Target Audience:
Jaguar XK8/XKR owners, DIY enthusiasts, independent repair shops.
Value Proposition:
Significant cost savings on repairs and maintenance by enabling DIY service.
Alternatives:
Official Jaguar service manuals (often more expensive and harder to obtain), generic repair guides (less specific).
Ease Of Use:
Easy-to-follow step-by-step instructions with accompanying pictures.
Delivery:
Instant email delivery upon payment confirmation.
Ownership:
Lifetime access to the downloaded manual.
Model Years Covered:
1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006
Trim Levels Covered:
All XK8 and XKR models
Engine Variants Covered:
All engine variants (e.g., 4.0L V8, 4.2L V8)
Transmission Types Covered:
All transmission types (e.g., 5-speed automatic)
Estimated Page Count:
High (exact count not specified, but described as 'complete' covering A-Z procedures)
Manual Type:
Workshop Service Repair Manual
Format:
Downloadable Digital File (PDF compatible)
Engine:
Detailed diagnostics, repair, and overhaul for V8 engines (4.0L and 4.2L AJ-V8 variants).
Transmission:
Service and repair procedures for the automatic transmission (e.g., ZF 5HP24).
Brakes:
Brake system diagnostics, hydraulic components, ABS, and parking brake.
Electrical System:
Comprehensive wiring diagrams, diagnostic procedures for all electrical components and modules.
Suspension Steering:
Front and rear suspension, steering system, wheel alignment.
Body Interior:
Body panel repair, interior trim, seats, convertible top systems (if applicable).
Cooling Heating Ac:
Radiator, cooling fan, climate control, HVAC system.
Fuel System:
Fuel pump, injectors, fuel tank, evaporative emissions control.
Exhaust System:
Exhaust manifold, catalytic converters, mufflers.
Wheels Tires:
Wheel specifications, tire pressure recommendations, rotation.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, tune-ups.
Troubleshooting:
Diagnostic flowcharts and symptom-based troubleshooting for common and complex issues.
Repair:
Step-by-step instructions for virtually all mechanical and electrical repairs.
Overhaul:
Detailed procedures for engine and transmission rebuilds.
Installation:
Guidance on replacing components and systems.
Specifications:
Torque specifications, clearances, fluid capacities, electrical specifications.
Depth:
Comprehensive from basic maintenance to complete engine/transmission overhauls and advanced electrical diagnostics.
Compatibility:
Compatible with all PC & MAC Computers, tablets, and mobile phones.
Required Software:
Adobe Reader (free download if not pre-installed).
Printability:
Printable by page, chapter, or entire document.
Binding Type:
N/A (Digital Download)
Paper Type:
N/A (Digital Download)
Engine Type:
Jaguar AJ-V8 DOHC V8
Displacement Early:
3996 cc (4.0 Liters)
Displacement Later:
4196 cc (4.2 Liters)
Horsepower 4.0L Xk8:
290-370 hp (depending on year and specific variant, e.g., early vs. CATS system)
Torque 4.0L Xk8:
290-393 lb-ft (depending on year)
Horsepower 4.2L Xk8:
300 hp
Torque 4.2L Xk8:
315 lb-ft
Horsepower Xkr 4.0L:
370 hp (supercharged)
Torque Xkr 4.0L:
385 lb-ft (supercharged)
Horsepower Xkr 4.2L:
400 hp (supercharged)
Torque Xkr 4.2L:
406 lb-ft (supercharged)
Fuel Delivery:
Multi-point fuel injection (MEFI/PFI)
Fuel Type:
Premium Unleaded Gasoline (91 octane or higher recommended)
Transmission Type:
5-speed Automatic (ZF 5HP24 for 4.0L, ZF 6HP26 for 4.2L introduced later)
Optional Transmission:
N/A (All models were automatic)
Transmission Features:
Adaptive shift control, sport mode.
Transmission Fluid Type:
Refer to manual for specific ZF fluid type (e.g., ATF LT71141 or equivalent for 5HP24).
Body Styles:
2-door Coupe, 2-door Convertible
Length:
Approx. 193.7 inches (4920 mm)
Width:
Approx. 70.2 inches (1783 mm)
Height:
Approx. 52.5 inches (1334 mm)
Wheelbase:
Approx. 102.4 inches (2600 mm)
Curb Weight:
Approx. 3,700 - 4,000 lbs (1680 - 1815 kg) depending on configuration.
Safety Ratings:
Not explicitly stated in product info, but built to contemporary safety standards.
Active Safety:
ABS, Traction Control (CATS - Computer Active Technology Suspension), optional Electronic Stability Control (ESC).
Passive Safety:
Front airbags, side airbags, reinforced chassis and body structure.
Infotainment System:
Touchscreen navigation system (optional), premium audio systems (e.g., Alpine, Harman Kardon).
Driver Assistance Features:
Cruise control, parking sensors (later models).
Connectivity Features:
CD player, radio, cassette player (early models).
Oil Change Interval:
Typically 5,000 - 7,500 miles or annually, subject to driving conditions. Consult manual for precise recommendation.
Transmission Fluid Interval:
Recommended service interval varies by manufacturer and driving conditions, often around 60,000 - 100,000 miles. Critical to consult the manual.
Engine Oil Type:
Refer to manual for viscosity (e.g., 5W-30 or 10W-40) and API/ACEA specifications.
Coolant Type:
Jaguar specified coolant (e.g., OAT type, often orange or pink).
Brake Fluid Type:
DOT 3 or DOT 4, consult manual for exact specification.
Timing Chain Tensioners:
Early 4.0L AJ-V8 engines (pre-2000) were known for plastic timing chain tensioners that could degrade and cause catastrophic engine failure. Replacement with updated parts is crucial.
Nikasil Liners:
Early 4.0L AJ-V8 engines also featured Nikasil cylinder liners, which could be susceptible to damage from high sulfur content fuel. Later engines used Alusil liners.
Transmission Leaks:
Potential for leaks at the transmission cooler lines or gearbox casing.
Water Pump Failure:
The plastic impeller on early water pumps could fail.
