @ 4500 rpm (typical for this engine configuration)

Fuel Delivery:

PGM-FI (Programmed Fuel Injection)

Fuel Type:

Unleaded gasoline, 87 octane or higher

Cooling Method:

Liquid-cooled

Starter System:

Electric

🔧 Transmission

Transmission Type:

5-speed manual

Drive Type:

Shaft drive

Clutch Type:

Wet, multi-plate

Gear Oil Type:

API GL-4, SAE 80 or 85W hypoid gear oil (Honda recommends specific type, check manual for exact part number)

📐 Dimensions

Length:

Approx. 95.9 inches (2435 mm)

Width:

Approx. 33.9 inches (860 mm)

Height:

Approx. 45.1 inches (1145 mm)

Curb Weight:

Approx. 717 lbs (325 kg)

Fuel Capacity:

Approx. 4.7 US gallons (17.8 liters)

🛡️ Safety Features

ABS:

Available on Deluxe model (Honda's Combined ABS)

Braking System:

Front: Dual 310mm discs with 3-piston calipers; Rear: 296mm disc with 3-piston caliper (all linked with ABS on Deluxe)

💡 Technology Features

Audio System:

Deluxe models feature an integrated audio system with handlebar-mounted controls, allowing for MP3 playback via an auxiliary input or USB connection.

ABS System:

Available Combined Anti-lock Braking System (C-ABS) for enhanced braking control.

Usb Port:

Integrated USB charging port for electronic devices (Deluxe model).

🔧 Maintenance

Engine Oil Change:

Every 8,000 miles (12,000 km) or 12 months, whichever comes first. Refer to manual for specific oil type and filter part number (e.g., Honda 15410-MFJ-001 or similar).

Drive Shaft Oil Change:

Every 16,000 miles (24,000 km) or 24 months. Refer to manual for specific lubricant (e.g., Honda GL-4 80W).

Spark Plug Replacement:

Typically at 16,000 miles (24,000 km) or as per manual recommendations (e.g., NGK CR9EH-9).

Air Filter Cleaning Replacement:

Inspect every 8,000 miles, clean/replace as needed. Refer to manual for part number.

Engine Oil Type:

Honda GN4 10W-30 or SAE 10W-40 API SG or higher motorcycle oil.

Brake Fluid Type:

Honda DOT 4 Ultra High Performance Brake Fluid.

Coolant Type:

Honda High Performance Coolant (50/50 mix of antifreeze and distilled water).

Common Problems:

While generally reliable, some owners report potential issues with the ABS system's sensitivity, occasional electrical gremlins, and normal wear and tear on suspension components due to its touring nature. The manual addresses these and provides diagnostic steps.
