Iseki Bolens Tractor H152 1592H 2140 & H174 1704H 2160 Hydrostatic Supplement Complete Workshop Service Repair Manual

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

This manual covers the Iseki/Bolens H152, 1592H, 2140, H174, 1704H, and 2160 hydrostatic tractor models. These compact utility tractors, likely produced in the late 1990s to early 2000s, are known...

26 people are viewing this right now

类型: Tractor

斯库: 99795

标签: 1592H 1704H 2140 2160 BOLENS H152 H174 Iseki Bolens Tractor

产品多属性

Description

This manual covers the Iseki/Bolens H152, 1592H, 2140, H174, 1704H, and 2160 hydrostatic tractor models. These compact utility tractors, likely produced in the late 1990s to early 2000s, are known for their hydrostatic transmission efficiency, offering ease of operation with foot pedal control for speed adjustment and typically a two-range hydrostatic system for optimal power delivery. Built on a heritage of quality from Iseki, a respected Japanese manufacturer, and often associated with the popular American brand Bolens, these tractors are designed for durability and suitability for homeowner and light commercial use. Their engineering emphasizes reliability, with a focus on the hydrostatic drive system's performance compared to gear-drive variants. This supplement to the Workshop Service Repair Manual provides comprehensive technical data specifically for the hydrostatic transmission system of these Iseki/Bolens tractors. It details critical maintenance procedures, including fluid changes and filter replacements, along with advanced diagnostic and repair instructions for hydrostatic unit components, pumps, and motors. The manual includes troubleshooting guides for common issues and emphasizes the importance of proper fluid maintenance and cooling system efficiency to ensure the longevity and performance of the hydrostatic drive. This resource is essential for owners, mechanics, and technicians seeking to maintain and repair the hydrostatic transmission, ensuring optimal operation and versatility of the tractor.
