Description

🏷️ Basic Information

Identification

Make:

Honda

Model:

Pilot

Year:

Codes

Chassis Code:

Engine Code:

J35Z4 (3.5L V6)

👋 Introduction

Market Position

Vehicle Segment:

Mid-size Crossover SUV

Target Audience:

Families, individuals seeking practical and reliable transportation

Competitive Analysis

Key Competitors:

Toyota Highlander, Ford Explorer, Chevrolet Traverse, Nissan Pathfinder

Key Features

Manual Advantage:

Licensed OE material from RepairSurge, accessible online, user-friendly interface

Vehicle Key Selling Points:

Spacious interior, V6 power, available AWD, comfortable ride, Honda reliability

📋 Manual Details

Coverage Areas

Primary Coverage:

Complete service and repair for the 2010 Honda Pilot

Secondary Coverage:

Maintenance, troubleshooting, diagnostics, wiring diagrams, component replacement, specifications

Page Count

Estimated Page Count:

Extensive (Digital format, equivalent to thousands of printed pages)

Manual Type

Type:

Online Service and Repair Manual Software

Language

Language:

English

Format

Format:

Web-based/Online Access

Access Duration:

1 Year (with discounts for extensions)

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Engine assembly, cylinder head, piston, crankshaft, camshafts, timing, lubrication, cooling

Engine Performance:

Fuel injection, ignition system, emission control, engine management

Transmission:

Automatic transmission (5-speed), removal, installation, internal components, fluid service

Drivetrain:

Front-wheel drive, all-wheel drive (VTM-4), drive shafts, differentials, axles

Suspension:

Front suspension (MacPherson strut), rear suspension (Multi-link beam), springs, shock absorbers, control arms

Steering:

Power steering system, steering rack, column, alignment specifications

Brakes:

Front disc brakes, rear disc brakes, ABS, VSA, parking brake, hydraulic system

Electrical System:

Battery, charging system, starter motor, lighting, horn, power accessories

Body Electrical:

Power windows, door locks, mirrors, sunroof, interior/exterior lighting

HVAC:

Air conditioning system, heater, ventilation, climate control

Body And Frame:

Body panels, doors, hood, tailgate, chassis structure, glass, seals

Restraint Systems:

Airbags, seat belts, SRS system diagnostics

Wiring Diagrams:

Comprehensive electrical schematics for all systems

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, fluid checks, tire rotation, wiper blade replacement

Diagnostic Procedures:

Troubleshooting guides for common and complex issues, DTC (Diagnostic Trouble Code) interpretation

Repair Procedures:

Step-by-step instructions for component removal, replacement, and repair

Overhaul Procedures:

Detailed instructions for engine and transmission overhauls

Alignment Procedures:

Wheel alignment specifications and procedures

Electrical Troubleshooting:

Schematic interpretation, testing of electrical circuits and components

Technical Depth

Depth:

Factory-level diagnostic and repair procedures

Scope:

Covers all aspects from basic maintenance to complete engine rebuilds and complex electrical diagnostics

📊 Manual Specifications

File Format

Primary Format:

Web-based (HTML/JavaScript)

Compatibility:

PC, Laptop, Smartphone, Tablet via Web Browser

Print Quality

Print Option:

Printable pages (user-dependent)

Binding Type

Binding Type:

N/A (Digital)

Paper Type

Paper Type:

N/A (Digital)

⚙️ Engine Specifications

Primary Engine

Engine Type:

3.5L SOHC V6 i-VTEC

Displacement:

3471 cc (211.8 cu in)

Bore X Stroke:

93.0 mm x 86.0 mm (3.66 in x 3.39 in)

Performance

Horsepower:

250 hp @ 5700 rpm

Torque:

248 lb-ft @ 4800 rpm

Compression Ratio:

10.0:1

Fuel System

Fuel Delivery:

Programmed Fuel Injection (PGM-FI)

Recommended Fuel:

87 Octane Unleaded Gasoline

Fluid Specifications

Engine Oil Type:

SAE 0W-20 API Certified

Engine Oil Capacity:

4.5 US qt (4.3 L) with filter change

Coolant Type:

Honda Long Life Antifreeze/Coolant (Type 2)

🔧 Transmission

Standard

Type:

5-speed Automatic with Sequential SportShift

Optional

Drive Type:

Available with Front-Wheel Drive (FWD) or Variable Torque Management 4-Wheel Drive (VTM-4)

Features

Transmission Fluid Type:

Honda Genuine ATF DW-1

Transmission Fluid Capacity:

3.7 US qt (3.5 L) for fluid change

📐 Dimensions

Exterior

Length:

191.4 inches (4862 mm)

Width:

78.5 inches (1994 mm)

Height:

70.7 inches (1796 mm)

Wheelbase:

106.3 inches (2700 mm)

Ground Clearance:

7.9 inches (201 mm)

Cargo

Cargo Volume Behind 3Rd Row:

10.5 cu ft (297 L)

Cargo Volume Behind 2Nd Row:

40.5 cu ft (1147 L)

Cargo Volume Behind 1St Row:

87.6 cu ft (2480 L)

Weights

Curb Weight FWD:

4,409 lbs (2,000 kg)

Curb Weight AWD:

4,575 lbs (2,075 kg)

Gross Vehicle Weight Rating Gvwr:

6,000 lbs (2,722 kg) for AWD

Towing Capacity:

Up to 5,000 lbs (2,268 kg) when properly equipped

🛡️ Safety Features

Ratings

NHTSA Rollover Rating:

4/5 stars (FWD & AWD)

IIHS Front Crash Rating:

IIHS Side Impact Rating:

IIHS Roof Strength Rating:

Active Features

Vehicle Stability Assist Vsa:

Standard on all models

Antilock Braking System ABS:

Standard with Electronic Brake-force Distribution (EBD) and Brake Assist

Tire Pressure Monitoring System Tpms:

Standard

Passive Features

Airbags:

Dual-stage front airbags, front side airbags, side curtain airbags with rollover sensor

Seat Belts:

3-point seat belts with pretensioners for all seating positions, LATCH child seat anchors

💡 Technology Features

Infotainment

Audio System:

Available premium audio system with subwoofer, auxiliary audio input jack, USB audio interface, Bluetooth HandsFreeLink.

Navigation System:

Optional Honda Satellite-Linked Navigation System with voice recognition.

Driver Assistance

Rearview Camera:

Standard on most trims, aids in reversing and parking.

Parking Sensors:

Available rear parking sensors.

Connectivity

Connectivity Features:

Bluetooth streaming audio, hands-free calling, steering wheel-mounted audio and cruise controls.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 to 10,000 miles (12,000 to 16,000 km) or as indicated by the Maintenance Minder System

Transmission Fluid Change:

Recommended every 60,000 miles (96,000 km) or as per Maintenance Minder. VTM-4 fluid change every 30,000 miles (48,000 km) under severe use.

Engine Air Filter:

Replace every 30,000 miles (48,000 km) or as indicated by Maintenance Minder.

Cabin Air Filter:

Replace every 15,000 miles (24,000 km) or as indicated by Maintenance Minder.

Spark Plugs:

Iridium-tipped spark plugs, replace at 100,000 miles (160,000 km).

Fluid Specifications

Power Steering Fluid:

Honda Genuine Power Steering Fluid

Brake Fluid:

DOT 3 Honda Genuine Brake Fluid

Known Issues

Common Complaint 1:

Transmission shudder or rough shifting, particularly in earlier models of the second generation. Maintenance and fluid changes are critical.

Common Complaint 2:

Excessive oil consumption in some V6 engines, especially if not regularly maintained. Addresses via specific engine checks and potential oil control ring updates.

Common Complaint 3:

Rear suspension noise or clunking, sometimes related to worn bushings or shock absorbers.

Common Complaint 4:

Air conditioning system performance issues, potentially related to refrigerant leaks or compressor faults.

📚 Vehicle History

Brand Heritage

Honda Reputation:

Known for reliability, fuel efficiency, and engineering quality in passenger cars and SUVs.

Model Evolution

Generation:

Second Generation (2009-2015)

Previous Generation Design:

First generation (2003-2008) was based on the Honda Odyssey minivan platform, featuring a more truck-like unibody design.

Second Generation Changes:

Redesigned chassis for improved ride and handling, enhanced VTM-4 system, updated styling, and more fuel-efficient V6 engine.

Production

Manufacturing Location:

Lincoln, Alabama, USA

🏆 Awards & Recognition

Recognitions

Safety Award 1:

IIHS Top Safety Pick (multiple years, including 2010)

Family Vehicle Award:

Often cited by automotive publications for its family-friendly features and practicality.
