Segment:
Compact SUV / Crossover
Target Audience:
Value-conscious consumers, light off-roading enthusiasts, urban dwellers
Key Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Kia Sportage, Hyundai Tucson
Brand Identity:
Jeep's rugged image and off-road capability, adapted for a compact package
Vehicle Attributes:
Affordability, practical interior, available 4WD (Freedom Drive II)
Manual Type:
Factory Service Repair Workshop Manual
Availability:
Downloadable PDF
Usage License:
Unlimited use on multiple devices, lifetime access, no expiry
Estimated Pages:
Hundreds (specific count not provided, but described as comprehensive)
Professional Equivalent:
Yes, same manual used by professional mechanics and technicians
Compatibility:
Windows and MAC computers, tablets, and smartphones
Engine:
Complete engine repair, diagnostics, and overhaul
Powertrain:
Transmission (automatic and manual), driveline, axles
Chassis:
Suspension, steering, brakes (hydraulic and ABS), wheels, and tires
Electrical:
Complete electrical system diagnostics, wiring diagrams, starter, alternator, battery, lighting, and accessories
Body:
Body panels, doors, glass, interior trim, exterior trim, HVAC system
Heating Cooling:
HVAC system operation, diagnosis, and repair, including A/C service
Exhaust Emissions:
Exhaust system components, catalytic converter, emissions control systems
Maintenance:
Regular servicing, oil changes, filter replacements, fluid checks and changes
Troubleshooting:
Comprehensive diagnostic procedures for all systems, common fault finding
Repair:
Step-by-step repair instructions for all components and systems
Installation:
Instructions for component replacement and installation
Rebuilding:
Detailed instructions for engine and transmission rebuilding
Depth:
Complete, from basic maintenance to advanced diagnostics and complete rebuilds
Illustrations:
Hundreds of detailed photos and diagrams, exploded views
Instructions:
Step-by-step instructions for all procedures
File Type:
PDF (Portable Document Format)
Printability:
Printable (single pages or entire manual)
Resolution:
High-resolution for clear viewing of text and images
Binding:
Digital (N/A for PDF, but reflects manual's intended use)
Paper Type:
Digital (N/A for PDF, but implies quality suitable for printing on standard paper)
Engine Code Gasoline 1:
GEMA (Global Engine Manufacturing Alliance) 2.0L I4
Displacement Gasoline 1:
1998 cc (122 cubic inches)
Bore X Stroke Gasoline 1:
83.0 mm x 92.0 mm (3.27 in x 3.62 in)
Compression Ratio Gasoline 1:
9.5:1
Horsepower Gasoline 1:
158 hp @ 6400 rpm
Torque Gasoline 1:
141 lb-ft @ 5000 rpm
Engine Code Gasoline 2:
GEMA (Global Engine Manufacturing Alliance) 2.4L I4 (World Engine)
Displacement Gasoline 2:
2360 cc (144 cubic inches)
Bore X Stroke Gasoline 2:
88.0 mm x 97.0 mm (3.46 in x 3.82 in)
Compression Ratio Gasoline 2:
9.5:1
Horsepower Gasoline 2:
172 hp @ 6000 rpm
Torque Gasoline 2:
165 lb-ft @ 4400 rpm
Fuel Delivery:
Multi-point Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline (87 octane recommended)
Emission Control:
Catalytic converter, On-Board Diagnostics (OBD-II)
Transmission Type Gasoline 1:
5-Speed Manual Transmission (Getrag NV1555 / MTX75)
Transmission Type Gasoline 1 Optional:
Continuously Variable Transmission (CVT) - Autostick (CVT2)
Transmission Type Gasoline 2:
CVT2 (Continuously Variable Transmission) - Autostick
Drivetrain:
Front-Wheel Drive (FWD) standard; All-Wheel Drive (AWD) optional (Freedom Drive I or II)
Freedom Drive Ii Package:
Includes AWD with low-range gearing and increased ground clearance
Manual Transmission Fluid Spec:
API GL-4 SAE 75W-90 (specific Mopar or equivalent)
Cv Transmission Fluid Spec:
Mopar CVT Fluid NS-2 or equivalent (refer to manual for exact type and capacity)
Length:
168.9 in (4290 mm)
Width:
69.1 in (1755 mm) (excluding mirrors)
Height:
63.9 in (1623 mm) (FWD) / 64.2 in (1631 mm) (AWD)
Wheelbase:
103.0 in (2616 mm)
Ground Clearance:
7.8 in (198 mm) (FWD) / 8.1 in (206 mm) (Freedom Drive II)
Curb Weight Est:
3100 - 3400 lbs (approximate, varies by trim and drivetrain)
Towing Capacity:
Up to 2000 lbs (when properly equipped with towing package)
NHTSA Overall Rating:
4/5 Stars (for 2016 model, review specific year/configuration for details)
Braking System:
Four-wheel disc brakes with Anti-lock Braking System (ABS)
Electronic Stability:
Electronic Stability Control (ESC), Traction Control (TCS), Electronic Roll Mitigation (ERM)
Airbags:
Frontal, side-curtain, and front-seat side airbags
Infotainment System:
Uconnect infotainment system with touchscreen display (various sizes depending on trim)
Connectivity Options:
Bluetooth connectivity for hands-free calling and audio streaming, USB ports, auxiliary input
Navigation:
Optional navigation system
Backup Camera:
Optional rearview backup camera
Tire Pressure:
Tire Pressure Monitoring System (TPMS)
Oil Change Interval:
Every 6,000 to 8,000 miles or 6 to 12 months, depending on driving conditions (refer to manual for specific recommendation)
Engine Air Filter Replacement:
Approximately every 30,000 miles or as needed based on inspection
Cabin Air Filter Replacement:
Approximately every 15,000 to 20,000 miles or annually
Spark Plug Replacement:
Around 100,000 miles (Platinum or Iridium type)
Engine Oil Capacity:
2.0L: 4.5 quarts (4.3 L) / 2.4L: 5.0 quarts (4.7 L) (with filter, refer to manual for exact capacity)
Engine Oil Type:
SAE 5W-20 (MS-6395 certified)
Coolant Type:
Mopar OAT (Organic Acid Technology) Antifreeze/Coolant, HOAT or equivalent (pink or orange color)
Brake Fluid Type:
DOT 3 or DOT 4 (check manual for specific recommendation)
Cv Transmission:
CVT failures can occur, often related to fluid degradation or overheating. Regular fluid changes are critical.
Suspension Components:
Early wear on suspension components like control arms and bushings can lead to clunking noises or alignment issues.
Power Steering:
Occasional reports of power steering pump or rack issues.
Heating And Cooling:
HVAC blower motor resistor failures are not uncommon, affecting fan speed control.
