🏷️ Basic Information

Make:

Jeep

Model:

Patriot

Year Range:

2008-2012

Chassis Code:

MK (with many components shared with Dodge Caliber and Jeep Compass)

👋 Introduction

Segment:

Compact SUV / Crossover

Target Audience:

Budget-conscious consumers seeking an affordable, capable, and rugged-styled compact SUV.

Key Competitors:

Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Mitsubishi Outlander Sport

Design Philosophy:

Jeep's signature rugged styling and off-road capability (though limited in the Patriot compared to other Jeep models), combined with practicality and affordability.

Powertrain Options:

Offers efficient 4-cylinder engines and available all-wheel drive with advanced off-road capability (Freedom Drive II).

Benefit To Owner:

Empowers owners to perform DIY maintenance, repairs, and diagnostics, saving money and extending vehicle lifespan.

Professional Standard:

Provides the same level of detail and accuracy as manuals used by certified technicians.

📋 Manual Details

Geographic Coverage:

Global (as factory service manuals are typically standardized across markets, though regional variations may exist for emissions or specific features)

Vehicle Variants Covered:

All Patriot trims, 2WD and 4WD models

Estimated Page Count:

Hundreds (Exact count not specified, but typical factory manuals are extensive)

Type:

Factory Service Manual / Workshop Manual / Repair Manual

Language:

English (assumed based on product description and typical availability)

Format:

Digital (PDF)

📖 Manual Coverage

Powertrain:

Engine Mechanical, Engine Performance, Fuel System, Exhaust System, Cooling System, Lubrication System, Ignition System, Starting and Charging System

Transmission:

Manual Transmission (Getrag NV1500/NV3550), Automatic Transmission (CVT2/CVT2L - JF011E), Transaxle, Clutch System, Drivetrain, CV Joints, Axles, 4WD System (Freedom Drive I / Freedom Drive II)

Brakes:

Front Disc Brakes, Rear Disc Brakes, Parking Brake, ABS (Anti-lock Braking System), ESP (Electronic Stability Program), Brake System Bleeding and Service

Steering And Suspension:

Power Steering System, Steering Gear, Steering Linkage, Front Suspension, Rear Suspension, Wheel Alignment, Wheel Bearings

Electrical:

Battery, Charging System, Starting System, Ignition System, Lighting System (Headlamps, Taillamps, Interior Lights), Instrument Panel, Gauges, Warning Indicators, Body Control Module (BCM), Powertrain Control Module (PCM), HVAC Control Module, Audio System, Power Locks, Power Windows, Power Mirrors, Remote Keyless Entry, Wiper and Washer System, Horn

HVAC:

Air Conditioning System, Heater System, Ventilation System, Climate Control

Body:

Body Construction, Exterior Panels, Doors, Hood, Liftgate, Bumpers, Interior Trim, Seats, Glass, Mirrors, Weatherstripping

Diagnostic Procedures:

On-Board Diagnostics (OBD-II), Diagnostic Trouble Codes (DTCs), Symptom-Based Troubleshooting, Component Testing

Maintenance:

Oil Changes, Filter Replacements, Fluid Checks and Replacements, Tire Rotation, Brake Inspections, Spark Plug Replacement, Belt Replacement

Repair:

Engine Rebuilds, Transmission Overhauls, Brake Component Replacement, Suspension Component Replacement, Electrical Component Replacement, Body Panel Repair and Replacement, HVAC Component Repair

Troubleshooting:

Step-by-step diagnostic trees for common and complex issues across all vehicle systems

Specifications:

Torque specifications, diagnostic values, electrical schematics, fluid types and capacities, component dimensions

Depth:

Comprehensive (Factory level detail, covering diagnostics, repair, rebuilding, and specifications)

📊 Manual Specifications

File Type:

PDF

Searchability:

Searchable text (highly probable for factory manuals)

Printability:

Printable (Single pages or entire manual as stated)

Binding:

N/A (Digital format, user can bind physically)

Paper Quality:

N/A (Digital format, user determines print quality)

Usage License:

Lifetime, unlimited devices (as per product description)

⚙️ Engine Specifications

Engine Code:

2.4L GEMA (World Engine)

Displacement:

2358 cc (2.4 Liters)

Configuration:

Inline 4-Cylinder, DOHC, 16 Valves

Horsepower:

Approx. 172 hp @ 6000 rpm (varies slightly by year/market)

Torque:

Approx. 165 lb-ft @ 4400 rpm (varies slightly by year/market)

Fuel Induction:

Multi-Port Fuel Injection (MPI)

Cooling System:

Pressurized, liquid-cooled with thermostat and fan

Oil Capacity:

Approx. 4.5 quarts (4.3 Liters) with filter change (refer to manual for exact specification)

Recommended Oil Viscosity:

SAE 5W-20 (Refer to manual for specific OEM approval and conditions)

Engine Management System:

Chrysler's NGC (Next Generation Controller) or similar, with OBD-II diagnostics

Engine Code:

2.0L GEMA (World Engine)

Displacement:

1998 cc (2.0 Liters)

Horsepower:

Approx. 158 hp @ 6400 rpm

Torque:

Approx. 141 lb-ft @ 5000 rpm

🔧 Transmission

Type:

5-Speed Manual Transmission (Getrag NV1500)

Type:

Continuously Variable Transmission (CVT2) or CVT2L (with low range for Freedom Drive II)

Cv Fluid Type:

CVTF NS-2 or equivalent (Refer to manual for specific OEM recommendation)

Manual Transmission Fluid:

API GL-4, SAE 75W-90 (Refer to manual for specific OEM recommendation)

AWD System:

Freedom Drive I (full-time AWD with lock) or Freedom Drive II (full-time AWD with lock and low-range gearing for off-road)

📐 Dimensions

Length:

Approx. 174.4 inches (4430 mm)

Width:

Approx. 69.3 inches (1760 mm)

Height:

Approx. 63.7 inches (1618 mm)

Wheelbase:

Approx. 103.7 inches (2634 mm)

Ground Clearance:

Approx. 8.1 inches (206 mm) for Freedom Drive II equipped models

Cargo Volume Behind Rear Seat:

Approx. 23.4 cu ft (663 Liters)

Cargo Volume With Rear Seat Folded:

Approx. 62.7 cu ft (1776 Liters)

Curb Weight:

Approx. 3179 - 3488 lbs (1442 - 1582 kg) depending on configuration

Towing Capacity:

Approx. 1000 - 2000 lbs (454 - 907 kg) depending on engine and drivetrain (check local regulations and manual for specific limits)

🛡️ Safety Features

NHTSA Front Impact Rating:

5 Stars (for driver and front passenger in the 2008 model year)

IIHS Side Impact Rating:

Good (for the 2008 model year)

Standard Active Safety:

Four-wheel Anti-lock Brakes (ABS), Traction Control, Electronic Stability Control (ESC) / Brake Traction Control System (BTCS)

Standard Passive Safety:

Front advanced multi-stage airbags, Front seat-mounted side-impact airbags, Side curtain airbags (front and rear occupants)

Occupant Restraint System:

3-point seat belts with pretensioners and load limiters, LATCH child seat anchor system

💡 Technology Features

Available Systems:

Uconnect infotainment system with AM/FM radio, CD player, MP3 playback, auxiliary input jack. Optional SiriusXM Satellite Radio, navigation system, and Bluetooth connectivity.

Available Features:

Rear parking assist sensors (optional), tire pressure monitoring system (TPMS)

Connectivity Options:

Bluetooth streaming and hands-free calling (optional on select trims), USB port (on some models)

🔧 Maintenance

Engine Oil Change:

Every 6,000-10,000 miles (9,600-16,000 km) or 6-12 months, depending on driving conditions and oil type. Consult manual for specific recommendations.

Engine Air Filter:

Inspect every 15,000 miles (24,000 km), replace as needed or every 30,000 miles (48,000 km)

Cabin Air Filter:

Replace every 15,000-30,000 miles (24,000-48,000 km) or annually

Spark Plugs:

Replace approximately every 100,000 miles (160,000 km) with recommended type (e.g., Iridium)

Transmission Fluid Change:

CVT: Check periodically, replace as per severe service schedule (e.g., 60,000 miles / 96,000 km). Manual: Inspect periodically, change if contaminated or every 100,000 miles (160,000 km).

Coolant Replacement:

First replacement at 100,000 miles (160,000 km) or 5 years, then every 60,000 miles (96,000 km) or 5 years thereafter (using HOAT coolant)

Brake Fluid Flush:

Every 2-3 years or as per manual recommendations

Engine Oil:

SAE 5W-20 (API SN or higher, Chrysler MS-6395)

Coolant:

Mopar HOAT (Hybrid Organic Acid Technology) Antifreeze/Coolant, 50/50 mix (Chrysler spec MS-9769)

Brake Fluid:

DOT 3 or DOT 4 (Refer to manual for exact specification)

Cv Transmission Concerns:

Some CVT models have reported premature failure or issues with the transmission control module (TCM) or valve body, especially in early production years. Proper fluid maintenance is critical.

Suspension Components:

Front suspension components like ball joints and control arm bushings can experience wear over time, leading to noise and alignment issues.

Engine Oil Leaks:

Valve cover gaskets and oil pan gaskets can sometimes develop leaks on the 2.4L engine.

Heating System:

Blend door actuator failures in the HVAC system can lead to issues with temperature control or airflow direction.

Awe System Problems:

Rear axle seal leaks, particularly on AWD models, have been reported.

📚 Vehicle History

Jeep Legacy:

Jeep has a long-standing reputation for ruggedness, off-road capability, and durable vehicles since its inception in the 1940s. The Patriot aimed to bring some of that heritage to a more accessible compact SUV segment.

Platform:

Built on the Chrysler compact global platform (JS/MK), sharing components with the Dodge Caliber and Jeep Compass.

Introduction Year:

2007 (for the 2007 model year)

Key Updates 2008-2012:

Minor styling tweaks, interior enhancements, revised suspension tuning, and powertrain updates across the model run. Introduction of the 'High Altitude' edition and updates to infotainment systems.

Manufacturing Location:

Belvidere Assembly Plant, Illinois, USA

Production End Year:

2017

🏆 Awards & Recognition

IIHS Top Safety Pick:

The Jeep Patriot received 'Good' ratings in IIHS frontal and side crash tests for certain model years, indicating a solid safety structure for its class.
