Positioning:
Premium, high-quality factory service manual for DIY enthusiasts and professional mechanics
Advantage:
Superior to competitor manuals due to searchability, indexing, and bookmarks; identical to manufacturer CD version but presented in a more user-friendly digital format.
Value Proposition:
Cost-saving through DIY repairs, detailed step-by-step guidance, and exhaustive system coverage.
Bonus Content:
Includes a bonus Automatic Transmission AW4 Manual.
Powertrain:
Engine, Transmission, Transfer Case, Differential and Driveline, Exhaust System and Turbo Charger (if applicable), Fuel System, Emission Control System
Chassis:
Suspension, Steering, Brakes, Tires and Wheels, Frame and Bumpers
Electrical Systems:
Battery, Starting Systems, Charging System, Ignition System, Instrument Panel Systems, Audio Systems, Horn Systems, Vehicle Speed Control System, Turn Signal and Hazard Warning Systems, Wipers and Washer Systems, Lamps, Passive Restraint Systems, Electrically Heated Systems, Power Distribution Systems, Power Lock Systems, Vehicle Theft/Security Systems, Power Seat Systems, Power Window Systems, Power Mirror Systems, Chime/Buzzer Warning Systems, Overhead Console Systems, Wiring Diagrams
Comfort And Convenience:
Heating and Air Conditioning, Power Seat Systems, Power Window Systems, Power Mirror Systems, Audio Systems
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, lubrication
Diagnostics:
Troubleshooting, fault code interpretation, component testing
Repair:
Component removal, installation, adjustment, and overhaul
Rebuilding:
Engine, transmission, transfer case, differentials, and other major components (as applicable)
Installation:
Accessory installation and adjustments (e.g., power windows, locks)
Depth:
Comprehensive, from basic maintenance to advanced diagnostics and full component rebuilds
Visuals:
Includes photos, exploded views, and detailed diagrams
Searchability:
Fully searchable text
Navigation:
Indexed and fully bookmarked
Engine Options:
4.0L Inline 6-Cylinder (High Output) OHV 12-Valve (242 ci)
Engine Code:
ERH (for 4.0L HO)
Horsepower 4.0L:
190 hp @ 4750 rpm (approx.)
Torque 4.0L:
220 lb-ft @ 3000 rpm (approx.)
Induction:
Sequential Multi-Port Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline
ECM:
Chrysler/Jeep Powertrain Control Module (PCM)
Transmission Type:
42RE Automatic Transmission (Optional for 4.0L)
Transmission Type Manual:
AX-15 Manual Transmission (Standard on some models)
Transfer Case:
NP231 Command-Trac (Standard)
Automatic Transmission Fluid:
Chrysler ATF+4 (or equivalent, check manual for specific recommendation)
Manual Transmission Fluid:
Dexron II/III or Mopar Manual Transmission Lubricant
Wheelbase:
103.4 inches (2626 mm)
Length:
170.5 inches (4331 mm)
Width:
71.3 inches (1811 mm)
Height:
64.4 inches (1636 mm)
Curb Weight:
Approx. 3400-3700 lbs (1542-1678 kg), varies by configuration
Gross Vehicle Weight Rating:
Approx. 4700-5000 lbs (2132-2268 kg), varies by configuration
Cargo Volume:
70.4 cu ft (with rear seats folded)
NHTSA Rollover Resistance:
3-star (refer to specific year/test)
Brakes Front:
Vented Disc
ABS:
Optional (4-wheel ABS available on some models)
Airbags:
Driver-side airbag standard
Seat Belts:
Front and rear seat belts
Oil Change Interval:
Every 3,000-5,000 miles or 3-6 months (refer to manual for exact spec)
Coolant Flush Interval:
Every 30,000-50,000 miles or 2-3 years
Transmission Fluid Change Interval:
Every 30,000-60,000 miles (refer to manual and driving conditions)
Engine Oil Specification:
API SJ or SL, SAE 10W-30 or 10W-40 (check manual for specific viscosity and type)
Coolant Type:
Chrysler HOAT (Hybrid Organic Acid Technology) or equivalent green ethylene glycol-based coolant
Common Failures:
Head gasket leaks (especially on early 4.0L), radiator issues, water pump failures, steering box wear, rust (especially in critical areas like unibody rails and floor pans).
Electrical Quirks:
Intermittent electrical gremlins can occur due to age and wiring harness issues.
