Kawasaki Engine WorkShop Service Repair Manual FH451V FH500V FH531V FH541V FH580V FH601V FH641V FH661V FH680V FH721V

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Kawasaki Model: FH451V, FH500V, FH531V, FH541V, FH580V, FH601V, FH641V, FH661V, FH680V, FH721V Engine Type: 4-Cycle Gasoline Engine Engine Configuration: Vertical Shaft, Overhead Valve, Forced Air...

19 people are viewing this right now

类型: Engine

斯库: 14894

标签: Datsun Engine Engines FH451V FH500V FH531V FH541V FH580V FH601V FH641V FH661V FH680V FH721V Kawasaki Tune Up Workshop Repair & Servic

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Kawasaki

Model:

FH451V, FH500V, FH531V, FH541V, FH580V, FH601V, FH641V, FH661V, FH680V, FH721V

Engine Type:

4-Cycle Gasoline Engine

Engine Configuration:

Vertical Shaft, Overhead Valve, Forced Air Cooled

📋 Manual Details

Document Information

Manual Type:

Workshop Service Repair Manual

Language:

English

Page Count:

Format:

PDF Download

Sections Included:

General Information, Periodic Maintenance, Fuel System, Cooling System, Engine Top End, Lubrication System, Camshaft Crankshaft, Starter System, Electrical System, Troubleshooting

⚙️ Engine Specifications

General

Bore Stroke Range:

Specific to each model (e.g., FH451V: 74 x 71.5 mm, FH721V: 82 x 71.5 mm)

Displacement Range:

Specific to each model (e.g., FH451V: 449cc, FH721V: 726cc)

Compression Ratio Range:

Typically around 8.0:1 to 8.5:1

Performance

Power Output Range:

Specific to each model (e.g., FH451V: 15 HP, FH721V: 23.5 HP)

Torque Range:

Specific to each model

🔧 Maintenance

Lubrication

Recommended Oil Type:

Kawasaki Genuine Engine Oil or equivalent SAE 10W-30, 10W-40, or 20W-50 (depending on ambient temperature)

Oil Capacity Range:

Typically 1.6 L to 2.2 L (without filter change)

Periodic Checks

Spark Plug Gap:

0.024-0.028 in (0.6-0.7 mm)

Valve Lash Clearance:

Intake: 0.10-0.15 mm, Exhaust: 0.15-0.20 mm (Cold)

📄 Engine Features

Ignition

Ignition System:

Digital Electronic Ignition

Fuel System

Fuel Delivery:

Carburetor (specific type varies by model)

Cooling System

Cooling Method:

Forced Air Cooling

Starting System

Starting Method:

Electric Starter

Exhaust

Muffler Type:

Standard Spark Arrestor Muffler

Flywheel

Flywheel Brake:

Governor

Governor Type:

Mechanical Centrifugal Governor
