Vehicle Segment:
Mid-size pickup truck
Key Competitors:
Toyota Hilux, Mitsubishi Triton (L200), Ford Ranger, Nissan Navara
Vehicle Strengths:
Known for durability, reliability, and off-road capability
Cost Saving:
Enables owners to perform maintenance and repairs themselves, saving on labor costs
Accessibility:
Instant digital access eliminates shipping delays and costs
Coverage Scope:
Comprehensive workshop and service repair
Target Audience:
Professional technicians and DIY mechanics
Estimated Page Count:
Hundreds of pages (typical for comprehensive factory manuals)
Manual Classification:
Workshop Service Manual / Repair Manual / Factory Service Manual
Language Provided:
English
Delivery Method:
Instant Download
Powertrain:
Engine, transmission, driveline, fuel system, cooling system, exhaust system
Chassis:
Suspension (front and rear), steering system, brakes (front and rear), wheels and tires
Electrical:
Engine control systems, body electrical systems, lighting, instrumentation, power accessories, audio system, wiring diagrams
Body:
Body structure, exterior panels, interior trim, doors, windows, seats, HVAC system
Maintenance:
Periodic maintenance charts, fluid changes, filter replacements, lubrication
Repair:
Step-by-step repair instructions for all major components and systems
Diagnostics:
Troubleshooting guides, symptom-based diagnostics, diagnostic trouble codes (DTCs)
Overhaul:
Detailed overhaul procedures for engines, transmissions, and other major assemblies
Diagnostic Capabilities:
Advanced diagnostics including component testing and circuit analysis
Repair Complexity:
Covers everything from basic fluid checks to complete engine and transmission rebuilds
Information Detail:
Includes detailed torque specifications, clearances, and assembly procedures
Engine Code Common:
4JJ1-TC (common for this generation, though other variants might exist)
Engine Configuration:
4-cylinder, inline, turbocharged diesel (common)
Displacement:
3.0 Liters (approx. 2999 cc for 4JJ1-TC)
Horsepower Range:
Typically 130-160 HP (depending on specific engine variant and tuning)
Torque Range:
Typically 270-350 Nm (depending on specific engine variant and tuning)
Fuel Delivery:
Common Rail Direct Injection (CRDi)
Cooling Type:
Water-cooled, pressurized system
Ignition Type:
Diesel Compression Ignition
Transmission Type Standard:
5-speed Manual Transmission
Transmission Type Optional:
4-speed or 5-speed Automatic Transmission (depending on market and trim)
Drivetrain Options:
Rear-Wheel Drive (RWD) and Four-Wheel Drive (4WD) with transfer case
Body Styles:
Single Cab, Extended Cab (Space Cab), Double Cab
Bed Length Options:
Varies by cab configuration (e.g., long bed, standard bed)
Curb Weight Range:
Approx. 1,700 kg to 2,000 kg (depending on configuration)
Gross Vehicle Weight Rating Gvwr:
Typically around 2,700 kg to 3,000 kg
Safety Certification Typical:
Refer to specific market crash test results (e.g., ANCAP, Euro NCAP if applicable)
Braking System:
Front disc brakes, Rear drum brakes (common), ABS (Anti-lock Braking System) available on some trims
Traction Control:
Available on some higher trims or 4WD models
Airbags:
Driver and passenger airbags standard on most models, side airbags optional/available on higher trims
Seat Belts:
3-point seat belts with pretensioners
Audio System:
Base models typically feature a single-DIN radio with CD player and basic speaker setup. Higher trims may offer 2-DIN units with USB/Aux inputs.
Cruise Control:
Available on some higher trim levels.
Auxiliary Input:
Auxiliary audio input jack commonly found on factory-fitted audio systems.
Power Windows:
Standard on higher trims, manual or power on lower trims depending on market.
Oil Change Interval:
Typically every 5,000 to 10,000 km or 6 months, whichever comes first (refer to manual for exact specification)
Air Filter Replacement:
Every 20,000 to 40,000 km or as needed based on driving conditions
Fuel Filter Replacement:
Every 20,000 to 40,000 km or as per manual, crucial for diesel engines
Engine Oil Grade:
API CI-4 or higher, SAE 15W-40 or 10W-30 (refer to manual for specific viscosity based on climate)
Engine Oil Capacity:
Approximately 6.5 to 7.0 Liters (refer to manual for exact capacity)
Coolant Type:
Isuzu Long Life Coolant (blue or green) or equivalent ethylene glycol-based coolant
Transmission Fluid Manual:
API GL-4 or GL-5, SAE 75W-90 (gear oil)
Transmission Fluid Automatic:
Dexron III or equivalent ATF (Automatic Transmission Fluid)
Common Wear Item:
Clutch wear, brake pad and rotor wear, suspension bushings, turbocharger wear (with high mileage/poor maintenance)
Diesel Specific:
Potential for injector issues or glow plug failures if maintenance is neglected, particularly fuel filter changes.
Isuzu Truck Legacy:
Isuzu has a long history in commercial vehicles and robust utility trucks, translating into D-Max's reputation for toughness.
D Max Platform:
The KB P190 is part of the second generation Isuzu D-Max, a platform known for its shared development with General Motors (GM) vehicles in certain markets.
Manufacturing Locations:
Primarily manufactured in Thailand, with assembly plants in other regions for specific markets.
