Target Audience:
DIY mechanics, automotive repair shops, and Hyundai owners seeking comprehensive repair guidance.
Advantage Over Printed:
Instant access, updated content potential, searchability, and convenience compared to traditional printed manuals.
Licensing:
Officially licensed, derived from OE (Original Equipment) materials, ensuring accuracy and authenticity.
Cost Savings:
Enables significant cost savings by empowering owners to perform repairs themselves.
General Coverage:
Comprehensive service and repair information for the 2004 Hyundai XG350.
Specific Systems:
Engine, Drivetrain, Transmission, Brakes, Suspension, Steering, Electrical System, HVAC, Body, Chassis.
Estimated Page Count:
Extensive (digital format, equivalent to hundreds of printed pages).
Type:
Service and Repair Manual
Format:
Online Software/Web-based Access
Access Duration:
1 Year (with discounts for renewal)
Device Compatibility:
PC, Laptop, Smartphone, Tablet (requires internet connection and web browser)
Engine Mechanical:
Engine assembly, cylinder head, crankshaft, pistons, connecting rods, lubrication system, cooling system, timing system, valve train.
Engine Performance:
Fuel system (injectors, pump, lines), ignition system, emissions control, engine diagnostics.
Transmission:
Automatic transmission (AT) operation, maintenance, overhaul, torque converter, valve body, electronic controls.
Drivetrain:
Front-wheel drive (FWD) system, driveshafts, axles, differential.
Brakes:
Front and rear brake systems (discs), hydraulic system, ABS (Anti-lock Braking System), parking brake.
Suspension:
Front and rear suspension components (struts, control arms, springs, shocks), alignment specifications.
Steering:
Power steering system, steering column, steering gear, linkages.
Electrical:
Battery, charging system (alternator), starting system, lighting, instrumentation, power accessories, body control module (BCM).
HVAC:
Heating, Ventilation, and Air Conditioning (HVAC) system, refrigerant, climate control unit, blower motor, compressor.
Body And Chassis:
Exterior body panels, doors, hood, trunk, glass, interior trim, chassis components.
Maintenance:
Routine maintenance (oil changes, filter replacements, fluid checks), tune-ups, inspections.
Repair:
Component replacement, system diagnostics and repair, troubleshooting guides.
Diagnostics:
Diagnostic trouble codes (DTCs), fault finding, electrical circuit diagrams, troubleshooting flowcharts.
Special Tools:
Identification and usage of specialized tools required for specific repair procedures.
Technical Specifications:
Torque values, clearances, fluid capacities, electrical resistance values, diagnostic parameters.
Depth:
In-depth, factory-level repair and diagnostic information suitable for professional technicians and advanced DIY enthusiasts.
Engine Type:
3.5L V6 DOHC (24-Valve)
Displacement:
3497 cc (213.4 cubic inches)
Horsepower Est:
201 hp @ 5500 rpm
Torque Est:
220 lb-ft @ 3500 rpm
Fuel Delivery:
Electronic Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline
Octane Rating Recommended:
87 Octane (Minimum)
Coolant Type Spec:
Hyundai Long Life Coolant (or equivalent ethylene glycol-based coolant with silicate inhibitors), typically blue. Capacity: Approx. 9.2 Liters (9.7 Quarts).
Engine Oil Type Spec:
API SL or higher, SAE 5W-30. Capacity: Approx. 4.7 Liters (5.0 Quarts) with filter change.
Timing Belt Or Chain:
Timing Belt
Timing Belt Replacement Interval Est:
Recommended every 60,000 - 90,000 miles or as per Hyundai's maintenance schedule for the specific model year and operating conditions.
NHTSA Front Impact Driver:
5-Star (for 2004 model year)
NHTSA Front Impact Passenger:
5-Star (for 2004 model year)
IIHS Frontal Offset:
Good (for models equipped with side airbags)
ABS:
Standard (4-wheel Anti-lock Braking System)
Traction Control:
Available (TCS)
Airbags:
Dual front airbags, available front side-impact airbags, available side curtain airbags.
Oil Change Interval:
Every 7,500 miles or 6 months, whichever comes first.
Engine Air Filter Replacement:
Every 30,000 miles or 24 months.
Cabin Air Filter Replacement:
Every 15,000 miles or 12 months.
Transmission Fluid Change:
Every 60,000 miles or 48 months, or as indicated by transmission fluid condition.
Power Steering Fluid:
Hyundai Genuine Power Steering Fluid or DEXRON III ATF.
Brake Fluid:
SAE J1703 or FMVSS 116 DOT 3.
Common Concerns:
Potential for transmission solenoid issues, HVAC blower motor failures, and early generation airbag sensor sensitivity.
