Jeep CHEROKEE 1999 Spare Parts Catalog

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Jeep Model: Cherokee Year: 1999 Codes Platform Code: XJ 👋 Introduction Market Position Vehicle Segment: Compact SUV Jeep Heritage: Part of Jeep's long legacy of...

16 people are viewing this right now

类型: Car

斯库: 585242

标签: 1999 Car Cars CHEROKEE Jeep

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Model:

Cherokee

Year:

Codes

Platform Code:

👋 Introduction

Market Position

Vehicle Segment:

Compact SUV

Jeep Heritage:

Part of Jeep's long legacy of off-road capable vehicles.

Competitive Analysis

Key Competitors 1999:

Ford Explorer, Chevrolet Blazer, Toyota RAV4, Honda CR-V (though slightly different positioning)

Key Features

Chassis Design:

Unibody construction, a departure from traditional body-on-frame SUVs of its era, offering better on-road manners.

Off Road Capability:

Renowned for its off-road prowess, especially with 4WD systems and high ground clearance.

Engine Options:

Popular 4.0L inline-six engine known for its torque and durability.

📋 Manual Details

Coverage Areas

All Systems:

Engine Coverage:

4.0L Inline 6-Cylinder (Select); 2.5L Inline 4-Cylinder (Select)

Transmission Coverage:

Automatic (Select Models); Manual (Select Models)

Drivetrain Coverage:

2WD; 4WD (Selec-Trac, Command-Trac)

Body And Chassis Coverage:

Exterior body panels, interior trim, chassis components, suspension, steering

Electrical System Coverage:

Wiring diagrams, lighting, power accessories, ignition, starting, charging

Brakes Coverage:

Front disc, rear drum; ABS (if equipped)

HVAC Coverage:

Heating, Ventilation, and Air Conditioning systems

Fuel System Coverage:

Fuel injection, fuel pump, lines, tank

Cooling System Coverage:

Radiator, water pump, thermostat, cooling fan

Exhaust System Coverage:

Manifold, catalytic converter, muffler, pipes

Suspension Coverage:

Front leaf springs, rear leaf springs, shock absorbers, steering knuckles

Steering Coverage:

Power steering system, steering column, tie rods

Wheel And Tire Coverage:

Wheel specifications, tire fitment, bolt patterns

Wheel Alignment Coverage:

Specifications for caster, camber, toe

Page Count

Estimated Pages:

Approx. 1000-1500 pages (estimated for a comprehensive parts catalog)

Manual Type

Type:

Spare Parts Catalog

Purpose:

Identify and order replacement parts for the 1999 Jeep Cherokee

Language

Primary Language:

English

Format

Digital Format:

Physical Format:

Digital Download (likely)

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Detailed illustrations of engine components, gaskets, seals, pistons, crankshaft, camshaft, cylinder head, and related parts.

Engine Electrical:

Spark plugs, ignition coils, sensors (crankshaft position, camshaft position, O2), starter motor, alternator, battery components.

Fuel And Emission Controls:

Fuel injectors, fuel pump, fuel filter, evaporative emission control (EVAP) system components, catalytic converter, exhaust gaskets.

Transmission And Drivetrain:

Internal transmission components (gears, clutches, seals), transfer case parts, driveshafts, U-joints, differential components (gears, bearings, seals).

Suspension And Steering:

Leaf springs (front and rear), shackles, bushings, shock absorbers, steering box, tie rod ends, ball joints, sway bar components.

Brake System:

Brake pads, rotors, calipers, brake lines, wheel cylinders, master cylinder, brake booster, ABS sensors (if applicable).

Electrical Components:

Headlights, taillights, interior lighting, switches, fuses, relays, wiring harnesses, connectors, power window regulators, door lock actuators.

HVAC Components:

Condenser, evaporator, compressor, blower motor, heater core, AC lines, cabin air filter (if applicable).

Body And Interior:

Door handles, mirrors, grilles, bumpers, fenders, hoods, liftgates, interior trim panels, seats, floor mats.

Procedures Included

Part Identification:

Precise identification of every component with exploded diagrams and part numbers.

Interchangeability Notes:

Potential notes on part interchangeability between specific sub-models or build dates.

Related Parts Listing:

Indication of associated parts needed for a complete repair (e.g., gaskets, bolts).

Technical Depth

Depth:

Highly detailed, focused on parts identification and OE (Original Equipment) part numbers for accuracy.

Diagrams Quality:

High-quality exploded view diagrams crucial for visual part identification.

Component Grouping:

Parts are typically organized by system or assembly for logical navigation.

📊 Manual Specifications

File Format

Format:

PDF (Portable Document Format)

Searchability:

Likely text-searchable for part names and numbers.

Print Quality

Reproducibility:

High resolution, suitable for printing individual pages or the entire document.

Binding Type

Digital:

N/A (Digital Download)

Paper Type

Digital:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Code 4.0L:

Engine Type 4.0L:

Overhead Valve (OHV) Inline 6-Cylinder

Displacement 4.0L:

242 cubic inches (3.96 Liters)

Bore X Stroke 4.0L:

3.875 in x 3.562 in

Compression Ratio 4.0L:

8.8:1

Horsepower 4.0L:

185 hp @ 4,600 rpm (approx.)

Torque 4.0L:

220 lb-ft @ 3,000 rpm (approx.)

Secondary Engine

Engine Code 2.5L:

Engine Type 2.5L:

Overhead Valve (OHV) Inline 4-Cylinder

Displacement 2.5L:

150 cubic inches (2.5 Liters)

Horsepower 2.5L:

125 hp @ 5,200 rpm (approx.)

Torque 2.5L:

148 lb-ft @ 3,200 rpm (approx.)

Fuel System

Fuel Delivery:

Sequential Electronic Multi-Port Fuel Injection (MPI)

Recommended Fuel:

87 Octane Unleaded Gasoline

Ignition System

Type:

Distributorless Ignition System (DIS) or Distributor with Coil Pack (depending on specific build date/engine variant)

🔧 Transmission

Standard

Transmission Type:

4-Speed Automatic (Select Models)

Optional

Transmission Type:

5-Speed Manual (Select Models)

Features

Automatic Transmission Model:

42RE (for 4.0L), 30RH (for 2.5L)

Manual Transmission Model:

AX-15 (early models), NV3550 (later models)

Transfer Case Options:

2WD, Selec-Trac (Full-time 4WD with 2WD mode), Command-Trac (Part-time 4WD)

📐 Dimensions

Exterior

Wheelbase:

103.4 inches (2626 mm)

Length:

167.5 inches (4255 mm)

Width:

70.1 inches (1781 mm)

Height:

63.4 inches (1610 mm)

Ground Clearance:

Approx. 8-9 inches (depending on suspension/tire configuration)

Weights

Curb Weight:

Approx. 3,300 - 3,800 lbs (depending on engine, drivetrain, and trim)

Towing Capacity:

Up to 2,000 lbs (unbraked), 5,000 lbs (braked, with optional tow package)

🛡️ Safety Features

Ratings

NHTSA Front Impact Driver:

4 Stars (1999 Model Year)

NHTSA Front Impact Passenger:

4 Stars (1999 Model Year)

Active Features

Available on some models (standard rear ABS on others)

Passive Features

Airbags:

Driver and Passenger front airbags

Seatbelts:

Front 3-point height-adjustable seat belts, rear lap and shoulder belts

💡 Technology Features

Infotainment

Audio System:

AM/FM stereo with cassette player, optional CD player. Basic speaker configurations.

User Interface:

Analog gauges and physical button controls for climate and audio.

Driver Assistance

Cruise Control:

Standard on most trim levels.

Connectivity

Auxiliary Inputs:

None standard. Aftermarket solutions for AUX/Bluetooth are common.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 3,000 - 5,000 miles or 3-6 months (depending on oil type and driving conditions).

Air Filter Replacement:

Every 15,000 - 30,000 miles, or as needed based on inspection.

Spark Plug Replacement:

4.0L: Approx. 60,000 - 100,000 miles (depending on plug type); 2.5L: Approx. 30,000 - 60,000 miles.

Transmission Fluid Change:

Every 30,000 - 60,000 miles (more frequently for heavy use/towing).

Fluid Specifications

Engine Oil 4.0L:

API Certified SAE 10W-30 or 10W-40. Refer to specific model year for exact recommendation (e.g., API SN/SP).

Engine Oil 2.5L:

API Certified SAE 5W-30 or 10W-30. Refer to specific model year for exact recommendation.

Coolant:

Ethylene Glycol antifreeze (conventional green) or HOAT (Hybrid Organic Additive Technology) with a 50/50 mix of antifreeze and distilled water. Capacity: Approx. 11-13 quarts.

Transmission Fluid Automatic:

ATF+3 (Chrysler spec) or equivalent for 42RE/30RH transmissions.

Transmission Fluid Manual:

GL-3 or GL-4 75W-90 gear oil for AX-15 and NV3550.

Power Steering Fluid:

ATF+3 or Mopar Power Steering Fluid.

Brake Fluid:

DOT 3.

Known Issues

Cooling System:

Radiator leaks, cracked coolant hoses, failing water pump, and thermostat issues are common on older XJs.

Suspension:

Worn leaf spring bushings, worn shackles, and leaf spring sag can occur, impacting ride quality and alignment.

Electrical:

Headlight switch failure, intermittent power window operation, and alternator issues can be encountered.

Engine 4.0L:

Cracked cylinder heads (though less common on 1999 models compared to earlier years), head gasket leaks, and lifter tick.

Steering:

Worn steering box, sloppy steering feel, and leaking power steering pumps.

Exhaust:

Catalytic converter failure, rusted exhaust pipes, and manifold cracks.

📚 Vehicle History

Brand Heritage

Jeep Legacy:

Built upon Jeep's reputation for ruggedness and off-road capability, originating from military vehicles.

Model Evolution

Xj Generation Start:

The XJ generation began in 1984, marking a significant shift to unibody construction for Jeep.

Xj Generation End:

The XJ generation concluded in 2001, with the Liberty (KJ) succeeding it in 2002.

Production

Manufacturing Locations:

Mainly Toledo, Ohio, USA

Popular Trims 1999:

Sport, SE, Limited, Classic

🏆 Awards & Recognition

Recognitions

Off Road Magazine:

Consistently recognized for its off-road capability and value by automotive publications over its lifespan.

Jeep Brand Recognition:

Benefited from Jeep's established reputation for durability and off-road prowess.
