🏷️ Basic Information

Make:

Land Rover

Model:

Discovery 2

Generation:

Series II

Chassis Code:

LT95, R380 (Transmission specific)

👋 Introduction

Segment:

Premium SUV, Off-road oriented

Competitors:

Jeep Grand Cherokee, Toyota Land Cruiser, Mitsubishi Pajero/Montero, Mercedes-Benz ML-Class, BMW X5

Distinguishing Factors:

Advanced Terrain Response (early iterations), robust chassis, strong off-road capability, sophisticated air suspension system (ACE - Active Cornering Enhancement), powerful diesel and V8 petrol engines

📋 Manual Details

Vehicle Years:

1998-2004

Regions:

Global (English speaking markets)

Estimated Pages:

300-500 (Typical for comprehensive wiring diagrams)

Type:

Electrical Wiring Diagram Manual

Language:

English

File Format:

PDF

📖 Manual Coverage

Electrical Systems:

Power Distribution, Lighting (Interior & Exterior), Ignition System, Charging System, Starting System, Engine Management Systems (GEMS, P38/Bosch), Transmission Control, ABS/Traction Control, Airbag Systems, HVAC Controls, Central Locking, Power Windows, Sunroof, Door Mirrors, Instrument Cluster, Audio System, Diagnostic Socket (OBD-II), Anti-Theft Alarm System, Cruise Control, Body Control Module (BCM), Shift Interlock

Diagnostic Procedures:

Troubleshooting electrical faults, circuit tracing, identifying component failures, understanding wiring schematics

Repair Procedures:

Wire repair techniques, connector diagnostics, component replacement guidance (based on wiring context)

Depth:

Comprehensive (Detailed schematics, component locations, connector pinouts, wire colors and descriptions, fuse and relay assignments)

📊 Manual Specifications

Software Requirements:

Adobe Acrobat Reader, WinRAR (for extraction)

Compatibility:

All versions of Windows and Mac OS

Printability:

Printable

Binding:

N/A (Digital PDF)

Paper Type:

N/A (Digital PDF)

⚙️ Engine Specifications

Engine Options:

4.0L V8 (BMW M62 derived - GEMS), 4.6L V8 (Bosch), 2.5L TD5 (Direct Injection Turbocharged Diesel), 4.0L V8 (GEMS, later Bosch)

Horsepower Range:

136 hp (TD5) - 218 hp (4.6L V8)

Torque Range:

207 lb-ft (TD5) - 300 lb-ft (4.6L V8)

Fuel Type:

Petrol (Gasoline), Diesel

Injection Type:

Multi-point Fuel Injection (MPI) for petrol, Direct Injection for TD5 diesel

🔧 Transmission

Transmission Types:

4-speed Automatic (ZF 4HP22, ZF 5HP24 for V8s), 5-speed Manual (R380)

Transfer Case:

Permanent Four-Wheel Drive with locking center differential

Gear Ratios:

Varies by transmission and axle ratio (detailed in specific service manuals)

📐 Dimensions

Wheelbase:

Approx. 100 inches (2540 mm)

Length:

Approx. 183 inches (4650 mm)

Width:

Approx. 71 inches (1800 mm)

Height:

Approx. 73 inches (1850 mm) - varies with suspension

Curb Weight:

Approx. 4,500 - 5,000 lbs (2040 - 2270 kg)

Towing Capacity:

Up to 7,716 lbs (3500 kg)

🛡️ Safety Features

NHTSA Ratings:

Not extensively rated by NHTSA for this era, generally considered robust for its class.

Active Safety:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Traction Control System (TCS), Hill Descent Control (HDC)

Passive Safety:

Front Airbags, Side Impact Beams, Seatbelt Pretensioners, Roll Over Protection (internal structural design)

💡 Technology Features

Audio System:

Factory fitted radio/cassette or CD player, optional premium sound systems (e.g., Harman Kardon)

Navigation:

Optional GPS navigation systems were available on higher trim levels.

Cruise Control:

Standard on many models, controlled via steering wheel buttons or stalk.

Diagnostic Port:

OBD-II compliant diagnostic socket, typically located under the dashboard.

🔧 Maintenance

Oil Change Interval:

Every 6,000 miles or 12 months, whichever comes first (refer to manual for exact spec)

Major Service Intervals:

Timing belt replacement (if applicable to specific engine), coolant flush, brake fluid change (typically 2-3 years or 30,000 miles)

Engine Oil Type:

API SG/SH or higher, SAE 10W-40 or 15W-40 for diesel; SAE 5W-30 or 10W-40 for petrol (check manual for exact specification and viscosity based on climate)

Coolant Type:

Ethylene Glycol based antifreeze with corrosion inhibitors (e.g., Rover Coolant PWB500010)

Transmission Fluid Type:

ATF Dexron III or equivalent for automatic transmissions; Manual transmission fluid: SAE 75W-90 GL-4 or GL-5 (check manual for specific requirements)

Brake Fluid Type:

DOT 3 or DOT 4

Common Problems:

Head gasket failure (especially on V8s), ACE hydraulic leaks, SLS (Self-Levelling Suspension) pump and airbag failures, EAS (Electronic Air Suspension) compressor and height sensor issues, crankcase breather issues (TD5), viscous fan clutch failure, rust on chassis and bodywork, door seal degradation

📚 Vehicle History

Brand Focus:

Land Rover is renowned for its legendary off-road capability and durable expedition vehicles.

Predecessor:

Land Rover Discovery 1

Successor:

Land Rover Discovery 3 (LR3)

Production Years:

1998-2004

Manufacturing Locations:

Solihull, England

🏆 Awards & Recognition

Off Road Acclaim:

Consistently recognized for its exceptional off-road prowess and durability, often favored in expeditions and overland travel.

Consumer Reports Style:

Mixed reviews from consumer reporting agencies, often highlighting reliability concerns balanced against strong capability. This manual is crucial for owners focused on maintenance.
