Segment:
Compact Crossover SUV
Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Nissan Xterra (early competitors).
Value Proposition:
Provides licensed, OE-quality repair information accessible digitally, offering a significant advantage over outdated printed manuals in terms of cost and convenience.
Manual Type:
Service and Repair Manual Software
Renewal Option:
Yes, discounts available
Delivery Method:
Online Access
Device Compatibility:
PC, Laptop, Smartphone, Tablet
Requirement:
Internet Connection and Web Browser
Licensing:
Officially Licensed, OE (Original Equipment) Material Derived
Engine:
Engine mechanical, engine performance, engine management, fuel system, cooling system, lubrication system, exhaust system, emission control systems.
Drivetrain:
Automatic transmission, manual transmission, clutch, drive shafts, axles, differentials, all-wheel drive (AWD) system.
Suspension:
Front suspension, rear suspension, shock absorbers, struts, springs, control arms, bushings, wheel alignment.
Steering:
Power steering system, steering column, steering gear, tie rods, power steering fluid.
Brakes:
Front brakes (disc), rear brakes (disc/drum depending on configuration), anti-lock braking system (ABS), brake hydraulics, parking brake.
Electrical:
Battery, charging system (alternator), starting system (starter motor), ignition system, lighting system, fuses, relays, wiring diagrams.
HVAC:
Heating system, ventilation system, air conditioning (A/C) system, refrigerant, climate control.
Body:
Body panels, doors, hood, tailgate, glass, interior trim, exterior trim, bumpers.
Chassis:
Frame, subframes, mounting points.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks and top-offs, tire rotation.
Repair:
Component replacement, system diagnostics and repair, troubleshooting guides.
Diagnostics:
Troubleshooting common problems, diagnostic trouble codes (DTCs) interpretation (likely requires separate scan tool reference, but manual guides symptom analysis).
Depth:
Comprehensive: Covers everything from basic maintenance to detailed component-level repair and diagnostics.
Engine Code:
G4GC (Beta II)
Engine Type:
2.0L Inline 4-Cylinder DOHC
Horsepower Est:
139 hp @ 6000 rpm
Torque Est:
134 lb-ft @ 4500 rpm
Fuel Delivery:
Electronic Multi-Point Fuel Injection (MPI)
Recommended Fuel:
87 Octane Unleaded Gasoline
Emissions Standard:
Likely LEV (Low Emission Vehicle) or ULEV (Ultra Low Emission Vehicle) depending on market.
Oil Capacity:
Approximately 4.0 quarts (3.8 liters) with filter change (verify specific engine variant).
Spark Plug Type:
NGK BKR5FS-11 (standard) or Iridium equivalent (verify).
Timing Belt Or Chain:
Timing Chain (G4GC engine uses a chain, not a belt).
Transmission Type Std:
5-Speed Manual Transmission
Transmission Type Opt:
4-Speed Automatic Transmission
AWD System:
Available All-Wheel Drive (AWD) system with viscous coupling.
Automatic Transmission Fluid Type:
SP-III (DEXRON III compatible versions may be suitable, but SP-III is preferred for Hyundai).
Manual Transmission Fluid Type:
GL-4 (75W-85 or 75W-90 viscosity) (verify specific fill).
NHTSA Front Crash Rating Est:
5 Stars (for driver and passenger in frontal impact, likely for certain configurations).
NHTSA Side Crash Rating Est:
4 Stars (for front and rear passengers in side impact, likely for certain configurations).
IIHS Frontal Offset Rating Est:
Good (for this generation of vehicle).
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Likely available or standard on higher trims (check specific vehicle).
Airbags Std:
Front dual airbags (driver and passenger).
Airbags Opt:
Side-impact airbags and side curtain airbags may be optional or standard on higher trims.
Seatbelts:
3-point seatbelts with pretensioners for all occupants.
Oil Change Interval:
Every 7,500 miles (12,000 km) or 6 months, whichever comes first (under normal driving conditions, severe driving may require shorter intervals).
Air Filter Replacement:
Inspect every 15,000 miles (24,000 km), replace as needed or every 30,000 miles (48,000 km).
Cabin Air Filter Replacement:
Inspect every 15,000 miles (24,000 km), replace as needed or every 15,000-30,000 miles (24,000-48,000 km).
Transmission Fluid Change Interval Auto:
Inspect every 30,000 miles (48,000 km), replace based on driving conditions (often recommended around 60,000-100,000 miles, but severe use may warrant earlier changes).
Transmission Fluid Change Interval Manual:
Inspect at 60,000 miles (96,000 km), replace if necessary.
Coolant Replacement:
Initial replacement at 105,000 miles (169,000 km), then every 50,000 miles (80,000 km) thereafter.
Engine Oil Spec:
API SM or higher, SAE 5W-20 (or 5W-30 depending on climate, refer to owner's manual for specific viscosity).
Common Concern 1:
Potential for ABS sensor failures leading to ABS warning lights.
Common Concern 2:
Water pump leaks or premature failure on some models.
Common Concern 3:
CV joint wear, particularly in vehicles driven in harsh conditions or with off-road use.
Common Concern 4:
Power steering pump noise or leaks.
Common Concern 5:
Early versions of the automatic transmission may exhibit less refined shifting.
