Target Audience:
DIY enthusiasts, independent repair shops, and dealership technicians
Advantage:
Provides exact same information used by dealership technicians, offering superior accuracy and detail over generic repair guides.
Data Source:
Official factory service information, mirroring dealership documentation
Instruction Style:
Step-by-step guides with comprehensive diagrams, illustrations, and wiring schematics
Format Benefit:
Single, easy-to-use PDF manual, eliminating the need to search through multiple physical books; printable pages for workshop use.
Engine Mechanical:
Engine assembly, cylinder head, block, pistons, connecting rods, crankshaft, camshafts, timing system, lubrication, cooling, intake, exhaust
Engine Fuel System:
Fuel injection system, fuel pump, fuel filter, injectors, fuel rail, high-pressure fuel pump (GDI)
Engine Ignition System:
Ignition coils, spark plugs, ignition timing
Engine Emission Control:
Catalytic converter, oxygen sensors, EVAP system
Engine Management:
ECU, sensors (MAF, MAP, TPS, CMP, CKP, knock), actuators, diagnostic trouble codes (DTCs)
Maintenance:
Scheduled maintenance, fluid checks and changes, filter replacements, belt inspections
Troubleshooting:
Diagnostic procedures, symptom analysis, common problem identification
Repair:
Step-by-step repair instructions for all engine components
Diagnostics:
On-board diagnostics (OBD-II), reading and interpreting DTCs, using diagnostic tools
Depth:
Comprehensive, factory-level detail covering maintenance, diagnosis, repair, and overhaul.
Printability:
Full Printable. Allows users to print specific pages or entire sections.
Binding:
Digital (No physical binding)
Paper Quality:
N/A (Digital content, printable on user's choice of paper)
Reader Requirements:
Adobe PDF Reader
Compression Requirements:
WinZip or equivalent archive utility
Operating Systems:
Compatible with all versions of Windows and Mac
Zoom Functionality:
Yes, zoom in/out for detailed viewing of diagrams and images
Engine Code:
G6DH (commonly associated with 3.3L GDI)
Engine Type:
Naturally Aspirated V6, Gasoline Direct Injection (GDI)
Displacement:
3.3 Liters (3342 cc)
Bore X Stroke:
94.0 mm x 80.5 mm (typical for this engine family)
Compression Ratio:
12.0:1 (typical for this engine)
Horsepower:
Approximately 293 hp @ 6400 rpm (for 2014 model)
Torque:
Approximately 255 lb-ft @ 5300 rpm (for 2014 model)
Fuel Delivery:
Direct Injection (GDI)
Fuel Type:
Unleaded Gasoline
Fuel Pressure Gdi:
High pressure system (specific values detailed in manual)
Coolant Type:
Antifreeze coolant (Ethylene Glycol based, specific Kia specification required, e.g., MS591-08)
Oil Type:
SAE 0W-30 Synthetic Oil (Kia Specification MS591-08 or equivalent API SN/ILSAC GF-5)
Oil Capacity:
Approximately 6.9 US Quarts (6.5 Liters) with filter change
Timing Mechanism:
Dual Overhead Camshafts (DOHC), timing chain driven
ECM Part Number:
Specific to VIN, details provided in manual for diagnosis.
Transmission Type:
6-Speed Automatic Transmission (A6LF1 / A6LF2)
Gear Ratios:
Detailed gear ratios for each speed are provided in the manual.
Transmission Fluid:
Kia Genuine ATF SP-IV (or equivalent specification)
Transmission Fluid Capacity:
Approximately 8.5 US Quarts (8.0 Liters) for dry fill; 4.5 US Quarts (4.2 Liters) for pan drop and refill.
Length:
Approx. 192.7 inches (4895 mm)
Width:
Approx. 74.1 inches (1882 mm)
Height:
Approx. 57.1 inches (1450 mm)
Wheelbase:
Approx. 112.4 inches (2855 mm)
Curb Weight:
Approx. 3700-3900 lbs (1680-1770 kg), varies by trim and options.
NHTSA Overall Rating:
5-Star (for 2014 model year, typically)
IIHS Top Safety Pick:
Likely a Top Safety Pick recipient in its class for the year, verify specific year's results.
Braking System:
Four-wheel disc brakes with ABS, EBD, and Brake Assist
Traction Control:
Electronic Stability Control (ESC), Traction Control System (TCS)
Airbags:
Advanced front airbags, front side-impact airbags, full-length side curtain airbags, driver's knee airbag
Infotainment System:
UVO infotainment system with touchscreen, navigation available, Bluetooth connectivity, premium audio options.
Available Features:
Rearview camera, parking assist sensors, potentially adaptive cruise control, blind-spot detection depending on trim.
Connectivity Options:
USB ports, auxiliary audio input, Bluetooth hands-free phone and audio streaming.
Oil Change Interval:
Every 7,500 miles or 12 months, whichever comes first (under normal driving conditions). Consult manual for severe conditions.
Engine Air Filter:
Replace every 30,000 miles or as needed based on inspection.
Cabin Air Filter:
Replace every 15,000 miles or annually.
Spark Plugs:
Iridium type, replace at 100,000 miles.
Transmission Fluid Change:
Inspect every 30,000 miles; recommended replacement every 60,000 miles or as per severe service schedule.
Engine Coolant Specification:
Kia MS591-08 or equivalent, P-OAT (Phosphate Organic Acid Technology) type
Brake Fluid Specification:
DOT 3 or DOT 4
Common Complaints:
Potential for carbon buildup in GDI engines (requiring cleaning), occasional transmission shifting issues, and typical wear-and-tear components. Manual provides detailed diagnostics for these.
