Target Audience:
Professional automotive technicians and knowledgeable DIY enthusiasts
Manual Advantage:
Provides dealer-level repair information, enabling cost savings and quality service comparable to authorized repair shops.
Emphasis Points:
Highlights critical information through WARNING, CAUTION, and NOTE symbols for safety and accuracy.
Special Tool Identification:
Identifies and illustrates special tools required for specific adjustments and repairs, often with Kia part numbers.
Proprietary Component Coverage:
Includes instructions for proprietary components as supplied by their manufacturers to ensure proper understanding and function.
Engine Systems:
Engine mechanical (including disassembly/assembly), fuel system, ignition system, lubrication system, cooling system, exhaust system, emissions control
Transmission Systems:
Manual and Automatic Transmission (disassembly, assembly, repair, overhaul), clutch system
Drivetrain Systems:
Front-wheel drive system, axles, differentials
Suspension Steering Systems:
Front and rear suspension, steering system, power steering
Brake Systems:
Brake system components (discs, pads, calipers, lines), ABS system, parking brake
Electrical Electronic Systems:
Starting system, charging system, lighting, instruments, gauges, body electrical, power accessories, basic diagnostic procedures for electronic control units (ECUs)
Body Chassis Systems:
Body repair, interior trim, exterior trim, glass, doors, windows, HVAC (Heating, Ventilation, and Air Conditioning)
Maintenance Procedures:
Routine maintenance, fluid checks and changes, filter replacements, tune-ups, scheduled servicing
Diagnostic Procedures:
Troubleshooting guides, symptom-based diagnostics, fault code interpretation (where applicable for the era)
Repair Overhaul Procedures:
Detailed step-by-step instructions for removal, installation, disassembly, and overhaul of all major vehicle components and systems
Component Installation:
Instructions for replacing or overhauling specific parts and assemblies
Depth Of Coverage:
Comprehensive, covering both routine maintenance and major mechanical repairs, suitable for professional technicians and advanced DIYers
Engine Type:
Gasoline (as specified in product description)
Horsepower:
Varies by specific engine option (e.g., 1.6L Gamma GDI typically around 130-138 hp; 2.0L Nu GDI typically around 164-175 hp - specific engines for 2013 Cerato model may vary by region)
Torque:
Varies by specific engine option (e.g., 1.6L Gamma GDI typically around 120-123 lb-ft; 2.0L Nu GDI typically around 154-160 lb-ft - specific engines for 2013 Cerato model may vary by region)
Fuel Delivery:
Multi-point fuel injection (MPI) or Gasoline Direct Injection (GDI), depending on engine variant.
Engine Codes:
Commonly includes Gamma 1.6L (e.g., G4FC) and Nu 2.0L (e.g., G4NA, G4ND for GDI) engines for this generation, specific codes may vary by market.
Standard Transmission:
6-speed Manual Transmission (MT)
Optional Transmission:
6-speed Automatic Transmission (AT) (e.g., A6GF1)
Transmission Fluid Type:
Specific ATF type required (e.g., SPIII or SPIV for automatic transmissions, manual gearbox oil for manual transmissions - consult manual for exact specifications).
Body Styles:
Sedan, Hatchback (e.g., Cerato Forte, Cerato Koup)
Wheelbase:
Approx. 2,700 mm (106.3 inches)
Curb Weight:
Varies by body style and equipment, typically between 1,250 kg to 1,450 kg (2,750 lbs to 3,195 lbs).
Crash Test Ratings:
Likely to have achieved good ratings in global crash tests (e.g., IIHS, NHTSA, Euro NCAP) for its time, depending on market. Specific ratings would require checking by region.
Braking Systems:
Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA) are typically standard or optional.
Airbags:
Front airbags, side airbags, and curtain airbags are common depending on trim level.
Audio System:
Standard CD/MP3 player with auxiliary input and USB connectivity. Optional upgrades may include Bluetooth, navigation, and enhanced speaker systems.
Parking Assistance:
Optional rear parking sensors may be available on certain trims.
Connectivity Options:
Bluetooth hands-free calling and audio streaming, USB input for media playback and device charging.
Oil Change Interval:
Typically every 7,500 miles (12,000 km) or 6 months, whichever comes first, under normal driving conditions. Severe driving conditions may require more frequent changes. Consult manual for specifics.
Air Filter Replacement:
Recommended replacement every 15,000-30,000 miles (24,000-48,000 km) or as per manual, depending on driving environment.
Spark Plug Replacement:
Intervals vary based on spark plug type (copper, platinum, iridium). Iridium plugs typically last 60,000-100,000 miles (96,000-160,000 km). Check manual.
Engine Oil Specification:
Typically SAE 0W-20 or 5W-20 synthetic oil, meeting API SM/SN or ILSAC GF-4/GF-5 standards. Consult manual for exact grade and quantity.
Coolant Type:
Ethylene Glycol based antifreeze, typically a long-life coolant (e.g., HOAT or OAT) in a 50/50 mixture with distilled water. Consult manual for Kia's specific recommendation (e.g., KSC 2624).
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid.
Transmission Fluid Type:
Refer to transmission specifications. Automatic transmissions often require proprietary ATF, manual transmissions require gear oil.
Common Wear Items:
Brake pads and rotors, tires, suspension components (bushings, ball joints), exhaust system (muffler, pipes) due to age and mileage.
Potential Engine Concerns:
While generally reliable, some instances of oil consumption in high-mileage GDI engines have been reported. Proper maintenance is key.
Potential Transmission Concerns:
Regular ATF changes are important for automatic transmission longevity. Manual transmissions are generally robust.
