Welcome to the comprehensive service manual for the VN1700 Voyager, including the VN1700 Voyager ABS model, covering production years 2009 through 2012. This full-fairing touring motorcycle is engineered for comfortable long-distance travel, featuring a robust V-twin engine, advanced electronic cruise control, and an integrated audio system. Built upon a strong heritage in performance and reliability, the VN1700 Voyager offers a premium riding experience, combining powerful performance with extensive touring amenities. Its design prioritizes rider comfort and cargo capacity, making it an ideal choice for extended journeys.
This complete factory service repair manual provides detailed, step-by-step instructions for maintaining and repairing your VN1700 Voyager. It covers all essential systems, including the engine, fuel system, cooling system, clutch, transmission, chassis, brakes, suspension, steering, and electrical systems. With hundreds of pages, including numerous photos and illustrations, this manual is an invaluable resource for do-it-yourself enthusiasts and professional mechanics alike. It facilitates routine maintenance, troubleshooting, and in-depth repairs, ensuring your motorcycle remains in optimal working condition and helping you save on service costs.
Model Designation:
Voyager ABS
Body Style:
Full-fairing Touring Motorcycle
Generation Code:
VN1700 Gen 1
Engine Family Code:
Not specified
Target Audience:
Do-it-yourselfers and experienced mechanics for Kawasaki VN1700 Voyager owners.
Value Proposition:
Inexpensive way to keep vehicle working properly, save money on mechanic costs, empowering owners to perform repairs.
Comparison To Print:
Superior to old paper repair manuals in convenience and cost-effectiveness.
Completeness:
COMPLETE official full factory service repair manual, no extra fees, no expiry dates.
Content Advantage:
Hundreds of pages of detailed information, step-by-step instructions, photos, and illustrations.
Convenience:
Digital format, printable, accessible on multiple devices, saves time and prevents manual wear and tear.
Years Covered:
2009, 2010, 2011, 2012
Models Covered:
VN1700 Voyager, VN1700 Voyager ABS
Trim Levels Covered:
All styles covered
Page Count Estimate:
Hundreds of pages
Type:
Complete Official Full Factory Service Repair Manual / Workshop Manual
Digital Delivery:
Speed Download
Accessibility:
Compatible with all Windows and Mac versions, smartphones, and tablets; accessible via web browser.
Engine Systems:
Fuel system, cooling system, engine top end, clutch, engine lubrication system, engine removal/installation, crankshaft, transmission
Chassis Systems:
Wheels/tires, final drive, brakes, suspension, steering, frame
Electrical Systems:
Electrical system
Ancillary Systems:
General information, Appendix
Maintenance:
Standard maintenance procedures, scheduled maintenance
Repair:
Step-by-step repair instructions based on complete disassembly
Troubleshooting:
Implied through detailed diagnostic information
Diagnostics:
Detailed procedures for diagnosing issues
Depth:
Comprehensive, suitable for do-it-yourselfers and experienced mechanics
Detail Level:
Hundreds of photos and illustrations included to guide through service and repair procedures.
Required Software:
Adobe PDF Reader, Winzip (free online)
Printability:
Yes, printable pages
Page Management:
Print in its entirety or just the pages you need.
Binding:
N/A (Digital PDF format)
Paper Type:
N/A (Digital PDF format)
Engine Type:
V-Twin, 4-stroke, SOHC, 8-valve
Displacement:
1700cc (103.6 cu. in.)
Bore X Stroke:
81.0 x 83.0 mm
Cooling System:
Liquid-cooled
Fueling:
Fuel Injection, Dual 40mm throttle bodies
Horsepower:
Approximately 93 hp @ 5700 rpm (manufacturer specification may vary slightly)
Torque:
Approximately 107 lb-ft @ 3500 rpm (manufacturer specification may vary slightly)
Fuel Type:
Unleaded gasoline, minimum 87 octane
Fuel Tank Capacity:
5.3 gal (20.0 L)
Transmission Type:
6-speed
Clutch Type:
Wet, multiple-disc
Overall Length:
101.6 in (2580 mm)
Overall Width:
38.8 in (985 mm)
Overall Height:
59.3 in (1505 mm)
Curb Weight:
851 lb (386 kg)
Dry Weight:
N/A (typically higher than curb weight for touring models)
Wheelbase:
64.0 in (1625 mm)
ABS:
Available (Voyager ABS model)
Braking System:
Dual 300mm front discs with 4-piston calipers, Single 300mm rear disc with 2-piston caliper.
Lighting:
Halogen headlights, LED taillight, integrated front and rear turn signals.
Frame Construction:
Steel, double-cradle
Audio System:
Integrated audio system with AM/FM radio and iPod/iPhone connectivity (features vary by market and specific model year).
Cruise Control:
Electronic cruise control
Dashboard Display:
Multi-function LCD display with analog speedometer and tachometer, gear position indicator, fuel gauge, clock, and diagnostic indicators.
ABS:
Anti-lock Braking System (ABS) available on specific models for enhanced stopping control.
Usb Port:
Available USB port for charging and/or audio input (verify model specifics).
Oil Change Interval:
Typically every 3,700 miles or 6 months (refer to manual for exact specification).
Valve Adjustment Interval:
Typically every 7,500 miles or 12 months (refer to manual for exact specification).
Spark Plug Replacement:
Typically every 7,500 miles or 12 months (refer to manual for exact specification).
Engine Oil Type:
SAE 10W-40 API SG or SH, JASO MA (refer to manual for exact specification).
Coolant Type:
Kawasaki genuine coolant or equivalent (50/50 mixture of ethylene glycol based coolant and distilled water).
Brake Fluid Type:
DOT 4 (refer to manual for exact specification and ABS system considerations).
Common Wear Items:
Brake pads, tires, clutch plates, drive belt.
Potential Electrical Concerns:
Intermittent issues with stator or voltage regulator (common on many liquid-cooled V-twins, refer to manual for diagnosis).
Fuel System Maintenance:
Regular cleaning of throttle bodies and fuel injectors as per service schedule.
