🏷️ Basic Information

Make:

Jeep

Model:

Compass

Year:

2014

Generation Identifier:

MK (Second Generation)

Generation Years:

2011-2016

Chassis Code:

MK

👋 Introduction

Target Audience:

DIY enthusiasts, independent repair shops, and Jeep Compass owners seeking to understand and maintain their vehicles.

Value Proposition:

Provides dealership-level technical information, enabling cost savings on repairs and maintenance while fostering greater vehicle understanding.

Differentiation:

Emphasizes vehicle-specific accuracy and factory-level detail over generic repair guides, assuring technicians and owners of its reliability.

Content Type:

Step-by-step instructions, diagrams, illustrations, wiring schematics, specifications.

Convenience:

Single, easy-to-use PDF format, no more paper manuals, printable pages for on-site use.

📋 Manual Details

Primary Coverage:

All models and all repairs A-Z

Specific Coverage:

Vehicle-specific, dealership technician level

Estimated Page Count:

Significant (often 1000+ pages for comprehensive manuals)

Type:

Service and Repair Manual

Language:

English

File Format:

PDF

Distribution Method:

Digital Download

📖 Manual Coverage

Engine Management:

Engine control system, fuel service specifications, emission control, intake, exhaust, cooling, lube, ignition, starting, charging

Powertrain:

Auto transmission, clutch, manual transmission, transfer propeller shaft, drive shaft, differential, axle, suspension

Chassis And Brakes:

Tire & wheel, brake control, brake, parking brake, steering column, power steering

Electrical And Comfort:

Air condition, suppl. restraint system (SRS), seat belt, engine immobilizer, cruise control, wiper & washer, door lock, meter, audio/visual, horn, windshield/glass/mirror, instrument panel, seat, engine hood/door, exterior & interior electrical systems, multiplex/CAN communication

Maintenance:

Scheduled maintenance, fluid checks and changes, filter replacements, belt inspections

Diagnostics:

Troubleshooting guides, symptom-based diagnostics, diagnostic trouble code (DTC) explanations

Repair:

Complete step-by-step repair instructions for all major systems and components

Component Replacement:

Detailed procedures for replacing engine, transmission, suspension, brake, electrical, and body components

Depth:

Factory-level detail, including precise torque specifications, diagnostic procedures, wiring schematics, and component tolerances.

📊 Manual Specifications

Readability:

High-resolution, zoomable images and text

Searchability:

Likely text-searchable if properly created

Printability:

All pages are printable

Customization:

Print only required pages and diagrams, enlarged copies of images possible

Binding:

N/A (Digital PDF format)

Paper:

N/A (Digital PDF format)

Operating Systems:

Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac compatible

Required Software:

Adobe PDF Reader, Winzip (free online)

⚙️ Engine Specifications

Engine Options 2014:

2.0L Tigershark I4, 2.4L Tigershark I4

Engine Code 2.0L:

GEMA (World Engine)

Engine Code 2.4L:

Tigershark (World Engine variant)

Horsepower 2.0L:

Approx. 158 hp @ 6400 rpm

Torque 2.0L:

Approx. 141 lb-ft @ 5000 rpm

Horsepower 2.4L:

Approx. 172 hp @ 6000 rpm

Torque 2.4L:

Approx. 165 lb-ft @ 4400 rpm

Fuel Delivery:

Electronic Multi-Point Fuel Injection (MPI)

Fuel Type:

Unleaded gasoline

Ignition System:

Distributorless ignition system (DIS) with coil-on-plug

🔧 Transmission

Standard Transmission:

5-speed Manual Transmission (Getrag Getrag PT555)

Optional Transmission FWD:

Continuously Variable Transmission (CVT) - JF011E (Nissan RE0F10A variant)

Optional Transmission AWD:

Continuously Variable Transmission (CVT) - JF011E (Nissan RE0F10A variant) with AWD capability

Cvt Features:

Selectable AWD modes (LOCK), simulated gear shifts

📐 Dimensions

Length:

Approx. 169.1 inches

Width:

Approx. 69.5 inches

Height:

Approx. 63.3 inches

Wheelbase:

Approx. 103.7 inches

Curb Weight FWD:

Approx. 3,100 - 3,300 lbs

Curb Weight AWD:

Approx. 3,300 - 3,500 lbs

🛡️ Safety Features

NHTSA Overall Rating:

4 out of 5 stars (for 2014 models)

IIHS Front Crashworthiness:

Good

IIHS Side Impact:

Good

Brake System:

Four-wheel disc brakes with ABS

Stability Control:

Electronic Stability Control (ESC) with Electronic Roll Mitigation

Traction Control:

Traction Control System (TCS)

Airbags:

Front airbags, front side-impact airbags, full-length side curtain airbags

Seatbelts:

Three-point seatbelts with pretensioners

💡 Technology Features

Infotainment Options:

Uconnect infotainment system with touchscreen, CD/DVD/MP3 player, SiriusXM Satellite Radio, optional navigation.

Connectivity:

Bluetooth for hands-free calling and audio streaming, USB port, auxiliary input.

Camera:

Optional ParkView Rear Back-Up Camera

Sensors:

Optional ParkSense Rear Park Assist System

Cruise Control:

Standard cruise control, often with steering wheel mounted controls.

🔧 Maintenance

Oil Change Interval:

Every 7,500 miles or 6 months, or 3,750 miles if operating under severe conditions (refer to manual for specifics).

Tire Rotation:

Every 7,500 miles

Cabin Air Filter:

Inspect every 10,000 miles, replace as needed (typically every 15,000-30,000 miles).

Spark Plugs:

Refer to manual; typically around 100,000 miles for iridium-tipped plugs.

Engine Oil:

SAE 0W-20 synthetic motor oil. API SN certified. Capacity approx. 4.5 quarts (2.0L) and 5.5 quarts (2.4L).

Transmission Fluid Cvt:

Mopar CVTF J4 or equivalent (Nissan NS-2 specification). Capacity approx. 5.6 quarts.

Coolant:

Mopar Antifreeze/Coolant (HOAT) 50/50 mixture. Capacity approx. 7.7 quarts.

Brake Fluid:

DOT 3

Power Steering Fluid:

Mopar Power Steering Fluid or equivalent.

Cvt Concern:

Some CVT models have reported issues with premature wear or failure, often related to fluid degradation or cooling. Regular fluid changes and proper maintenance are crucial.

Suspension Noise:

Occasional reports of suspension component noise (e.g., struts, control arms) over time.

Electrical Gremlins:

As with many vehicles of this era, minor electrical issues or sensor faults can occur. The detailed wiring diagrams in the manual are invaluable for diagnosis.

📚 Vehicle History

Jeep Brand:

Jeep is an iconic American automotive brand with a rich history in off-road and rugged utility vehicles, known for its durability and capability.

Compass Introduction:

The Jeep Compass was introduced in 2007 as a compact crossover SUV, positioned as a more car-like and accessible Jeep model.

Mk Generation:

The MK generation (2007-2016) received a significant refresh for the 2011 model year, which included updated styling, interior improvements, and powertrain enhancements, defining the 2014 model.

Manufacturing Location:

Belvidere, Illinois, USA

🏆 Awards & Recognition

IIHS Safety Award:

The 2014 Jeep Compass earned Top Safety Pick status from the IIHS in some configurations and model years prior to this specific update, highlighting good performance in crash tests.
