🏷️ Basic Information

Make:

Jeep

Model:

Patriot

Year:

2010

Vehicle Code:

MK

👋 Introduction

Segment:

Compact SUV / Crossover

Target Audience:

Budget-conscious buyers seeking a practical and capable compact SUV with Jeep's brand identity.

Key Competitors:

Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Subaru Forester

Exterior Styling:

Distinctive Jeep styling with a boxy, upright stance and signature seven-slot grille.

Capability:

Available Freedom Drive I™ (FWD) and Freedom Drive II™ (AWD with off-road enhancements like low range gearing and skid plates) for enhanced all-weather and light off-road capability.

Interior Practicality:

Spacious interior for its class, versatile cargo space with folding rear seats.

Value Proposition:

Offers Jeep branding and some degree of off-road capability at a more accessible price point compared to larger Jeep models.

📋 Manual Details

General Operation:

True

Maintenance:

True

Troubleshooting:

True

Specifications:

True

Safety Features:

True

Technical Repair:

True

Estimated Pages:

Approx. 400-500

Type:

Owner's Manual / User Manual

Language:

English

Format:

Digital Download (PDF)

📖 Manual Coverage

Powertrain:

Engine, Transmission, Drivetrain (FWD/AWD)

Chassis:

Suspension, Steering, Brakes

Electrical:

Lighting, Instruments, HVAC Controls, Audio System, Power Accessories

Body And Interior:

Doors, Windows, Seats, Climate Controls, Body Panels

Safety Systems:

Airbags, Seatbelts, ABS, Traction Control, Electronic Stability Control (ESC)

Routine Maintenance:

Oil Changes, Filter Replacements, Fluid Checks and Top-offs, Tire Rotation

Basic Troubleshooting:

Warning Lights, Common Drivability Issues, Interior/Exterior Component Functionality

Fluid Replacement:

Engine Oil, Coolant, Brake Fluid, Power Steering Fluid, Transmission Fluid

Tire And Wheel:

Tire Pressure Monitoring System (TPMS) reset, Jacking and Lifting Points

Operator Controls:

Dashboard Layout, Switch Functions, Infotainment Operation

Depth:

Comprehensive owner-level information for operation, maintenance, and basic troubleshooting. Not a full factory service manual, but provides essential details for understanding vehicle systems and performing routine upkeep.

📊 Manual Specifications

File Type:

PDF

Searchability:

Typically searchable text, enabling quick navigation to specific topics.

Resolution:

High resolution, suitable for printing individual pages or the entire manual.

Digital Format Advantage:

Instant download, no physical binding concerns. Print only what you need.

N A:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Code 1:

2.4L I4 (World Engine)

Displacement 1:

2.4 Liters (2360 cc)

Horsepower 1:

172 hp @ 6000 rpm

Torque 1:

165 lb-ft @ 4400 rpm

Engine Code 2:

2.0L I4

Displacement 2:

2.0 Liters (1998 cc)

Horsepower 2:

158 hp @ 6400 rpm

Torque 2:

141 lb-ft @ 5000 rpm

Fuel Delivery:

Multi-point Fuel Injection (MPI)

Fuel Type:

Unleaded Gasoline

Emission Controls:

California/Federal Emissions (varies by region)

🔧 Transmission

Transmission Type 1:

5-Speed Manual

Transmission Type 2:

Continuously Variable Transmission (CVT) - JF011E (Kugler)

Transmission Type 3:

4-Speed Automatic (41TE - less common for 2.4L)

Drivetrain Options:

Front-Wheel Drive (FWD), All-Wheel Drive (AWD - Freedom Drive I and Freedom Drive II)

📐 Dimensions

Length:

174.5 inches (4432 mm)

Width:

69.1 inches (1755 mm)

Height:

65.7 inches (1669 mm)

Wheelbase:

103.7 inches (2634 mm)

Ground Clearance:

Approx. 8.1 inches (206 mm) with FDII

Cargo Volume Rear Seats Up:

23.4 cu ft (663 liters)

Cargo Volume Rear Seats Down:

62.7 cu ft (1776 liters)

Curb Weight Min:

Approx. 3,338 lbs (1514 kg) - FWD

Curb Weight Max:

Approx. 3,647 lbs (1654 kg) - AWD FDII

Towing Capacity:

2,000 lbs (907 kg) (when properly equipped with trailer tow group)

🛡️ Safety Features

NHTSA Front Driver Impact:

Good

NHTSA Front Passenger Impact:

Good

NHTSA Side Driver Impact:

Good

NHTSA Side Rear Passenger Impact:

Good

NHTSA Rollover Resistance:

4/5 Star Rating (estimated)

IIHS Front Crashworthiness:

Good

IIHS Side Impact Crashworthiness:

Good

IIHS Roof Strength:

Good

ABS:

Standard

Traction Control:

Standard

Electronic Stability Control:

Standard

Airbags:

Front, Side Curtain, Front Seat-Mounted Side Airbags

Seatbelts:

3-point front and rear seatbelts, pretensioners

Child Seat Anchors:

LATCH System

💡 Technology Features

Audio System:

Standard AM/FM/CD/MP3 player. Optional Boston Acoustics premium audio system available on higher trims.

Navigation:

Optional Uconnect Navigation system available.

Tire Pressure Monitoring:

Standard (TPMS)

Cruise Control:

Standard

Rear View Camera:

Optional

Bluetooth:

Optional Uconnect Hands-Free Communication system with Bluetooth capability.

Usb Port:

Optional

🔧 Maintenance

Oil Change Interval:

Every 6,000 miles (9,600 km) or 6 months, whichever comes first (or based on oil change indicator system).

Air Filter Replacement:

Every 24,000 miles (38,400 km) or 24 months

Engine Coolant Replacement:

First replacement at 100,000 miles (160,000 km), then every 50,000 miles (80,000 km) thereafter.

Spark Plug Replacement:

Every 100,000 miles (160,000 km) (for Iridium spark plugs)

Transmission Fluid Change:

CVT fluid typically needs changing at around 60,000-100,000 miles, depending on driving conditions. Automatic transmission fluid and filter changes are also recommended at similar intervals. Consult manual for specific recommendations.

Engine Oil Type:

SAE 5W-20 (API SN or higher)

Engine Oil Capacity:

4.5 quarts (4.3 liters) for 2.4L, 4.0 quarts (3.8 liters) for 2.0L

Coolant Type:

Mopar OAT (Orange) Antifreeze/Coolant, 5 Year / 100,000 Mile Formula

Brake Fluid Type:

DOT 3

Power Steering Fluid Type:

ATF +4 (Chrysler specification)

Cvt Transmission:

Some owners have reported issues with the CVT transmission, including premature failure or hesitation, particularly in earlier models. Regular fluid changes are critical.

Suspension Components:

Wear on suspension components like ball joints and control arms can occur with mileage.

Heater Core:

Some reports of premature heater core failure, leading to cabin heating issues.

Engine Oil Leaks:

Minor oil leaks can sometimes develop from valve cover gaskets or oil pan seals.

📚 Vehicle History

Jeep Legacy:

Jeep has a long-standing reputation for ruggedness and off-road capability, dating back to its military origins in WWII.

Introduction Year:

2007 (First Generation)

2010 Updates:

Minor updates may have been applied, but the core design and platform remained consistent from the 2007 introduction.

Platform:

Chrysler's global compact car platform (shared with Dodge Caliber and Compass)

Manufacturing Location:

Belvidere Assembly Plant, Illinois, USA

🏆 Awards & Recognition

IIHS Top Safety Pick:

The Jeep Patriot often received good ratings from the IIHS for its safety performance, contributing to its competitive standing.

Consumer Reports:

Consumer Reports typically rated the Patriot below average for predicted reliability, often citing issues with the CVT transmission and other mechanical components.

California Pzev:

Certain configurations of the Patriot were available as Partial Zero Emission Vehicles (PZEV) in California and other CARB-compliant states.
