Segment:
A-segment (city car, subcompact car)
Target Audience:
Budget-conscious urban commuters, first-time car buyers, small families.
Key Competitors:
Hyundai Getz, Chevrolet Spark, Toyota Aygo, Peugeot 107, Fiat 500 (depending on market).
Value Proposition:
Affordability, fuel efficiency, compact size for urban maneuverability, surprisingly practical interior for its class.
Manual Benefit:
Empowers owners to perform maintenance and repairs, saving significant costs and extending vehicle lifespan.
Covered Years:
2003, 2004, 2005
Models Covered:
All Kia Picanto models, all engine variants, all trim levels, all transmission types
Manual Type:
Complete Workshop Service Repair Manual
File Format:
Downloadable (PDF compatible)
Delivery:
Instant Email Delivery
Estimated Page Count:
Extensive (Detailed step-by-step instructions and pictures)
Engine Service And Repair:
Engine mechanical, cooling system, lubrication system, fuel system, ignition system, exhaust system, emission controls.
Transmission Service And Repair:
Manual and automatic transmission overhaul, clutch system, driveline components.
Chassis Service And Repair:
Suspension system (front and rear), steering system, brake system (hydraulic and mechanical), wheels and tires.
Electrical And Electronics:
Wiring diagrams, lighting systems, ignition system, charging system, starting system, instrumentation, body control modules, infotainment systems, power accessories.
Body And Interior:
Body construction, exterior panels, doors, windows, interior trim, seats, HVAC system, safety systems (airbags, seatbelts).
Routine Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspections and replacement.
Troubleshooting And Diagnostics:
Step-by-step diagnostic procedures for common and uncommon faults, error code interpretation, electrical troubleshooting guides.
Component Overhaul And Rebuild:
Detailed instructions for engine teardown and reassembly, transmission rebuilds, brake caliper overhaul, etc.
Specifications And Torques:
Precise technical specifications, torque values for critical fasteners, clearances, and measurements.
Wiring Diagrams:
Comprehensive electrical system schematics for all major circuits.
Depth:
Comprehensive (A-Z coverage), suitable for DIY enthusiasts and professional technicians.
File Format Details:
Digital PDF, viewable on all major operating systems and devices with Adobe Reader.
Printability:
Fully printable (individual pages, chapters, or the entire manual).
Searchability:
Searchable text content for quick access to information.
Quality Description:
High quality, professional technical documentation with clear illustrations and diagrams.
Binding Type:
N/A (Digital Format)
Paper Type:
N/A (Digital Format)
Engine Family:
Kia Epsilon
Engine 1 0L:
1.0L (999cc) Inline-3, G3LA
Engine 1 1L:
1.1L (1086cc) Inline-4, G4HD
Engine 1 3L:
1.3L (1342cc) Inline-4, G4EH
Power Output 1 0L:
Approx. 60-61 PS (59-60 hp) @ 5500 rpm
Torque Output 1 0L:
Approx. 88-90 Nm (65-66 lb-ft) @ 3500 rpm
Power Output 1 1L:
Approx. 64-66 PS (63-65 hp) @ 5500 rpm
Torque Output 1 1L:
Approx. 94-97 Nm (69-72 lb-ft) @ 3500 rpm
Power Output 1 3L:
Approx. 75-82 PS (74-81 hp) @ 5500-6000 rpm
Torque Output 1 3L:
Approx. 115-118 Nm (85-87 lb-ft) @ 3200-3500 rpm
Fuel Delivery:
Multi-point Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline
Bore Stroke 1 0L:
71.0 mm x 83.0 mm
Bore Stroke 1 1L:
68.0 mm x 75.0 mm
Bore Stroke 1 3L:
71.0 mm x 82.7 mm
Compression Ratio Typical:
9.5:1 to 10.0:1 (varies by engine)
Transmission Type Base:
5-speed manual transmission
Transmission Type Optional:
4-speed automatic transmission
Clutch Type:
Dry single plate clutch (manual)
Manual Transmission Fluid:
API GL-4, SAE 75W-90 (check manual for specific fill)
Automatic Transmission Fluid:
Kia Genuine ATF SP-III or equivalent (check manual for specific fill)
Length:
Approx. 3,495 mm (137.6 inches)
Width:
Approx. 1,595 mm (62.8 inches)
Height:
Approx. 1,480 mm (58.3 inches)
Wheelbase:
Approx. 2,360 mm (92.9 inches)
Ground Clearance:
Approx. 140-150 mm (5.5-5.9 inches)
Curb Weight:
Approx. 870-950 kg (1918-2094 lbs) depending on engine and transmission
Gross Vehicle Weight Rating:
Approx. 1300-1400 kg (2866-3086 lbs)
Luggage Capacity Seats Up:
Approx. 157 liters (5.5 cubic feet)
Luggage Capacity Seats Down:
Approx. 760 liters (26.8 cubic feet) with rear seats folded
Euro Ncap Rating:
4-star (for earlier models, tested circa 2003)
Airbags:
Driver and front passenger airbags (standard on most trims), optional side airbags.
Seatbelts:
Three-point seatbelts with pre-tensioners for front seats, three-point rear seatbelts.
Child Seat Anchors:
ISOFIX mounting points.
ABS:
Anti-lock Braking System (ABS) available on certain trims/options.
Ebs:
Electronic Brakeforce Distribution (EBD) often paired with ABS.
Audio System:
Basic AM/FM/CD player with 2 or 4 speakers. Higher trims might have auxiliary input.
Display:
Simple digital or analog displays for radio, CD, and basic vehicle information.
Cruise Control:
Rarely fitted on base models, more common on higher trims or optional.
Parking Sensors:
Optional rear parking sensors on some higher-spec models.
Bluetooth:
Not typically available on models from these years. Often requires aftermarket integration.
Usb Port:
Not standard. Usually introduced in later generations or via aftermarket solutions.
Oil Change Interval:
Typically every 15,000 km (9,300 miles) or 12 months, whichever comes first (refer to manual for specific engine).
Air Filter Replacement:
Check every 15,000 km, replace as needed or at 30,000 km (18,600 miles).
Spark Plug Replacement:
Typically around 60,000 km (37,000 miles), dependent on plug type (copper, platinum, iridium).
Coolant Replacement:
Initial change at 100,000 km (60,000 miles), then every 40,000 km (25,000 miles) or 24 months thereafter.
Engine Oil Type:
API SN/SM/SL or ACEA A3/B3/B4, SAE 5W-20 or 5W-30 (check manual for specific viscosity based on climate and engine).
Engine Oil Capacity:
Approx. 2.7 - 3.0 liters (2.8 - 3.2 US quarts) with filter change (varies by engine).
Coolant Type:
Ethylene glycol-based antifreeze, typically a red or pink OAT (Organic Acid Technology) or HOAT (Hybrid Organic Acid Technology) coolant. Always use pre-diluted or mix with distilled water as per manual.
Brake Fluid Type:
DOT 3 or DOT 4.
Common Wear Items:
Clutch wear (manual transmission), brake pads and rotors, suspension components (bushings, ball joints), exhaust system (rusting).
Engine Oil Consumption:
Some reports of higher than average oil consumption in higher mileage 1.1L and 1.3L engines due to piston ring wear.
Electrical Gremlins:
Occasional issues with window regulators, central locking, or dashboard warning lights due to wiring or module faults.
Rust Prone Areas:
Wheel arches, sills, and tailgate due to subcompact car construction and climate exposure.
Manufacturer Origin:
South Korea
Brand Philosophy:
Focus on value, affordability, and increasingly, design and technology.
Introduction Year:
2004 (Global introduction of the SA generation)
Design Influence:
Designed in Europe, often associated with Italian design firm Pininfarina's input in early styling concepts.
Manufacturing Locations:
Primarily South Korea (Gwangmyeong), with some production or assembly also occurring in other countries depending on market.
Design Awards:
While not a major award winner, the Picanto's design was considered fresh and youthful for its segment at launch.
Fuel Efficiency Rankings:
Consistently ranked as one of the most fuel-efficient vehicles in its class, especially with the 1.0L and 1.1L engines.
Affordability Rankings:
Praised for its low purchase price and running costs, making it a strong contender in the budget car market.
