Description

🏷️ Basic Information

Identification

Make:

Hummer

Model:

Year:

Codes

Platform:

GMT355

👋 Introduction

Market Position

Segment:

Compact SUV with robust off-road capabilities.

Competitive Analysis

Competitors:

Jeep Wrangler, Toyota FJ Cruiser, Nissan Xterra, Ford Bronco (older models, but similar market appeal).

Key Features

Distinctive Attributes:

Unique Hummer styling, exceptional off-road prowess, robust chassis, powerful inline-5 engine.

Manual Value Proposition

Convenience:

Online, instant access format provides unparalleled convenience over traditional printed manuals, with a one-year subscription.

Accuracy:

Officially licensed and derived from OE (Original Equipment) materials, ensuring high accuracy.

📋 Manual Details

Coverage Areas

Coverage Type:

Comprehensive Service and Repair

Page Count

Estimated Pages:

Thousands (digital format, extensive)

Manual Type

Type:

Software / Online Service Manual

Language

Language:

English

Format

Format:

Online Access (Web Browser)

📖 Manual Coverage

Systems Covered

Engine Systems:

Engine mechanical, lubrication, cooling, fuel, ignition, emissions, starting, charging, engine control module (ECM) diagnostics and repair.

Drivetrain Systems:

Manual and automatic transmission (NV1500, NV3550, 4L60-E), transfer case (2-speed electronically controlled), drive shafts, axle assemblies (front and rear), wheel bearings.

Suspension Steering:

Front independent torsion bar suspension, rear solid axle leaf spring suspension, steering gear, power steering system, steering linkage.

Brake Systems:

Front and rear disc brakes, hydraulic system, ABS (Anti-lock Braking System), parking brake system.

Electrical Systems:

Wiring diagrams, lighting systems, instrument cluster, power windows, locks, mirrors, horn, audio systems, charging system, starter system, body control module (BCM).

Body Chassis:

Body panels, doors, hood, tailgate, bumpers, chassis components, frame inspection and repair, interior trim, seating systems.

HVAC Systems:

Heating, Ventilation, and Air Conditioning (HVAC) system components, refrigerant handling, diagnostics and repair.

Procedures Included

Maintenance Procedures:

Oil change, filter replacement, fluid level checks and top-offs, tire rotation, brake inspection, battery service, air filter replacement.

Diagnostic Procedures:

Troubleshooting guides for common and intermittent problems, diagnostic trouble codes (DTCs), sensor testing, circuit testing.

Repair Procedures:

Step-by-step instructions for engine component replacement, transmission overhaul, brake caliper replacement, suspension component replacement, electrical component repair.

Special Procedures:

Engine timing adjustments, clutch replacement, torque converter replacement, axle seal replacement, driveline service, airbag system service (with safety precautions).

Technical Depth

Depth:

Factory-level detailed service information, including schematics, component testing, specifications, and torque values for complete repair and diagnosis.

📊 Manual Specifications

File Format

Digital Format:

Web-based platform; accessible via any modern web browser on PC, laptop, smartphone, or tablet.

Print Quality

Printable Pages:

Content is designed to be viewed and printed as needed, ensuring clarity.

Binding Type

Binding:

N/A (Digital Online Access)

Paper Type

Paper Quality:

N/A (Digital Online Access)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Inline 5-Cylinder, DOHC

Displacement:

3.7 Liters (3700 cc)

Bore X Stroke:

95.5 mm x 97.7 mm

Compression Ratio:

9.8:1

Performance

Horsepower:

242 hp @ 5600 rpm

Torque:

242 lb-ft @ 3600 rpm

Fuel System

Fuel Delivery:

Sequential Fuel Injection (SFI)

Fuel Type:

Unleaded Gasoline (87 octane recommended)

Lubrication

Oil Capacity:

5.5 quarts (5.2 L) with filter, SAE 5W-30

Cooling

Coolant Capacity:

14.5 quarts (13.7 L) - Dex-Cool (Orange) Extended Life Coolant

🔧 Transmission

Standard

Transmission Type:

5-speed Manual Transmission (NV3550)

Optional

Transmission Type:

4-speed Automatic Transmission (4L60-E)

Features

Transfer Case:

2-speed electronically controlled with Neutral, 4WD High, 4WD Low options.

Fluid Specs

Automatic Transmission Fluid:

Dexron VI

Manual Transmission Fluid:

GM Synchromesh Transmission Fluid (or equivalent DEXRON-III H)

Fluid Capacity

Automatic Transmission Capacity:

7.4 quarts (7.0 L) (Dry fill)

📐 Dimensions

Exterior

Length:

183.9 inches (4671 mm)

Width:

81.2 inches (2063 mm)

Height:

77.3 inches (1963 mm)

Wheelbase:

113.0 inches (2870 mm)

Weights

Curb Weight:

Approx. 4,700 - 5,000 lbs (2132 - 2268 kg) depending on configuration

Towing Capacity:

Up to 6,000 lbs (2721 kg)

Dimensions

Ground Clearance:

9.1 inches (231 mm)

Approach Angle:

46.7 degrees

Departure Angle:

39.8 degrees

Breakover Angle:

26.5 degrees

🛡️ Safety Features

Ratings

NHTSA Front Driver Side Impact:

5 Stars

NHTSA Front Passenger Side Impact:

5 Stars

IIHS Moderate Overlap Frontal Offset:

IIHS Side Impact:

Active Features

Standard

Traction Control:

Standard

Electronic Stability Control:

Optional

Passive Features

Airbags:

Driver and front passenger airbags, front seat-mounted side-impact airbags (optional).

Seat Belts:

Three-point seat belts with pretensioners in all seating positions.

💡 Technology Features

Infotainment

Audio System:

Available AM/FM/CD/MP3 player with optional Bose premium audio system, SiriusXM Satellite Radio.

Navigation:

Optional factory-installed navigation system.

Driver Assistance

Rear Parking Assist:

Optional

Connectivity

Bluetooth:

Optional Bluetooth for hands-free calling.

Other Features

Remote Start:

Optional

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 miles (12,000 km) or 12 months, whichever comes first, under normal driving conditions. Consult manual for severe conditions.

Tire Rotation Interval:

Every 7,500 miles (12,000 km)

Engine Air Filter Replacement:

Every 45,000 miles (72,000 km) or as needed based on inspection.

Cabin Air Filter Replacement:

Every 30,000 miles (48,000 km) or annually.

Transmission Fluid Change Automatic:

Inspect every 30,000 miles (48,000 km), replace as recommended by dealer or based on severe usage (e.g., towing, off-roading).

Fluid Specifications

Engine Oil Specification:

SAE 5W-30, API SN or higher, Dexos approved.

Coolant Specification:

Dex-Cool (Orange) Extended Life Coolant (50/50 mix with distilled water).

Brake Fluid Specification:

DOT 3

Power Steering Fluid:

GM Power Steering Fluid or Dexron III H

Known Issues

Common Complaints:

Fuel pump failures, alternator issues, exhaust manifold cracks, interior trim rattles, front differential pinion seal leaks, potential for ABS sensor failures.

Maintenance Tips:

Regularly inspect for oil and coolant leaks, especially around the engine and differential. Ensure proper lubrication of suspension components, especially if used off-road.

📚 Vehicle History

Brand Heritage

Brand Legacy:

Hummer brand originated from AM General's High Mobility Multipurpose Wheeled Vehicle (HMMWV or Humvee).

Model Evolution

Generation:

First Generation H3 (2006-2010)

Updates For 2009:

While significant mechanical changes were minimal for 2009 compared to earlier years, the model continued to offer its established features and ruggedness. Minor trim and option package adjustments may have occurred.

Production

Manufacturing Location:

Shreveport, Louisiana, USA (GM's Shreveport Operations)

Production Years:

2006-2010

🏆 Awards & Recognition

Recognitions

Off Road Capability Awards:

Often praised by off-road publications and enthusiasts for its capability in its class.

Ratings

Kelley Blue Book Value:

While not an award, KBB and similar guides provide valuation data, indicating market acceptance.
