🏷️ Basic Information

Make:

Kia

Model:

Sportage

Year:

2006

Engine:

2.7L V6

Chassis Code:

JE

Engine Code Prefix:

G6BA

👋 Introduction

Segment:

Compact SUV / Crossover

Target Audience:

Budget-conscious SUV buyers seeking utility, practicality, and a capable powertrain.

Key Competitors 2006:

Honda CR-V, Toyota RAV4, Ford Escape, Nissan Xterra, Subaru Forester

Powertrain Highlight:

2.7L V6 engine offering a good balance of power and smoothness for its class.

Design Philosophy:

Rugged yet functional design, characteristic of many Korean automakers of the era.

Value Proposition:

Offered a compelling package of features and capability at a competitive price point.

📋 Manual Details

Primary Coverage:

2006 Kia Sportage 2.7L V6

Estimated Pages:

1500+

Type:

Factory Service Manual / Repair Manual

Language:

English

Format:

Digital (likely PDF)

📖 Manual Coverage

Engine:

Complete Engine Mechanical and Electrical Systems, including Engine Control Module (ECM), Fuel Delivery, Ignition, Cooling, Lubrication, Emissions Control

Transmission:

Automatic Transmission (4-speed), including Hydraulic Controls, Torque Converter, Transmission Control Module (TCM), Gear Ratios, and Fluid Service

Drivetrain:

Front Wheel Drive (FWD) and All Wheel Drive (AWD) Systems, including CV Axles, Differential, Transfer Case (if applicable for AWD), and Driveshafts

Suspension:

Front Independent Suspension (MacPherson Strut), Rear Multi-link Suspension, Shock Absorbers, Springs, Bushings, and Alignment Specifications

Brakes:

Front Ventilated Disc Brakes, Rear Disc Brakes, Anti-lock Braking System (ABS) Components and Diagnostics, Parking Brake System

Steering:

Power Rack and Pinion Steering System, Steering Column, Power Steering Pump, Fluid Requirements, and Troubleshooting

Electrical:

Complete Electrical Schematics, Lighting Systems, Power Distribution, Fuses and Relays, Battery, Charging System, Starter, Horn, Wiper/Washer System, Power Accessories

HVAC:

Heating, Ventilation, and Air Conditioning (HVAC) System, Refrigerant, Compressor, Condenser, Evaporator, Blower Motor, and Controls

Body:

Body Panels, Doors, Hood, Tailgate, Bumpers, Glass, Seals, Interior Trim, Exterior Trim, and Paint Information

Chassis:

Frame Structure, Underbody Components, Fuel Tank, Exhaust System

Maintenance:

Scheduled Maintenance Intervals, Oil and Filter Changes, Fluid Level Checks and Replenishment, Spark Plug Replacement, Air Filter Replacement, Coolant Flush, Brake Fluid Flush

Diagnostics:

Troubleshooting Guides based on Symptoms, Diagnostic Trouble Codes (DTCs) Interpretation, Wiring Diagram Analysis, Component Testing Procedures

Repair:

Engine Overhaul and Rebuild, Transmission Repair and Overhaul, Brake System Overhaul, Suspension Component Replacement, Electrical Component Repair, HVAC System Repair, Body Panel Repair

Installation:

Component Removal and Installation procedures for all major systems

Specifications:

Torque Specifications for all Fasteners, Alignment Specifications, Diagnostic Data Values, Electrical Resistance Values

Depth:

Comprehensive Factory-Level Repair and Maintenance Information, suitable for professional technicians and advanced DIY enthusiasts

Detail Level:

Detailed step-by-step instructions with accompanying diagrams, illustrations, and photos for all procedures

📊 Manual Specifications

File Type:

PDF

Searchability:

Likely Searchable Text within PDF

Image Resolution:

High-resolution for clear diagrams and illustrations

Binding:

N/A (Digital Format)

Paper Quality:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Family:

Kia V6 Alpha Engine

Configuration:

60-degree V6, SOHC (Single Overhead Camshaft)

Displacement:

2656 cc (2.7 Liters)

Bore X Stroke:

86.7 mm x 75.0 mm

Compression Ratio:

9.0:1

Valve Train:

24 Valves (4 per cylinder)

Horsepower:

173 hp @ 6000 rpm

Torque:

174 lb-ft @ 4500 rpm

Induction:

Multi-Port Fuel Injection (MPI)

Fuel Type:

Unleaded Gasoline, 87 Octane (Recommended)

Coolant Type:

Ethylene Glycol based coolant (e.g., Hyundai/Kia Long Life Coolant - Pink)

Coolant Capacity:

Approx. 7.0 Liters (7.4 US qts)

Oil Type:

API SJ/SL or higher, SAE 5W-30

Oil Capacity:

Approx. 4.5 Liters (4.8 US qts) with filter change

Oil Filter Part Number Example:

Kia/Hyundai 26300-35056 (Verify with VIN)

🔧 Transmission

Type:

4-Speed Automatic Transmission (4WD Automatic Transmission)

Model Designation:

Hyundai/Kia A4CF1

Manual Transmission:

N/A for 2.7L V6 models in this year

Drive Modes:

Electronically Controlled Automatic with Overdrive

Fluid Type:

Kia Genuine ATF SP-III (or equivalent approved specification)

Fluid Capacity Approx:

7.5 Liters (7.9 US qts) (total fill, check level procedure)

📐 Dimensions

Length:

4345 mm (171.1 inches)

Width:

1795 mm (70.7 inches)

Height:

1690 mm (66.5 inches)

Wheelbase:

2630 mm (103.5 inches)

Ground Clearance:

Approx. 200 mm (7.9 inches)

Curb Weight Approx:

1580 - 1650 kg (3483 - 3638 lbs) (depending on FWD/AWD and trim)

Cargo Volume Seats Up Approx:

667 Liters (23.5 cu ft)

Cargo Volume Seats Down Approx:

1884 Liters (66.5 cu ft) (with rear seats folded)

Towing Capacity Unbraked:

750 kg (1650 lbs)

Towing Capacity Braked:

1500 kg (3300 lbs)

🛡️ Safety Features

NHTSA Frontal Driver 2006:

4 Stars

NHTSA Frontal Passenger 2006:

4 Stars

NHTSA Side Driver 2006:

5 Stars

NHTSA Side Passenger 2006:

5 Stars

IIHS Frontal Offset 2006:

Good

ABS:

Standard (4-wheel disc ABS)

Traction Control:

Available on some trims

Airbags Standard:

Front Driver and Passenger Airbags

Airbags Optional:

Available Front Side-Impact Airbags on some trims

Seatbelts:

3-point front and rear seatbelts with pretensioners and load limiters

💡 Technology Features

Audio System:

AM/FM CD Player, with optional premium audio and subwoofer on higher trims.

Navigation:

Optional factory-installed navigation system available on select models.

Cruise Control:

Standard

Rear Parking Sensors:

Available as an option or part of a package.

Auxiliary Input:

Optional auxiliary audio input jack available on some models.

🔧 Maintenance

Oil Change Interval Normal Service:

Every 7,500 miles or 12 months, whichever comes first (using synthetic blend or full synthetic oil)

Oil Change Interval Severe Service:

Every 3,750 miles or 6 months (e.g., frequent short trips, dusty conditions, towing).

Engine Air Filter Replacement:

Inspect every 7,500 miles, replace as needed or every 15,000 miles.

Cabin Air Filter Replacement:

Inspect every 7,500 miles, replace every 15,000 miles or annually.

Transmission Fluid Change:

Inspect every 30,000 miles, replace every 60,000 miles (or as per severe service schedule).

Coolant Flush Replacement:

Flush and replace coolant every 30,000 miles or 24 months. Long-life coolant may extend this interval, refer to manual.

Brake Fluid Replacement:

Replace brake fluid every 24 months or 30,000 miles, regardless of mileage.

Spark Plug Replacement 2.7L V6:

Replace spark plugs every 60,000 miles. Recommended: Iridium-tipped spark plugs (e.g., NGK IFR5A11).

Power Steering Fluid:

Dexron III ATF or equivalent (refer to manual for exact specification)

Engine Mounts:

Premature wear or failure of engine mounts can lead to increased vibration.

Cv Joints:

Front CV joint boots can tear, leading to joint failure if not addressed.

Window Regulators:

Power window regulators can fail over time.

Evaporative Emissions Control System:

Issues with the EVAP system, such as a faulty purge valve or charcoal canister, can trigger check engine lights.

Standard Tire Size:

235/60R16 (Base models), 235/55R18 (Optional/Higher Trims)

Wheel Bolt Pattern:

5x114.3 mm (5x4.5 inches)

Recommended Tire Pressure:

30-32 PSI (refer to door jamb sticker for specific values)

📚 Vehicle History

Kia History:

Founded in 1944, Kia started as a manufacturer of steel tubing and bicycle parts. It entered the automotive industry in the 1960s, initially producing trucks and later cars through licensing agreements before developing its own models.

Sportage Generation 1 Je:

The first-generation Sportage (JE) was launched in 1993 as a compact SUV based on Kia's Bongo light truck platform. The 2006 model represents the latter part of this generation's lifecycle, with styling updates and improved powertrains.

Sportage Generation 2 Km:

The second-generation Sportage (KM) was introduced for the 2005 model year globally, and this manual covers the later phase of the first generation that was still in production in some markets or the transition to the second generation in others, depending on region. The 2006 2.7L V6 is a key offering of this generation's platform.

Manufacturing Locations:

South Korea (Kia's primary manufacturing base), with potential assembly in other regions.

🏆 Awards & Recognition

IIHS Top Safety Pick:

The 2006 Sportage received a 'Good' rating in IIHS frontal offset crash tests, indicating strong structural integrity for its time, contributing to its favorable safety ratings.

Consumer Reports Reliability 2006:

Consumer Reports reliability ratings for the 2006 Sportage were typically average to below average, a common characteristic for many vehicles from less established brands at the time. This manual is crucial for maintaining and repairing potential issues.
