2003 Hyundai XG350 Service & Repair Manual Software

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Hyundai Model: XG350 Year: 2003 Codes Chassis Code: XG 👋 Introduction Market Position Segment: Full-size Luxury Sedan Positioning: Hyundai's premium offering, competing with established Japanese...

21 people are viewing this right now

类型: Car

斯库: 331003

标签: 2003 Car Cars Featured Grandeur Hyundai XG350

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Hyundai

Model:

XG350

Year:

Codes

Chassis Code:

👋 Introduction

Market Position

Segment:

Full-size Luxury Sedan

Positioning:

Hyundai's premium offering, competing with established Japanese and American luxury sedans.

Competitive Analysis

Competitors 2003:

Toyota Avalon, Buick Park Avenue, Ford Crown Victoria, Chevrolet Impala, Lincoln Town Car.

Key Features

Premium Appointments:

Leather seating, wood trim accents, premium audio systems, and a comfortable ride.

Value Proposition:

Offered a strong value proposition with a well-equipped interior and potent V6 engine at a competitive price point.

Manual Value

Benefit To Owner:

Empowers owners to perform maintenance and repairs, saving significant costs compared to dealership or independent shop labor.

Reliability Of Info:

Licensed OE (Original Equipment) data ensures accuracy and authenticity, mirroring factory service procedures.

📋 Manual Details

Coverage Areas

All Systems:

Page Count

Estimated Pages:

Extensive (Digital Software)

Manual Type

Type:

Service and Repair Manual Software

Language

Language:

English

Format

Format:

Online Digital Software (Web Browser Accessible)

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Complete repair, overhaul, and diagnostics for the 3.5L V6 engine.

Engine Electrical:

Detailed wiring diagrams, component testing, ECM diagnostics, and sensor data.

Fuel System:

Fuel pump, injectors, pressure regulator, EVAP system, and diagnostics.

Cooling System:

Radiator, thermostat, water pump, hoses, and fan controls.

Lubrication System:

Oil pump, oil filter, oil pan, and lubrication passages.

Ignition System:

Spark plugs, ignition coils, and timing system.

Transmission Automatic:

Complete repair, overhaul, diagnostics, fluid replacement, and electronic control for the 4-speed automatic transmission.

Drivetrain:

Front-wheel drive components, CV axles, differential, and related systems.

Suspension Front:

MacPherson struts, control arms, ball joints, bushings, and alignment.

Suspension Rear:

Multi-link suspension, shock absorbers, springs, and bushings.

Steering System:

Power steering pump, rack and pinion, steering column, and related components.

Brake System:

Front and rear disc brakes, ABS system, EBD, brake fluid, calipers, rotors, and pads.

Wheel And Tire:

Tire specifications, rotation, pressure, wheel balancing, and lug nut torque.

Exhaust System:

Manifolds, catalytic converter, mufflers, and exhaust pipes.

Body Exterior:

Doors, hood, trunk, bumpers, trim, glass, and seals.

Body Interior:

Seating, dashboard, console, door panels, headliner, and trim removal.

HVAC System:

Air conditioning, heater core, blower motor, climate controls, refrigerant, and troubleshooting.

Electrical Lighting:

Headlights, taillights, interior lights, fog lights, and bulb replacement.

Electrical Audio Visual:

Stereo system, speakers, antenna, and related wiring.

Electrical Power Accessories:

Power windows, locks, mirrors, sunroof, and wipers.

Safety Systems:

Airbags, seat belts, SRS system diagnostics, and related components.

Instrumentation:

Dashboard gauges, warning lights, and instrument cluster troubleshooting.

Diagnostics:

OBD-II diagnostics, scan tool usage, DTC interpretation, and troubleshooting flowcharts.

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, tire rotations, and battery maintenance.

Component Replacement:

Detailed guides for replacing common wear items like brakes, belts, hoses, spark plugs, and suspension parts.

Engine Overhaul:

Complete instructions for engine teardown, inspection, repair, and reassembly.

Transmission Repair:

Step-by-step guides for transmission overhaul, solenoid replacement, and fluid service.

Electrical Troubleshooting:

Diagnosing electrical faults using wiring diagrams and specialized testing procedures.

HVAC Repair:

Refrigerant handling, leak detection, compressor replacement, and climate control module diagnostics.

Suspension Alignment:

Specifications and procedures for front and rear wheel alignment.

Brake System Service:

Bleeding brakes, caliper replacement, rotor resurfacing/replacement, and ABS component testing.

Body Panel Replacement:

Instructions for removing and installing exterior body panels, doors, and trim.

Diagnostic Troubleshooting:

Systematic approaches to diagnosing and resolving vehicle issues.

Technical Depth

Depth:

Factory-level detail, suitable for professional technicians and advanced DIY enthusiasts.

Diagnostics:

In-depth diagnostic trouble codes (DTCs), live data interpretation, and specific component testing procedures.

Rebuild Procedures:

Comprehensive instructions for complete engine and transmission rebuilds.

Torque Specifications:

Detailed torque values for all critical fasteners.

Wiring Diagrams:

High-quality, comprehensive electrical wiring diagrams for all systems.

📊 Manual Specifications

File Format

Format:

Proprietary Online Software

Print Quality

Printability:

Digital format, printable sections available.

Binding Type

Binding:

N/A (Digital)

Paper Type

Paper:

N/A (Digital)

Access

Access Duration:

1 Year (with option for renewal)

Device Compatibility:

PC, Laptop, Smartphone, Tablet (via web browser)

Internet Requirement:

Required for access and functionality

⚙️ Engine Specifications

Primary Engine

Engine Code:

Engine Type:

3.5L SOHC V6

Displacement:

3497 cc (213.4 cubic inches)

Performance

Horsepower:

200 hp @ 5500 rpm

Torque:

220 lb-ft @ 3500 rpm

Fuel System

Fuel Delivery:

Multi-port Fuel Injection (MPI)

Fuel Type:

Unleaded Regular (87 Octane Recommended)

Engine Management

Engine Control Unit (ECU) with integrated transmission control.

🔧 Transmission

Standard

Transmission Type:

4-speed Automatic

Features

Transmission Modes:

Standard Drive, Manual Shift Mode (Shiftronic)

Fluid Specifications

Transmission Fluid Type:

Hyundai Genuine ATF SP-III (or equivalent)

Fluid Capacity

Transmission Fluid Capacity:

Approximately 9.8 Liters (10.4 US Quarts) for complete fill.

📐 Dimensions

Exterior

Length:

193.7 inches (4920 mm)

Width:

72.4 inches (1839 mm)

Height:

56.3 inches (1430 mm)

Wheelbase:

108.7 inches (2761 mm)

Weights

Curb Weight:

Approximately 3750 lbs (1701 kg)

Gross Vehicle Weight Rating:

Approximately 4740 lbs (2150 kg)

Cargo

Trunk Volume:

Approximately 14.5 cubic feet

🛡️ Safety Features

Ratings

NHTSA Frontal Impact Driver:

NHTSA Frontal Impact Passenger:

NHTSA Side Impact Driver:

NHTSA Side Impact Rear Passenger:

IIHS Frontal Offset:

Active Features

Standard Anti-lock Braking System (ABS)

Traction Control:

Optional Traction Control System (TCS)

Passive Features

Airbags Front:

Driver and front passenger airbags

Airbags Side:

Optional front side-impact airbags

Seat Belts:

Three-point seat belts with pretensioners

💡 Technology Features

Infotainment

Audio System:

Standard AM/FM/CD player with premium audio system (e.g., Infinity) on higher trims.

Navigation:

Optional factory-installed GPS navigation system.

Driver Assistance

Cruise Control:

Standard electronically controlled cruise control.

Connectivity

Keyless Entry:

Standard keyless entry system.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 miles (12,000 km) or 6 months, whichever comes first.

Air Filter Replacement:

Every 15,000 miles (24,000 km) or 12 months.

Cabin Air Filter Replacement:

Every 15,000 miles (24,000 km) or 12 months.

Spark Plug Replacement:

Every 60,000 miles (96,000 km)

Transmission Fluid Change:

Every 60,000 miles (96,000 km) or as indicated by maintenance schedule.

Fluid Specifications

Engine Oil Type:

API SJ or higher, SAE 5W-30 Synthetic or Synthetic Blend

Engine Oil Capacity:

5.8 US Quarts (5.5 Liters) with filter

Coolant Type:

Hyundai Long Life Antifreeze/Coolant (Blue)

Brake Fluid Type:

DOT 3

Known Issues

Engine Oil Consumption:

Some reports of higher-than-average oil consumption in certain engines.

Transmission Harsh Shifting:

Occasional reports of harsh shifting or delayed engagement, often related to fluid condition or solenoids.

Suspension Clunking:

Worn suspension bushings or ball joints can lead to clunking noises.

HVAC Blower Motor:

Blower motor resistor failure can lead to non-functional fan speeds.

Power Window Motors:

Window regulator or motor failures have been reported.

📚 Vehicle History

Brand Heritage

Hyundai History:

Hyundai Motor Company, founded in 1967, initially focused on licensed production of Ford vehicles before developing its own models.

Model Evolution

Xg Series Introduction:

The XG series was Hyundai's first foray into the full-size luxury sedan segment, introduced in South Korea in 1999.

Xg300 To Xg350:

The XG350 succeeded the XG300, featuring a larger 3.5L V6 engine and minor styling updates.

Production

Production Period:

2003 model year (Globally, production of the XG series ran from 1999-2005).

Manufacturing Location:

Ulsan, South Korea

🏆 Awards & Recognition

Recognitions

Initial Reception:

While not a segment leader in sales, the XG350 was generally praised for its value, comfort, and powerful V6 engine in reviews of its time.

Safety Awards:

Achieved good ratings in government crash tests (NHTSA) and IIHS frontal offset tests, contributing to its safety reputation.
