Category:
Sport Touring Motorcycle
Key Selling Points:
Long-distance comfort, powerful engine, advanced technology, stable handling
Primary Competitors:
BMW R1250RT, Honda ST1300, Yamaha FJR1300
Ergonomics:
Upright riding position, adjustable windscreen, comfortable seating for rider and passenger
Performance Focus:
High-performance engine with strong torque for effortless cruising and acceleration
Technology Integration:
ABS, often integrated braking systems, advanced fuel injection
Owner Benefits:
Empowers owners to maintain their investment, reduce service costs, and understand their machine's intricacies
Primary Coverage:
Comprehensive repair and maintenance
Specific Systems:
Engine, fuel system, cooling system, transmission, chassis, suspension, brakes, electrical system, bodywork, accessories
Estimated Page Count:
High (typically 500+ pages for this level of detail)
Type:
Official Factory Service Manual
Format:
Digital Download (PDF)
Engine Mechanical:
Engine assembly, disassembly, valve clearance, camshafts, pistons, crankshaft, oil pump, lubrication system, timing chain
Fuel System:
Fuel injection system (EFI), throttle body, fuel pump, injectors, fuel pressure regulator, evaporative emission control (EVAP)
Cooling System:
Radiator, cooling fan, thermostat, water pump, coolant flow, maintenance
Transmission Drivetrain:
Clutch operation, gearbox, final drive (shaft drive), lubrication, disassembly, assembly
Suspension Steering:
Front fork (inversion, damping, springs), rear shock absorber, linkage, steering system, wheel bearings
Brakes:
Front and rear disc brakes, caliper service, master cylinders, brake fluid, ABS system (including hydraulic unit, sensors, control module diagnosis)
Electrical System:
Battery, charging system (alternator, regulator/rectifier), starting system (starter motor), ignition system (ECU, ignition coils), lighting, instrumentation, horn, sensors, wiring diagrams
Bodywork Frame:
Fairing removal and installation, fuel tank, seat, body panels, frame inspection, subframe
Accessories:
Adjustable windscreen, pannier mounting, potential factory options integration
Routine Maintenance:
Oil changes, filter replacements, air filter cleaning/replacement, spark plug replacement, chain adjustment (if applicable, though GTR is shaft-driven), fluid checks and changes
Troubleshooting:
Diagnostic procedures, fault code interpretation (if applicable via diagnostic tool), symptom-based troubleshooting guides
Major Repairs:
Engine rebuilds, transmission overhaul, suspension component replacement, brake system bleeding and component replacement, electrical component diagnosis and replacement
Adjustments:
Clutch adjustment, throttle cable adjustment, idle speed adjustment, suspension setup
Special Tools:
Listing of required or recommended special tools for specific procedures
Depth:
Comprehensive, from basic rider maintenance to advanced mechanical and electrical repairs
Diagnostic Level:
Detailed diagnostics for all major systems, including electrical and ECU-related issues
Rebuild Procedures:
Complete engine, gearbox, and major component overhaul procedures with torque specifications and tolerances
Engine Type:
Liquid-cooled, 4-stroke, DOHC, 16-valve Inline-Four
Displacement:
1,352 cc (82.5 cu. in.)
Bore X Stroke:
84.0 x 61.0 mm
Compression Ratio:
11.0:1
Horsepower:
Approx. 153 HP @ 8,800 rpm (claimed)
Torque:
Approx. 102 lb-ft @ 6,200 rpm (claimed)
Fuel Delivery:
Digital Fuel Injection (DFI) with Keihin throttle bodies
Fuel Type:
Unleaded premium gasoline (91 octane or higher recommended)
Oil Type:
SAE 10W-40 API SG or SH, or motorcycle-specific synthetic oil
Oil Capacity:
Approx. 4.0 L (4.2 US qt) without filter change, 4.3 L (4.5 US qt) with filter change
Ignition System:
Digital CDI with electronic advance
Coolant Type:
Permanent anti-freeze (50/50 mixture of ethylene glycol and distilled water)
Crash Test Data:
Motorcycle safety ratings are not typically standardized like automobiles. Focus is on design features.
ABS:
Anti-lock Braking System (standard on ABS models, optional on some markets for standard models).
Linked Braking:
Unified Braking System (UBS) - applying one brake lever actuates the other brake to some degree, enhancing stability.
Traction Control:
Not typically featured on this model year range.
Lighting:
Halogen headlights, LED taillight and brake light.
Frame Structure:
Monocoque frame for rigidity and weight distribution.
Audio System:
Some models may have integrated audio systems, often controlled via handlebar switches. Manual covers basic functions and troubleshooting.
ABS Integration:
Comprehensive ABS system diagnostics and repair procedures are a key part of the manual's electrical coverage.
Diagnostics:
The manual provides wiring diagrams and diagnostic procedures to support understanding of the ECU and sensor network.
Headlight Type:
Dual Halogen headlights, providing excellent nighttime visibility.
Dashboard Features:
Analog tachometer and speedometer, multi-function LCD display with fuel gauge, gear indicator, clock, trip meters, and warning lights.
First Service:
Typically around 600 miles (1,000 km) - includes oil change, filter, inspection.
Routine Maintenance Intervals:
Oil changes every 3,000-4,000 miles (5,000-6,000 km) or annually. Valve checks every 15,000-20,000 miles (24,000-32,000 km). Refer to the manual for precise intervals.
Air Filter Maintenance:
Inspect every 7,500 miles (12,000 km), clean or replace as needed.
Spark Plug Replacement:
Typically every 15,000-20,000 miles (24,000-32,000 km).
Engine Oil Spec:
SAE 10W-40 API SG or SH, or JASO MA approved motorcycle oil.
Brake Fluid Spec:
DOT 4 brake fluid.
Cooling Fluid Spec:
50/50 mixture of ethylene glycol and distilled water.
Final Drive Oil Spec:
API GL-4 SAE 80W-90 hypoid gear oil.
Common Wear Items:
Tires, brake pads, clutch plates (high mileage), suspension seals.
Potential Electrical Quirks:
Some owners report minor electrical glitches, often resolvable with proper diagnosis detailed in the manual.
Engine Performance Notes:
Known for smooth power delivery; maintain proper cooling and lubrication for longevity.
