Honda TRX250TE/TRX250TM Fourtrax Recon ATV Service Repair Manual 1997-2004

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

This manual covers the Fourtrax Recon models TRX250TE (ES) and TRX250TM from 1997 through 2004. Engineered for both utility and recreational use, the Fourtrax Recon is renowned for its robust...

18 people are viewing this right now

类型: Atv

斯库: 104894

标签: 1997 1998 1999 2000 2001 2002 2003 2004 ATV Honda Powersports Recon Series TRX250TE Fourtrax Recon TRX250TM Fourtrax Recon

产品多属性

Description

This manual covers the Fourtrax Recon models TRX250TE (ES) and TRX250TM from 1997 through 2004. Engineered for both utility and recreational use, the Fourtrax Recon is renowned for its robust 249cc liquid-cooled engine, reliable shaft drive, and user-friendly operation, featuring either a 5-speed manual transmission with automatic clutch or an Electric Shift Program (ESP) on TE models. The legacy of quality and durability is evident in this versatile ATV, designed to provide dependable performance across a range of tasks and terrains. This comprehensive Service Repair Manual provides detailed instructions for the maintenance, repair, and overhaul of your Fourtrax Recon. It includes in-depth coverage of all major systems, including the powertrain, chassis, brakes, and electrical components, with specific sections dedicated to the Electric Shift Program (ESP) for TE models. Within its 360 pages, you will find scheduled maintenance procedures, step-by-step repair and rebuild instructions, systematic troubleshooting guides, and essential technical specifications such as torque values and fluid capacities. This manual is an indispensable resource for owners and technicians seeking to maintain the peak performance and longevity of their vehicle.

🏷️ Basic Information

Identification

Make:

Honda

Model:

Fourtrax Recon

Model Designation:

TRX250TE (ES) / TRX250TM

Model Years Covered:

1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004

Codes

Chassis Code Series:

First Generation (TRX250TE/TRX250TM)

👋 Introduction

Market Position

Positioning:

Essential resource for owners and technicians of the Honda TRX250 Fourtrax Recon series, offering complete repair and maintenance guidance for an extended production run.

Competitive Analysis

Analogy:

This manual serves as the definitive technical bible for the TRX250 Recon, akin to a factory service manual, providing the same level of detail and accuracy.

Key Features

Features:

Instant download, comprehensive coverage, detailed illustrations, diagrams, wiring schematics, troubleshooting, and extensive specifications.

📋 Manual Details

Coverage Areas

Covered Models:

Honda TRX250TM Fourtrax Recon, Honda TRX250TE Fourtrax Recon ES

Page Count

Total Pages:

Manual Type

Type:

Service Repair Manual

Language

Language:

English

Format

File Format:

📖 Manual Coverage

Systems Covered

Powertrain:

Engine (top end, bottom end), Clutch, Transmission, Drivetrain (rear drive mechanism)

Chassis & Body:

Frame, Body Panels, Exhaust System, Front Suspension, Rear Suspension, Steering System

Brakes:

Brake System (Front and Rear)

Electrical:

Battery, Charging System (Alternator, Starter Clutch), Ignition System, Electric Starter, Lights, Switches, Wiring Diagrams, Electric Shift Program (TRX250TE models after 2001)

Fuel & Lubrication:

Fuel System, Lubrication System

Procedures Included

Maintenance:

Scheduled maintenance, Fluid changes, Filter replacements, Lubrication

Repair Rebuild:

Complete teardown and rebuild procedures, Engine component overhauls (cylinder head, piston, crankshaft), Transmission rebuild, Suspension component repair, Brake system servicing

Diagnostics Troubleshooting:

Systematic troubleshooting guides, Common issue diagnosis and solutions

Specifications:

Torque specifications, Clearance measurements, Fluid capacities, Electrical specifications

Restoration:

Guidance for refurbishing and restoring the ATV to its original condition.

Technical Depth

Depth:

Comprehensive from basic maintenance to complete engine and transmission overhauls, suitable for both DIY enthusiasts and professional mechanics.

📊 Manual Specifications

File Format

Compatibility:

All versions of Windows, Mac, Linux OS, iPhone, iPad, Android.

Features:

Searchable text, Bookmarked for easy navigation.

Printability:

Printable pages.

Print Quality

Quality:

High-quality digital reproduction with clear illustrations and diagrams.

Binding Type

Type:

Digital Download (PDF)

Paper Type

Type:

N/A (Digital)

⚙️ Engine Specifications

Primary Engine

Engine Type:

249cc Liquid-Cooled OHC Single-Cylinder Four-Stroke

Performance

Bore X Stroke:

Approximately 68.5 mm x 68.5 mm (typical for this class)

Compression Ratio:

Approximately 9.2:1 (typical for this model range)

Horsepower Estimated:

Around 18-20 HP (manufacturer specifications may vary slightly by year)

Fuel System

Fuel Delivery:

Carburetor (specific model: Keihin or similar, likely constant velocity)

Fuel Type:

Unleaded Gasoline

Carburetor Details:

Specific model and jetting information detailed within the manual.

Lubrication System

Oil Type Recommendation:

SAE 10W-40 API SG or higher (refer to manual for specific Honda recommendations)

Oil Capacity:

Approximately 1.7 L (1.8 US qt) with filter change (verify in manual)

🔧 Transmission

Standard

Transmission Type:

5-speed manual with automatic clutch (TRX250TM) or 5-speed manual with electric shift program (ESP) and automatic clutch (TRX250TE)

Optional

Transmission Features:

Reverse gear

Features

Clutch Type:

Wet multi-plate automatic clutch

Final Drive:

Shaft drive with enclosed oil bath

Fluid Type

Transmission Oil:

SAE 80 hypoid gear oil (verify in manual for specific viscosity)

📐 Dimensions

Exterior

Length:

Approximately 1845 mm (72.6 in)

Width:

Approximately 1055 mm (41.5 in)

Height:

Approximately 1050 mm (41.3 in)

Weights

Dry Weight:

Approximately 209 kg (460 lbs)

Curb Weight:

Approximately 217 kg (478 lbs) (TRX250TE ES)

Wheelbase

Wheelbase:

Approximately 1200 mm (47.2 in)

Ground Clearance

Ground Clearance:

Approximately 165 mm (6.5 in)

🛡️ Safety Features

Ratings

Atv Safety Standards:

Designed to meet applicable industry safety standards for ATVs.

Active Features

Braking System:

Hydraulic disc brakes front and rear, mechanical drum rear brake (TRX250TM), or hydraulic disc front and rear (TRX250TE).

Lighting:

Headlights, taillight/brake light.

Passive Features

Ergonomics:

Thumb throttle, handlebar controls designed for intuitive operation.

Chassis Design:

Low center of gravity for stability.

💡 Technology Features

Infotainment

Features:

N/A (ATV technology focused on functionality and durability).

Driver Assistance

Features:

Electric Shift Program (ESP) on TE models allows for handlebar button shifting.

Connectivity

Features:

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 1000 km or 6 months (refer to manual for exact interval).

Air Filter Cleaning:

As needed, or every 6 months.

Spark Plug Check:

Every 4000 km or 2 years.

Fluid Specifications

Coolant Type:

Honda HP Coolant or equivalent, 50/50 mixture with distilled water.

Brake Fluid:

DOT 4 brake fluid.

Known Issues

Common Wear Items:

Brake pads, tires, drive chain/shaft components (if applicable depending on exact model variant), electrical switchgear contacts.

Potential Issues:

Water pump seal leaks, starter solenoid issues, carburetor gumming if not run regularly.

📚 Vehicle History

Brand Heritage

Heritage:

Honda's long-standing reputation for reliability and quality in powersports vehicles.

Model Evolution

Recon Lineage:

The TRX250 Recon, introduced in 1996, evolved into the TRX250TE/TM for this generation, offering a balance of utility and recreational capability with a focus on user-friendliness.

Production

Production Period:

1997-2004

Manufacturing:

Manufactured by Honda Motor Co., Ltd.

🏆 Awards & Recognition

Recognitions

Reputation:

The Honda Recon series is widely recognized for its reliability, ease of use, and strong resale value within the utility ATV market.
