Iveco Motors Tier 2 Cursor Series C78 C10 C13 G-DRIVE 78 TE2 13 TE1 13 TE2 13 TE3 Engine Workshop Service & Repair Manual

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Iveco Motors Series: Cursor Series Model Variants: • C78 • C78 ENT • C10 • C10 ENT • C13 • C13 ENT • CURSOR G-DRIVE...

21 people are viewing this right now

类型: Engine

斯库: 51375

标签: C13 Cursor Series C10 Cursor Series C13 Cursor Series C78 Engine G-DRIVE 13 TE1 G-DRIVE 13 TE2 G-DRIVE 13 TE3 G-DRIVE 78 TE2 Inboard Engines Iveco Marine

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Iveco Motors

Series:

Cursor Series

Model Variants:

• C78

• C78 ENT

• C10

• C10 ENT

• C13

• C13 ENT

• CURSOR G-DRIVE

• CURSOR 78 TE2

• CURSOR 13 TE1

• CURSOR 13 TE2

• CURSOR 13 TE3

Engine Platforms:

• F2B Cursor engines

• F3A Cursor engines

• F3B Cursor engines

Emission Standard:

Tier 2

📋 Manual Details

Identification

Manual Type:

Workshop Service & Repair Manual

Format:

PDF Download

Language:

English (implied by product description)

Availability:

Instant Download

⚙️ Engine Specifications

General

Engine Type:

Internal Combustion (Diesel)

Displacement Variants:

• 7.8 Liters (C78)

• 10 Liters (C10)

• 13 Liters (C13)

Technical Data

Cylinder Block Materials:

Not specified, but typically cast iron for heavy-duty engines

Crankshaft Design:

Multi-bearing crankshaft with journals and crank pins

Piston Design:

Piston-connecting rod assembly with gudgeon pin

Lubrication

Oil Pump:

Included

Oil Filters:

Single and double filter options mentioned

Cooling

Cooling System Type:

Water-cooled

Water Pump:

Included

Turbocharging

Turbocharger Model:

HX 50W

Fuel System

Fuel Prefilter:

Included with water drain capability

Fuel Filter:

Included

Engine Management

Edc System:

Electronic Diesel Control (diagnostics tool required for checks)

🔧 Maintenance

Intervals

Engine Visual Inspection:

Daily

Water In Fuel Prefilter Check:

Daily

Engine Oil Change:

As required (no specific interval listed in overview)

Engine Oil Filter Change:

As required (no specific interval listed in overview)

Fuel Prefilter Change:

When required by application

Fuel Filter Change:

As required (no specific interval listed in overview)

Blow By Filter Check:

By clogging indicator

Drive Belt Check:

Condition of water pump/alternator control belt

Valve Lash Adjustment:

Check and adjust if required

Dry Air Filter Change:

Replacement and container cleaning

General

Service Recommendation:

Comprehensive service and repair procedures provided
