🏷️ Basic Information

Make:

KTM

Model:

1290 Super Duke R

Year:

2014, 2015, 2016

Segment:

Hyper-Naked / Streetfighter

Engine Code Designation:

LC8

👋 Introduction

Vehicle Type:

High-performance naked sport motorcycle, known for its aggressive styling, powerful engine, and dynamic handling.

Competitors:

Competes with other top-tier hyper-nakeds such as the Ducati Streetfighter, Aprilia Tuono V4, and Yamaha MT-10.

Engine Power:

Renowned for its potent 1301cc V-twin engine, delivering exceptional torque and horsepower.

Handling Dynamics:

Features a lightweight yet robust chassis, advanced suspension components, and rider-aids for precise and exhilarating handling.

Technology Suite:

Equipped with sophisticated electronic rider aids, including traction control, ride modes, and cornering ABS (depending on specific model year/trim).

📋 Manual Details

General Coverage:

Comprehensive repair and maintenance for the KTM 1290 Super Duke R (2014-2016).

Specific Systems:

Engine, transmission, chassis, suspension, brakes, electrical system, fuel system, exhaust system, cooling system, steering, wheels, and tires.

Total Pages:

312

Type:

Workshop Service Repair Manual

Primary Language:

English

Digital Format:

PDF

📖 Manual Coverage

Engine Mechanical:

Detailed instructions for engine disassembly, assembly, inspection, and repair of all internal components (pistons, cylinders, crankshaft, valves, etc.).

Fuel And Ignition:

Comprehensive data on fuel injection system, throttle body, fuel pump, injectors, ignition system components, spark plugs, and troubleshooting.

Cooling System:

Information on radiator, coolant, water pump, thermostat, and associated hoses and passages.

Exhaust System:

Details on exhaust components, catalytic converter (if applicable), and mounting hardware.

Transmission And Drivetrain:

Procedures for clutch operation, gearbox disassembly/assembly, chain and sprocket maintenance, and final drive.

Brakes:

Detailed procedures for brake caliper service, master cylinder overhaul, brake pad replacement, bleeding procedures, and ABS system troubleshooting (if applicable).

Suspension:

Instructions for front fork (WP APEX) and rear shock absorber (WP APEX) servicing, oil changes, seal replacement, and adjustment procedures.

Steering:

Details on steering head bearing inspection, adjustment, and replacement.

Electrical System:

Wiring diagrams, troubleshooting guides for starting and charging systems, lighting, instrumentation, ECU functions, and sensor diagnostics.

Chassis And Frame:

Information on frame inspection, subframe, and component mounting points.

Bodywork And Fairings:

Procedures for removal and installation of body panels, seats, and fuel tank.

Routine Maintenance:

Oil changes, filter replacements, chain adjustment, brake fluid checks, coolant levels, tire pressure monitoring, and spark plug checks.

Troubleshooting:

Systematic diagnostic procedures for identifying and resolving common and complex issues, including fault code interpretation (if applicable).

Disassembly And Assembly:

Step-by-step guides for removing and reinstalling all major and minor components.

Adjustments:

Detailed procedures for adjusting clutch, throttle cables, suspension settings, and idle speed.

Rebuilds And Overhauls:

Comprehensive instructions for complete engine rebuilds, gearbox overhauls, and suspension component servicing.

Special Tool Usage:

Identification and usage instructions for specialized KTM tools required for specific repair operations.

Diagnostic Capabilities:

Advanced diagnostic procedures, including identification of sensor failures and ECU-related issues.

Repair Methodology:

Detailed explanations of repair methodologies, including correct torque values, seal replacement, and lubrication specifications.

Pictorial Representation:

Richly illustrated with step-by-step pictorial diagrams, exploded views, and photographs to guide users through complex procedures.

📊 Manual Specifications

Type:

PDF

Searchable:

Yes (assumed for a professional PDF)

Printability:

Yes, all pages are printable.

Digital Delivery Method:

Instant Download

Operating Systems:

Windows, Mac, Linux OS

Software:

Adobe Reader

⚙️ Engine Specifications

Type:

V-twin, 4-stroke, liquid-cooled

Displacement:

1301 cc (1290 cubic centimeters)

Bore X Stroke:

103 mm x 77.1 mm

Valve Train:

DOHC, 4 valves per cylinder

Horsepower Peak:

Approximately 180 HP (132 kW) @ 8870 rpm (for 2014-2016 models, variations may exist)

Torque Peak:

Approximately 144 Nm (106 lb-ft) @ 6750 rpm (for 2014-2016 models, variations may exist)

Induction:

Electronic fuel injection with dual throttle bodies (Ride-by-Wire)

Fuel Type:

Unleaded Premium Gasoline (RON 95 or higher)

Oil Type Recommendation:

Fully synthetic motorcycle oil, API SJ or higher, JASO MA/MA2 certified. Specific grade: 10W-50 or 15W-50.

Oil Capacity:

Approximately 3.4 liters (3.6 US qt) with filter change.

🔧 Transmission

Type:

6-speed, claw-shifted

Quickshifter:

KTM Quickshifter+ (optional accessory or standard on certain trims/years, for upshifts and downshifts)

Clutch:

PASC™ Anti-hopping clutch (Mechanically operated)

Final Drive:

X-ring chain 525

📐 Dimensions

Length:

2105 mm (82.87 in) (approximate, check specific model year)

Width:

873.5 mm (34.39 in) (approximate, check specific model year)

Height:

1131 mm (44.53 in) (approximate, check specific model year)

Dry Weight:

Approx. 185 kg (408 lbs) (dry, without fuel)

Wet Weight:

Approx. 205 kg (452 lbs) (ready to ride, with full tank - estimate)

Fuel Tank Capacity:

18 liters (4.75 US gal)

Seat Height:

835 mm (32.87 in)

🛡️ Safety Features

ABS:

Bosch 9.1 MP ABS (with Cornering ABS function on later models or as an option/package)

Traction Control:

MTC (Motorcycle Traction Control) with multiple modes (Sport, Street, Rain).

Ride Modes:

Multiple ride modes (e.g., Sport, Street, Rain) affecting throttle response and MTC intervention.

Lighting:

LED lighting elements where applicable, designed for enhanced visibility.

💡 Technology Features

Instrument Cluster:

Full-color TFT display (on later models or as an upgrade) providing comprehensive information including speed, RPM, gear position, ride modes, and diagnostics.

Cornering ABS:

Bosch ABS system designed to function while the motorcycle is leaned over (cornering ABS).

Kdm Connectivity App:

While direct smartphone integration might be limited on these early models, later KTMs feature the KTMconnect app for navigation and music, which can be referenced for potential upgrades or system understanding.

🔧 Maintenance

Oil And Filter Change:

Typically every 7,500 miles (12,000 km) or annually, whichever comes first. Consult manual for exact intervals.

Valve Clearance Check:

Typically at 15,000 miles (24,000 km) or as specified in the service manual.

Spark Plug Replacement:

As per manual, often around 15,000 - 20,000 miles (24,000 - 32,000 km).

Coolant:

Mixture of distilled water and a high-quality antifreeze/coolant (e.g., silicate-free, ethylene glycol-based). Capacity: Approx. 1.4 liters. Consult manual for specific KTM approved coolant.

Brake Fluid:

DOT 4 or DOT 5.1 brake fluid. Capacity depends on system. Regular replacement recommended (e.g., every 2 years).

Clutch Fluid:

DOT 4 brake fluid (for hydraulic clutch systems). Capacity depends on system.

Fuel Pump Relay:

Some early models may have experienced issues with the fuel pump relay.

Electrical Connectors:

Occasional reports of minor electrical connector issues, generally resolvable with proper maintenance.

Suspension Seals:

As with any high-performance motorcycle, fork seal longevity can be a factor with aggressive riding. Regular inspection is advised.

📚 Vehicle History

Manufacturer Philosophy:

KTM is renowned for its 'Ready to Race' philosophy, focusing on performance, off-road prowess, and rider-centric engineering, which translates into their street bikes.

Predecessors:

The 1290 Super Duke R builds upon the 'Super Duke' lineage, evolving from earlier iterations like the 990 Super Duke, increasingly focusing on raw power and advanced technology.

Development Focus:

The 'R' designation signifies the higher-spec, more track-oriented version of the Super Duke, emphasizing performance over comfort compared to its non-R siblings.

Manufacturing Location:

Austria (KTM AG)

🏆 Awards & Recognition

General Reputation:

Consistently praised by automotive journalists and riders for its extreme performance, sharp handling, and aggressive styling, often earning 'Hyper-Naked' or 'Streetfighter of the Year' accolades in its class.
