Segment:
Compact SUV / Crossover
Target Audience:
Families, outdoor enthusiasts, individuals seeking premium compact SUV capabilities.
Key Competitors:
BMW X3, Audi Q5, Volvo XC60, Honda CR-V, Toyota RAV4 (during its production run).
Design Philosophy:
Blend of Land Rover's off-road heritage with modern crossover practicality and comfort.
Unique Selling Points:
Advanced AWD system (Haldex), Terrain Response, respectable off-road capability for its class, premium interior.
Geographic Coverage:
Global (assumed based on factory manual nature)
Region Specific Notes:
May include variations for specific markets; consult VIN for precise build.
Estimated Page Count:
Hundreds (as stated in product description, typical for factory manuals)
Type:
Factory Service & Repair Workshop Manual
Language:
English (assumed for global market appeal and technical detail)
Accessibility:
Instant download, usable on computers, tablets, and smartphones.
License Type:
Perpetual use, no expiry dates, no renewal fees
Usage Rights:
Unlimited installations across multiple devices.
Powertrain:
Engine mechanical, lubrication, cooling, fuel delivery, exhaust, engine management (ECM).
Drivetrain:
Manual transmission, automatic transmission, final drive, propeller shaft, differentials, drive axles, Haldex all-wheel-drive system.
Chassis:
Suspension (front and rear), steering system, braking system (ABS, DSC, EBA), wheels and tires.
Electrical:
Battery, charging system, starting system, lighting, instrumentation, power windows, central locking, body control module (BCM), engine control module (ECM), transmission control module (TCM).
Body And Trim:
Body panels, doors, latches, hinges, exterior trim, interior trim, seats, airbags, climate control system (HVAC), infotainment system.
Driver Assistance:
Hill Descent Control (HDC), Terrain Response (if equipped), cruise control.
Maintenance:
Scheduled maintenance (oil changes, filter replacements, fluid checks), brake fluid flush, coolant replacement, spark plug replacement.
Repair:
Engine overhaul, transmission rebuild, suspension component replacement, brake caliper replacement, electrical component diagnosis and repair.
Troubleshooting:
Diagnostic trouble codes (DTCs), symptom-based troubleshooting guides, electrical circuit diagrams, flowcharts.
Diagnostics:
On-board diagnostics (OBD-II) procedures, specific module diagnostics, sensor testing.
Specifications:
Torque specifications for all fasteners, fluid capacities, tolerances, diagnostic parameters.
Special Tools:
Identification and usage of specialized tools required for specific repair procedures.
Depth:
Comprehensive factory-level detail, suitable for professional mechanics and advanced DIY enthusiasts.
Diagrams And Illustrations:
Detailed exploded diagrams, step-by-step photos, wiring schematics.
Engine Code Petrol:
Si6 (3.2L I6), i4 (2.0L Turbo I4 - later models, check specific VIN)
Engine Code Diesel:
DW12 (2.2L TD4), DW10 (2.0L TD4 - later models, check specific VIN)
Displacement Si6:
3.2 liters (3192 cc)
Configuration Si6:
Inline 6-cylinder, transverse mounting
Horsepower Si6:
Approx. 233 hp @ 6300 rpm
Torque Si6:
Approx. 230 lb-ft (317 Nm) @ 3200 rpm
Displacement Td4:
2.2 liters (2179 cc)
Configuration Td4:
Inline 4-cylinder, turbocharged diesel, common rail, DOHC
Horsepower Td4:
Approx. 150 hp - 190 hp (depending on variant)
Torque Td4:
Approx. 260 lb-ft (350 Nm) - 310 lb-ft (420 Nm) (depending on variant)
Petrol Injection:
Electronic Fuel Injection (EFI)
Diesel Injection:
Common Rail Direct Injection (CRDI) with Diesel Particulate Filter (DPF) on later models.
Standard Transmission:
6-speed Manual Transmission (Getrag M66 for some variants)
Optional Transmission:
6-speed Automatic Transmission (Aisin TF-80SC for Si6, ZF 6HP26 for some TD4 variants)
AWD System:
Haldex Generation 4 All-Wheel Drive System with electronic control.
Terrain Response:
Available with Terrain Response system (adapts powertrain, traction control, and differentials to surface conditions).
Length:
Approx. 4500 mm (177.2 inches)
Width:
Approx. 1895 mm (74.6 inches) (excluding mirrors)
Height:
Approx. 1740 mm (68.5 inches)
Wheelbase:
Approx. 2660 mm (104.7 inches)
Curb Weight:
Approx. 1700 kg - 1900 kg (3748 lbs - 4189 lbs) depending on engine and specification.
Cargo Volume Seats Up:
Approx. 755 liters (26.7 cu ft)
Cargo Volume Seats Down:
Approx. 1670 liters (59.0 cu ft)
Euro Ncap Rating:
5 Stars (for models equipped with optional safety pack; base models may vary)
ABS:
Anti-lock Braking System (ABS) standard.
Esp:
Electronic Stability Control (ESC) / Dynamic Stability Control (DSC) standard.
Traction Control:
Traction Control System (TCS) standard.
Hdс:
Hill Descent Control (HDC) standard.
Airbags:
Front airbags, side airbags, curtain airbags (availability varies by trim level).
Seatbelts:
Pre-tensioned seatbelts with load limiters.
Child Seat Anchors:
ISOFIX child seat mounting points.
Head Unit:
Standard radio/CD player with optional upgraded audio systems, satellite navigation, and Bluetooth connectivity.
Connectivity:
Optional USB integration, auxiliary input, and Bluetooth hands-free calling.
Parking Sensors:
Optional front and rear parking sensors.
Bi Xenon Headlights:
Optional Bi-Xenon headlights with adaptive front lighting.
Oil Change Interval:
Typically 15,000 miles or 12 months, whichever comes first (diesel models may vary, consult specific manual section).
Timing Belt Chain:
Si6 (3.2L I6) uses a timing chain. TD4 (2.2L Diesel) uses a timing chain (check for chain tensioner updates).
Engine Oil Si6:
API SN/SM or ACEA A3/B4, viscosity 5W-30 or 5W-40 (refer to manual for exact specification and capacity).
Engine Oil Td4:
API CF or ACEA C2/C3, viscosity 5W-30 (Low SAPS oil required for DPF models, refer to manual for exact specification and capacity).
Coolant:
OAT (Organic Acid Technology) coolant, specification: Jaguar/Land Rover Long Life Coolant (Green).
Brake Fluid:
DOT 4 or DOT 4 LV (Low Viscosity) for ABS/ESC systems.
Transmission Fluid Auto:
Aisin JWS 3309 or equivalent ATF (for Aisin TF-80SC); ZF LifeguardFluid 6 (for ZF 6HP26). Specific fluid type and change interval critical.
AWD Haldex Fluid:
Specific Haldex Oil (refer to manual for part number and capacity for periodic change).
Td4 Dpf:
Diesel Particulate Filter (DPF) clogging can occur with insufficient highway driving, leading to regeneration issues or replacement.
Haldex Coupling:
Haldex coupling system can require fluid changes and filter maintenance; potential for pump failure if neglected.
Thermostat:
Coolant thermostat housing can develop leaks or fail to regulate temperature correctly.
Suspension:
Worn control arm bushings, ball joints, and wheel bearings are common wear items, especially with higher mileage.
Turbocharger Td4:
Turbocharger wastegate actuator or seals can fail, leading to loss of power or boost issues.
Brand Legacy:
Land Rover has a long history of producing robust and capable off-road vehicles, including the Defender and Discovery.
Generation:
Second generation of the Freelander, introduced in 2006.
Key Changes L359:
Significant redesign from the first generation; introduction of monocoque chassis, independent suspension, and Haldex AWD system.
Manufacturing Plant:
Solihull, West Midlands, United Kingdom.
Production Period:
2006-2015 (Manual covers 2007-2011 sub-period).
