🏷️ Basic Information

Make:

Jeep

Model:

Patriot

Year:

2017

Vin Prefix:

1J4

👋 Introduction

Segment:

Compact SUV

Target Audience:

Budget-conscious consumers seeking a capable, no-frills compact SUV with a focus on utility and off-road potential (relative to segment).

Key Competitors 2017:

Honda CR-V, Toyota RAV4, Ford Escape, Kia Sportage, Hyundai Tucson, Subaru Forester

Distinctive Selling Points:

Affordability, available 4x4 (Freedom Drive II with low-range gearing), boxy and upright styling, relatively simple mechanicals, good visibility.

Manual Value Proposition:

Empowers owners with dealership-level repair and maintenance information, enabling cost savings and a deeper understanding of their vehicle.

📋 Manual Details

General Coverage:

All models and all repairs A-Z

Geographic Scope:

Global (based on dealership technician usage)

Estimated Page Count:

Varies significantly by specific model year and engine, but described as comprehensive (hundreds to over a thousand pages typical for full service manuals)

Type:

Factory Service and Repair Manual

Language:

English

Format:

PDF (Digital Download)

📖 Manual Coverage

Powertrain:

Engine, Fuel System, Emission Control, Cooling System, Lubrication System, Ignition System, Starting System, Charging System, Automatic Transmission, Manual Transmission, Clutch

Drivetrain:

Transfer Case, Propeller Shaft, Drive Shaft, Differential, Axles

Chassis:

Suspension, Wheels, Tires, Brakes (Service, Control, Parking), Steering Column, Power Steering

Electrical And Electronics:

Electrical System, Multiplex/CAN Communication, Supplemental Restraint System (Airbags), Seat Belts, Engine Immobilizer, Cruise Control, Wiper and Washer Systems, Door Locks, Horn, Instrument Panel, Meter/Audio/Visual Systems

Body And Interior:

Air Conditioning, Windshield/Glass/Mirrors, Instrument Panel, Seats, Engine Hood/Doors, Exterior and Interior Trim

Diagnostic Procedures:

Component testing, circuit analysis, DTC (Diagnostic Trouble Code) interpretation, troubleshooting flowcharts

Maintenance Procedures:

Scheduled maintenance, fluid changes, filter replacements, inspections

Repair Procedures:

Component removal, installation, adjustment, calibration, and overhaul for all major vehicle systems

Technical Data And Specs:

Torque specifications, clearances, fluid capacities, electrical resistance values, system pressures

Depth:

Comprehensive, vehicle-specific. Designed for dealership technicians, covering everything from routine maintenance to complex diagnostics and full rebuilds.

Accuracy:

Directly sourced from OEM (Original Equipment Manufacturer) data, ensuring precision and adherence to factory standards.

📊 Manual Specifications

File Type:

PDF

Searchability:

Likely text-searchable due to PDF format, facilitating quick information retrieval.

Printability:

All pages are printable, allowing users to create hard copies for specific tasks or locations.

Image Resolution:

High-resolution for clear viewing and printing of diagrams, illustrations, and schematics.

Binding:

N/A (Digital PDF - user prints and binds as desired)

Paper Type:

N/A (Digital PDF - user chooses paper type for printing)

Reader Requirement:

Adobe PDF Reader (Free)

Compression Utility:

WinZip or similar (Free)

Operating Systems:

Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac compatible

⚙️ Engine Specifications

Engine Code:

GEMA (Global Engine Manufacturing Alliance) family

Displacement:

2.0L (1998 cc) and 2.4L (2360 cc)

Cylinder Configuration:

Inline-4 (I4)

Horsepower 2.0L:

158 hp @ 6400 rpm (approx.)

Torque 2.0L:

141 lb-ft @ 5000 rpm (approx.)

Horsepower 2.4L:

172 hp @ 6000 rpm (approx.)

Torque 2.4L:

165 lb-ft @ 4400 rpm (approx.)

Injection Type:

Multi-point Fuel Injection (MPI)

Fuel Type:

Unleaded Gasoline

System Type:

Catalytic converter, oxygen sensors, EGR (Exhaust Gas Recirculation) system (depending on market/configuration)

🔧 Transmission

Transmission Type Base:

5-Speed Manual Transmission

Transmission Type Optional:

Continuously Variable Transmission (CVT) with AutoStick or 4-Speed Automatic Transmission (depending on engine and trim)

Cvt Designation:

CVT2 (Continuously Variable Transmission)

AWD System:

Freedom Drive I (full-time, lockable AWD), Freedom Drive II (off-road package with CVT, low-range gearing, locking center differential)

📐 Dimensions

Length:

Approximately 168.4 inches (4277 mm)

Width:

Approximately 69.1 inches (1755 mm)

Height:

Approximately 65.7 inches (1669 mm)

Wheelbase:

Approximately 103.7 inches (2634 mm)

Cargo Volume Behind Rear Seats:

Approximately 23.4 cubic feet (0.66 m³)

Cargo Volume With Rear Seats Folded:

Approximately 61.5 cubic feet (1.74 m³)

Curb Weight Start:

Approximately 3,188 lbs (1446 kg) for FWD 2.0L manual

Curb Weight End:

Approximately 3,579 lbs (1623 kg) for AWD 2.4L CVT w/FDII

🛡️ Safety Features

NHTSA Overall Rating 2017:

4 out of 5 stars (Overall, Frontal Driver, Frontal Passenger, Side Driver, Side Rear Passenger, Rollover) - based on available data, may vary slightly by specific configuration.

Braking System:

Front ventilated disc brakes, rear drum brakes (standard on most models) or rear disc brakes (optional/higher trims)

ABS:

Standard Anti-lock Braking System (ABS)

Traction Control:

Standard Electronic Traction Control

Electronic Stability:

Standard Electronic Stability Control (ESC)

Airbags:

Front driver and passenger airbags, front side-impact airbags, full-length side curtain airbags (standard across most trims)

Seatbelts:

3-point seatbelts with pretensioners, LATCH child seat anchor system

💡 Technology Features

Infotainment System:

Uconnect infotainment system, typically with touchscreens ranging from 4.3 to 6.5 inches, offering AM/FM, CD/DVD, MP3, SiriusXM Satellite Radio, and optional navigation.

Driver Assistance Features:

Limited; typically includes ABS, Traction Control, ESC. Backup camera and parking assist sensors were optional on higher trims.

Connectivity Options:

Bluetooth connectivity for hands-free calling and audio streaming (depending on Uconnect system), USB and auxiliary audio inputs.

🔧 Maintenance

Oil Change Interval:

Every 7,500 miles (12,000 km) or 6 months, whichever comes first, using synthetic oil. (Consult manual for exact recommendation based on driving conditions).

Tire Rotation Interval:

Every 7,500 miles (12,000 km) or with oil changes.

Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on inspection.

Spark Plug Replacement:

2.0L: 100,000 miles (160,000 km); 2.4L: 100,000 miles (160,000 km) - use specified iridium plugs.

Engine Oil Type:

SAE 5W-20, API Certified (Full Synthetic recommended for optimal performance and longevity)

Engine Oil Capacity 2.0L:

4.3 US quarts (4.1 L) with filter

Engine Oil Capacity 2.4L:

5.0 US quarts (4.7 L) with filter

Coolant Type:

MOPAR OAT (Organic Acid Technology) Engine Coolant or equivalent HOAT (Hybrid Organic Acid Technology) coolant, typically a pink or orange color.

Transmission Fluid Type Cvt:

CVT Fluid (e.g., MOPAR CVTF NS-2 or equivalent specification, consult manual for exact part number)

Transmission Fluid Type Auto:

MOPAR ATF+4 (Automatic Transmission Fluid) or equivalent

Brake Fluid Type:

DOT 3 or DOT 4 Brake Fluid

Power Steering Fluid:

MOPAR Power Steering Fluid or equivalent (if equipped with hydraulic power steering)

Common Complaints:

CVT issues (hesitation, shuddering), interior rattles, some electrical gremlins, potential for coolant leaks (heater core, water pump), transmission mount wear, rear brake caliper seizing (especially with rear drums).

📚 Vehicle History

Jeep Legacy:

Jeep, established in 1941, is renowned for its off-road capabilities and ruggedness, originally developed for military use.

Jeep Patriot Introduction:

The Jeep Patriot was introduced for the 2007 model year as a compact SUV designed to offer Jeep's styling and some utility at a more accessible price point than the Wrangler or Cherokee.

Jeep Patriot Updates Pre 2017:

Received minor styling updates and interior improvements over its lifespan, including a facelift in 2011. The 2017 model year represented one of the final years for the Patriot before its discontinuation.

Manufacturing Location:

Belvidere, Illinois, USA

Production Run Years:

2007 - 2017

🏆 Awards & Recognition

Significant Awards Patriot:

The Jeep Patriot was not a recipient of major industry awards for performance, luxury, or innovation. Its market appeal was primarily driven by its price and utility, often earning it mention in 'budget SUV' or 'best value' lists rather than performance accolades.
