Positioning:
Compact Crossover SUV
Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Kia Sportage
Design Philosophy:
Fluidic Sculpture design language
Licensing:
Officially licensed, derived from OE (Original Equipment) materials by RepairSurge
Access Duration:
1 Year of access, with discounts for extended access
Primary Coverage:
Factory Service and Repair Information
Scope:
Comprehensive diagnostics, repair, maintenance, and specifications
Estimated Pages:
Thousands (Digital Format)
Type:
Service and Repair Manual (Software)
Format:
Online Digital Access (Web Browser Based)
Powertrain:
Engine mechanical, engine management, fuel system, cooling system, exhaust system, drivetrain (FWD/AWD), transmission (automatic/manual)
Chassis:
Suspension, steering, brakes (hydraulic, ABS, ESC), wheels, tires
Electrical:
Body electrical systems, lighting, power accessories, instrument cluster, diagnostic connectors, wiring diagrams
HVAC:
Heating, ventilation, and air conditioning (HVAC) system
Body And Interior:
Body panels, doors, windows, seats, interior trim, airbags
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, inspections
Repair:
Component removal and installation, system diagnosis and repair, troubleshooting guides
Diagnostics:
OBD-II diagnostics, diagnostic trouble code (DTC) interpretation, symptom-based troubleshooting
Specifications:
Torque specifications, clearances, fluid capacities, electrical specifications
Depth:
Factory-level detail, covering basic maintenance to complex component overhaul and electronic system diagnosis
Engine Code Gasoline 2.4L:
Theta II G4KC
Engine Type 2.4L:
2.4L Inline-4 DOHC MPI
Engine Displacement 2.4L:
2359 cc (143.9 cu in)
Horsepower 2.4L:
176 hp @ 6000 rpm (approx.)
Torque 2.4L:
169 lb-ft @ 4000 rpm (approx.)
Engine Code Gasoline 2.0L:
Theta II G4KD
Engine Type 2.0L:
2.0L Inline-4 DOHC MPI
Engine Displacement 2.0L:
1998 cc (121.9 cu in)
Horsepower 2.0L:
164 hp @ 6200 rpm (approx.)
Torque 2.0L:
147 lb-ft @ 4600 rpm (approx.)
Compression Ratio 2.4L:
10.5:1
Bore X Stroke 2.4L:
88.0 mm x 97.0 mm
Fuel Delivery:
Multi-Point Fuel Injection (MPI)
Recommended Fuel:
87 Octane Unleaded Gasoline
ECU:
ECM (Engine Control Module) with CAN bus communication
Standard Transmission:
6-Speed Automatic (Optional on 2.0L, Standard on 2.4L)
Optional Transmission:
6-Speed Manual (Available on select 2.0L models)
Automatic Features:
Shiftronic manual mode, adaptive learning control
Automatic Transmission Fluid Type:
Hyundai SPII ATF (or equivalent) - Refer to manual for specific part number
Automatic Gear Ratios:
Refer to manual for detailed ratios by model/engine
NHTSA Overall Rating:
4 out of 5 stars (for AWD models tested in 2013)
IIHS Top Safety Pick:
Yes (for models built after a certain date in 2012/2013)
Active Safety Systems:
Electronic Stability Control (ESC), Traction Control System (TCS), Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA)
Passive Safety Features:
Advanced front airbags, front-seat side-impact airbags, roof-side curtain airbags (front and rear), active front head restraints
Infotainment Options:
Available touchscreen infotainment system with navigation, Bluetooth, USB/Aux inputs
Driver Assistance Features:
Optional rearview camera, parking assist sensors
Connectivity Features:
Bluetooth hands-free calling and audio streaming
Oil Change Interval:
7,500 miles (12,000 km) or 6 months, whichever comes first (under normal driving conditions)
Tire Rotation Interval:
7,500 miles (12,000 km)
Engine Air Filter Replacement:
Every 30,000 miles (48,000 km) or as needed
Cabin Air Filter Replacement:
Every 15,000 miles (24,000 km) or as needed
Spark Plug Replacement 2.4L:
100,000 miles (160,000 km) with Iridium-tipped plugs
Engine Oil Type 2.4L:
SAE 0W-20 Synthetic
Engine Oil Capacity 2.4L:
4.8 US quarts (4.5 liters) with filter change
Coolant Type:
Hyundai Long Life Coolant (Blue) - Ethylene Glycol Based
Coolant Capacity:
Approx. 7.7 US quarts (7.3 liters)
Brake Fluid Type:
DOT 3 or DOT 4
Common Complaint 1:
Potential for oil consumption on higher mileage 2.4L engines (check for piston ring issues)
Common Complaint 2:
CVT transmission issues (though this generation primarily uses conventional automatics, it's a general Hyundai concern to be aware of)
Common Complaint 3:
Water pump leaks (particularly on the 2.4L engine)
Common Complaint 4:
Active Eco system issues (may affect performance/fuel economy)
