Body Style:
2-door (JKU) and 4-door Unlimited (JK)
Model Trims:
Sport, Sahara, Rubicon, (and variations thereof, e.g., Altitude, Arctic, etc.)
Generation Years:
2007-2018
Covered Years:
2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018
Target Audience:
Jeep Wrangler JK owners, DIY enthusiasts, independent repair shops, and professional technicians.
Manual Advantage:
Provides factory-level detail and specific coverage, unlike generic repair guides. Offers a comprehensive, all-in-one digital solution.
Unique Selling Points:
Exact same manual used by dealership technicians, step-by-step instructions, diagrams, illustrations, wiring schematics, complete A-Z coverage, printable, searchable PDF format.
Manual Scope:
Complete Workshop Service and Repair Manual for all JK models and all repairs A-Z
Estimated Page Count:
Extensive (specific count not provided, but described as comprehensive)
Manual Type:
Workshop Service Repair Manual
Manual Source:
Factory-authorized or equivalent dealer service manual.
Platform Compatibility:
Windows, Mac
Powertrain:
Engine (all aspects), Fuel Service Specifications, Emission Control, Intake/Exhaust/Cooling, Lube, Ignition, Starting, Charging, Automatic Transmission, Clutch, Manual Transmission, Transfer Case, Propeller Shaft, Drive Shaft, Differential, Axle
Chassis:
Suspension, Tire & Wheel, Brake Control, Brakes, Parking Brake, Steering Column, Power Steering
Body Electrical HVAC:
Air Conditioning, Supplemental Restraint System (SRS), Seat Belts, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Locks, Meter/Audio/Visual, Horn, Windshield/Glass/Mirror, Instrument Panel, Seats, Engine Hood/Doors, Exterior & Interior Trim, Electrical Systems, Multiplex/CAN Communication
Maintenance:
Scheduled maintenance, fluid checks and changes, filter replacements
Repair Diagnostics:
Step-by-step repair instructions, troubleshooting guides, diagnostic procedures, component removal and installation
Technical Data:
Detailed specifications, torque values, diagnostic trouble codes (DTCs), wiring schematics, component diagrams
Wiring Schematics:
Comprehensive wiring diagrams for all electrical systems, crucial for troubleshooting and repair.
Diagnostic Procedures:
Includes specific diagnostic trees and symptom-based troubleshooting steps.
Depth Of Coverage:
Factory-level, dealer technician accuracy, covering everything from basic maintenance to complex system diagnostics and repairs.
Printability:
Fully printable, allowing users to print specific pages or sections as needed.
Image Resolution:
High-resolution images and diagrams, with the ability to enlarge for detailed viewing.
Binding:
Digital (PDF) - No physical binding, offering flexibility.
Paper Description:
N/A (Digital format - print as needed on user's chosen paper type).
Engine Code:
3.8L V6 (2010-2011), 3.6L V6 Pentastar (2012-2018)
Engine Displacement 3.8L:
3.8 Liters (230.5 cu. in.)
Horsepower 3.8L:
Approx. 202 hp @ 5200 rpm
Torque 3.8L:
Approx. 237 lb-ft @ 4000 rpm
Engine Displacement 3.6L:
3.6 Liters (220.5 cu. in.)
Horsepower 3.6L:
Approx. 285 hp @ 6400 rpm
Torque 3.6L:
Approx. 260 lb-ft @ 4800 rpm
Engine Block Material:
Aluminum Alloy (3.6L Pentastar), Cast Iron (3.8L)
Valvetrain:
Overhead Valve (OHV) for 3.8L, Dual Overhead Camshaft (DOHC) with Variable Valve Timing (VVT) for 3.6L
Fuel Delivery:
Multi-port Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline (87 octane recommended, higher recommended for optimal performance)
Transmission Type Standard:
6-speed Manual Transmission (NSG 370)
Transmission Type Optional:
5-speed Automatic Transmission (W5A580)
Transfer Case:
Command-Trac NV241G (Standard), Rock-Trac NV241OR (Optional on Rubicon models)
Gear Ratios Manual:
Specific gear ratios for the NSG 370 are detailed in the manual.
Gear Ratios Automatic:
Specific gear ratios for the W5A580 are detailed in the manual.
Wheelbase 2-Door:
Approx. 95.4 inches (2423 mm)
Wheelbase 4-Door:
Approx. 116 inches (2947 mm)
Ground Clearance:
Varies by model and tire size, typically 9.5-10.1 inches (241-257 mm)
Approach Angle:
Varies by model, typically around 42.2 degrees (2-door) and 37.4 degrees (4-door).
Departure Angle:
Varies by model, typically around 37.2 degrees (2-door) and 32.5 degrees (4-door).
Breakover Angle:
Varies by model, typically around 22.6 degrees (2-door) and 21.1 degrees (4-door).
Curb Weight:
Approx. 4,000 - 4,500 lbs (1814 - 2041 kg), varies by configuration.
NHTSA Overall Rating:
Generally good for its class, but varies by model year and specific tests. Consult NHTSA for exact ratings.
Active Safety:
Electronic Stability Control (ESC), Traction Control (TC), Anti-lock Braking System (ABS), Hill Start Assist (HSA)
Brake System:
Front ventilated disc brakes, rear solid disc brakes with ABS.
Passive Safety:
Front airbags, optional side curtain airbags (availability varies by model year and trim).
Infotainment Options:
Various Uconnect systems available depending on trim and model year, featuring touchscreens, navigation (optional), SiriusXM Satellite Radio, and Bluetooth connectivity.
Audio System:
Available premium audio systems with subwoofer, depending on trim level.
Driver Assistance Features:
Limited in base models; higher trims may offer rear backup camera. Primarily focused on core driving and off-road functionality.
Connectivity Features:
Bluetooth streaming audio and hands-free calling, USB ports.
Oil Change Interval:
Every 6,000 miles or 6 months, whichever comes first (for synthetic blend or full synthetic oil). Check manual for specific recommendations.
Tire Rotation Interval:
Every 6,000 - 7,500 miles.
Transmission Fluid Change:
Automatic: 60,000-100,000 miles depending on driving conditions. Manual: Check manual, often longer intervals or as needed.
Engine Oil Spec:
SAE 5W-30 (for both 3.8L and 3.6L engines, consult manual for exact API service classification and Chrysler specifications like MS-6395).
Coolant Spec:
Mopar OAT (Orange) Antifreeze/Coolant, 10 Year/150,000 Mile Formula, or equivalent meeting Chrysler MS-90032.
Transmission Fluid Auto:
Mopar ATF+4 (MS-9602) or equivalent.
Transmission Fluid Manual:
Mopar Manual Transmission Lubricant (MS-9224) or equivalent SAE 75W-90 synthetic.
Brake Fluid Spec:
DOT 3 or DOT 4 brake fluid.
Differential Fluid Spec:
API GL-5, SAE 75W-140 synthetic gear lubricant (for front and rear differentials, including limited-slip if equipped).
Transfer Case Fluid Spec:
Mopar NV241G Transfer Case Fluid or equivalent Mopar ATF+4 or Dexron III H.
Common Wear Items:
Clutch wear (manual transmission), tie rod ends, ball joints, axle seals, ball stud for hood latch.
Electrical Concerns:
Water intrusion into TIPM (Total Integrated Power Module) can cause various electrical gremlins. Power window motor failures.
Powertrain Concerns:
Oil filter housing leaks (3.6L Pentastar), potential for exhaust manifold cracks (3.6L Pentastar).
Steering Components:
Potential for premature wear in steering components due to off-road use and steering geometry.
Jeep Legacy:
Rooted in military utility vehicles, the Jeep brand is synonymous with off-road capability and ruggedness.
Jk Generation Launch:
The JK generation was introduced for the 2007 model year, representing a significant redesign from its TJ predecessor with a longer wheelbase option (Unlimited) and updated styling.
Manufacturing Plant:
Toledo South Assembly Plant, Toledo, Ohio, USA
