Model:
Brute Force 750 4x4i
Applicable Years:
2008, 2009, 2010, 2011
Covered Models:
KVF750D8F, KVF750E8F, KVF750E8FA, KVF750F8F, KVF750D9F, KVF750E9F, KVF750E9FA, KVF750DAF, KVF750EAF, KVF750FAF, KVF750DBF, KVF750EBF, KVF750FBF
Vin Decoder Reference:
Service manual will provide VIN decoding information relevant to these model years and variants.
Generation Identifier:
This service manual covers a specific generation of the Brute Force 750 4x4i, likely the second generation (2008-2011) which introduced significant updates.
Positioning:
The Kawasaki Brute Force 750 4x4i is a flagship ATV in its class, known for its powerful V-twin engine and advanced 4x4 capabilities, targeting serious recreational riders and utility users.
Competitors:
Competes with other premium utility ATVs from manufacturers such as Honda (FourTrax Foreman/Rancher), Yamaha (Grizzly), and Polaris (Sportsman).
Features Highlighted By Manual:
Emphasis on comprehensive coverage for the 749cc V-twin engine, advanced DFI system, robust 4x4 drivetrain, and a comfortable riding experience, all detailed within the manual.
Manual Benefit:
Provides dealership-level technical information for DIY repairs and maintenance, saving owners significant costs and empowering them to maintain their vehicle effectively.
Systems Covered:
General information, periodic maintenance, fuel system (DFI), cooling system, engine top end, converter system, engine lubrication system, engine removal/installation, crankshaft/transmission, wheels/tires, final drive, brakes, suspension, steering, frame, electrical system, appendix.
Estimated Page Count:
Actual page count not specified, but professional service manuals typically range from 500 to over 1000 pages for comprehensive coverage.
Type:
Service Repair Manual
Format:
PDF (Portable Document Format)
Engine:
Detailed coverage of the 749cc liquid-cooled, 4-stroke, V-twin engine, including top end, lubrication, and removal/installation.
Fuel System:
Comprehensive information on the Digital Fuel Injection (DFI) system, including component testing, calibration, and troubleshooting.
Drivetrain:
In-depth coverage of the converter system (CVT), transmission, and final drive mechanisms, including internal components and servicing.
Suspension Steering:
Detailed procedures for front and rear suspension systems, including shocks, springs, and bushings, as well as steering components and alignment.
Brakes:
Complete brake system service, including hydraulic components, disc brakes, and bleeding procedures.
Electrical:
Extensive electrical system coverage, including wiring diagrams, component testing, ignition system, lighting, and accessories.
Maintenance:
All periodic maintenance tasks, from basic oil changes and filter replacements to more complex inspections and adjustments.
Diagnostics:
Troubleshooting guides and diagnostic procedures for common and complex issues across all vehicle systems.
Repair Rebuild:
Step-by-step repair and overhaul instructions for major components, including engine internals, transmission, and suspension.
Troubleshooting Guides:
Includes diagnostic flowcharts and symptom-based troubleshooting for engine, electrical, and mechanical issues.
Depth:
Professional-grade technical depth, suitable for both experienced mechanics and knowledgeable DIY enthusiasts. Features detailed diagrams and clear instructions for complex repairs.
Compatibility:
All versions of Windows & Mac
Requirements:
Adobe PDF Reader & WinZip
Quality:
High resolution, ensuring clear and crisp printed pages.
Type:
Digital Download (PDF). User can print and bind as needed.
Recommendation:
Not applicable (digital product). High-quality printing is achievable on standard or premium paper.
Searchability:
PDF format with searchable text allows for quick location of specific information.
Delivery Method:
Instant download after payment confirmation.
Engine Type:
Liquid-cooled, four-stroke, V-twin, SOHC, 4 valves per cylinder
Bore X Stroke:
85.0 x 66.0 mm
Fuel Delivery:
DFI (Digital Fuel Injection) with dual 36mm Keihin throttle bodies
Ignition:
TCBI (Transistor Controlled Ignition) with digital advance
Lubrication System:
Forced lubrication, wet sump
Overall Length:
Approx. 82.1 in (2,085 mm)
Overall Width:
Approx. 47.8 in (1,215 mm)
Overall Height:
Approx. 49.2 in (1,250 mm)
Wheelbase:
Approx. 50.6 in (1,285 mm)
Curb Weight:
Approx. 624 lbs (283 kg) - Varies slightly by model variant
Towing Capacity:
1,500 lbs (680 kg)
Cargo Capacity Front Rack:
110 lbs (50 kg)
Cargo Capacity Rear Rack:
198 lbs (90 kg)
Atv Classification:
Category 1: Utility ATV
Braking System:
Front: Dual sealed, oil-bathed multi-disc brakes; Rear: Sealed, oil-bathed multi-disc brake. Manual covers detailed inspection and maintenance.
Engine Braking:
Effective engine braking provided by the CVT system, detailed in the manual.
Frame Construction:
Steel tubing frame, with frame integrity and repair covered in the manual.
Dashboard Display:
Digital multi-function meter including speedometer, odometer, trip meter, clock, fuel gauge, 2WD/4WD indicator, and 4WD diff-lock indicator.
4Wd System Features:
Variable Tension Control (VTC) 4WD system enhances traction and maneuverability, with technical details on its operation in the manual.
Charging System:
12V DC accessory outlet (location and rating specified in manual) for charging devices.
Oil Change Engine:
Refer to manual for specific mileage/hour intervals, typically around 1000 miles or 6 months. Manual will detail specific oil viscosity and capacity.
Air Filter Cleaning Replacement:
Regular inspection and cleaning/replacement recommended, especially in dusty conditions. Manual provides precise intervals and procedures.
Spark Plug Replacement:
Recommended at specific mileage or time intervals. Manual will specify plug type and gap.
Engine Oil:
Manual specifies SAE 10W-40 API SG or higher, synthetic recommended. Capacity typically around 2.3 US qt (2.2 L) with filter change. Exact specification in manual.
Gear Oil Final Drive:
Manual specifies specific hypoid gear oil, e.g., SAE 80W-90 API GL-5. Capacity detailed for front and rear differentials.
Coolant:
Manual specifies a permanent type antifreeze (ethylene glycol based) with corrosion inhibitor, typically a 50/50 mix with distilled water. Capacity around 2.6 US qt (2.5 L).
Common Wear Items:
CVT belt wear, suspension bushings, and brake pad wear are common items addressed by this manual's procedures.
Fuel System Maintenance:
DFI system may require occasional cleaning of injectors and throttle bodies, with detailed procedures in the manual.
Kawasaki Atv Legacy:
Kawasaki has a long-standing reputation in the powersports industry, including a significant presence in the ATV market with the Brute Force line known for its power and durability.
Brute Force 750 Updates:
The 2008 model year marked a significant update for the Brute Force 750 4x4i, often referred to as the second generation, featuring chassis and engine refinements over its predecessor.
Manufacturing Location:
Kawasaki ATVs are typically manufactured in Lincoln, Nebraska, USA.
