🏷️ Basic Information

Make:

Land Rover

Model:

Range Rover Sport

Years Covered:

2012, 2013, 2014

Chassis Codes:

L320 (facelift models)

👋 Introduction

Segment:

Luxury SUV, Performance SUV

Target Audience:

Owners seeking detailed self-maintenance, independent repair shops, professional Land Rover technicians.

Competitors:

BMW X5, Audi Q7, Porsche Cayenne, Mercedes-Benz ML-Class (W164/W166), Lexus RX

Vehicle Attributes:

Off-road capability, luxurious interior, powerful engine options, sophisticated all-wheel-drive system.

Manual Value Proposition:

Provides comprehensive, factory-authorized information for accurate diagnosis and repair, crucial for maintaining the complex systems of a luxury vehicle like the Range Rover Sport.

📋 Manual Details

Primary Coverage:

Factory Service Repair

Specific Exclusions:

Wiring Diagrams

Total Pages:

>8000

Type:

Comprehensive Service and Repair Manual

Language:

English

Format:

Digital (likely PDF)

📖 Manual Coverage

Powertrain:

Engine, Transmission, Drivetrain, Fuel System, Exhaust System

Chassis:

Suspension, Steering, Brakes, Wheels & Tires

Body And Exterior:

Body Panels, Doors, Windows, Mirrors, Roof System, Exterior Trim

Interior And Comfort:

Seating, Interior Trim, HVAC System, Audio System, Climate Control

Electrical And Electronics:

Lighting, Power Features (windows, seats), Exterior Lighting, Interior Lighting, Battery, Charging System (excluding detailed wiring diagrams)

Maintenance:

Scheduled Maintenance, Oil Changes, Filter Replacements, Fluid Checks and Replacements

Diagnostics:

Troubleshooting Guides, Symptom-Based Diagnostics, Component Testing

Repair:

Component Removal and Installation, Overhaul Procedures, Adjustments

Special Tools:

Identification and usage recommendations for specialized Land Rover tools

Depth:

In-depth diagnostics, component-level repair, overhaul procedures, specifications, and torque values. Suitable for professional technicians and advanced DIY enthusiasts.

📊 Manual Specifications

Digital Format:

PDF (assumed, common for large manuals). High-resolution scans or digitally produced content.

Digital Quality:

Likely high resolution for clarity of diagrams and text. Searchable text is a common feature for digital manuals.

Physical Binding:

N/A (Digital Format)

Physical Paper:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Options:

3.0L TD V6, 3.0L V6 Supercharged, 5.0L V8 Naturally Aspirated, 5.0L V8 Supercharged

Displacement:

2993 cc (3.0 Liters)

Fuel Type:

Diesel

Induction:

Turbocharged (likely variable geometry turbocharger - VGT)

Displacement:

2995 cc (3.0 Liters)

Fuel Type:

Petrol (Gasoline)

Induction:

Supercharged

Displacement:

5000 cc (5.0 Liters)

Fuel Type:

Petrol (Gasoline)

Induction:

Naturally Aspirated

Displacement:

5000 cc (5.0 Liters)

Fuel Type:

Petrol (Gasoline)

Induction:

Supercharged (Jaguar/Land Rover 'AJ-V8 Gen III SC')

3.0L Td V6 Hp:

Approx. 256 hp @ 4000 rpm

3.0L Td V6 Torque:

Approx. 443 lb-ft @ 2000 rpm

3.0L V6 S/C Hp:

Approx. 340 hp @ 6500 rpm

3.0L V6 S/C Torque:

Approx. 332 lb-ft @ 3500 rpm

5.0L V8 Na Hp:

Approx. 375 hp @ 6500 rpm

5.0L V8 Na Torque:

Approx. 375 lb-ft @ 3500 rpm

5.0L V8 S/C Hp:

Approx. 510 hp @ 6000-6500 rpm (Supercharged variants, e.g., Supercharged trim)

5.0L V8 S/C Torque:

Approx. 461 lb-ft @ 2500-5500 rpm (Supercharged variants)

Fuel Delivery:

Electronic Fuel Injection (EFI), Direct Injection (DI) on later models/specific engines. Diesel Common Rail Injection.

V6 Supercharged Engine Code:

3.0L AJ126 (for 340hp variant)

V8 Supercharged Engine Code:

5.0L AJ-V8 Gen III SC (e.g., 508PS for 510hp variant)

V8 Naturally Aspirated Engine Code:

5.0L AJ-V8 Gen III NA (e.g., 508PN for 375hp variant)

V6 Diesel Engine Code:

3.0L TDV6 (e.g., 306DT)

🔧 Transmission

Transmission Type:

6-speed ZF Automatic (e.g., ZF 6HP26/6HP28)

Optional Transmissions:

N/A (All models in this generation typically came with the 6-speed automatic)

Drivetrain:

Permanent Four-Wheel Drive (4WD) with advanced Terrain Response system.

Automatic Transmission Fluid:

ZF LifeguardFluid 6 (or equivalent such as Shell M-1375.4 or Pentosin ATF1)

📐 Dimensions

Length:

Approx. 4950 mm (194.9 inches)

Width:

Approx. 2000 mm (78.7 inches) (excluding mirrors)

Height:

Approx. 1795 mm (70.7 inches) (adjustable air suspension)

Seating Capacity:

5 or 5+2 (optional third row)

Cargo Volume Rear Seats Up:

Approx. 958 liters (33.8 cubic feet)

Cargo Volume Rear Seats Down:

Approx. 2085 liters (73.6 cubic feet)

Curb Weight:

Varies significantly by engine and trim, generally 2200-2400 kg (4850-5300 lbs)

Gross Vehicle Weight Rating:

Typically around 3000-3200 kg (6600-7050 lbs)

Wheel Bolt Pattern:

5x120mm

Typical Tire Sizes:

255/50R20, 275/40R20, 275/45R21

🛡️ Safety Features

NHTSA Ratings:

Specific NHTSA ratings for this model year are varied and should be confirmed. Typically performed well in crash tests for its class.

IIHS Ratings:

Check IIHS ratings for specific years. Often rated 'Good' in relevant impact categories.

Electronic Stability Control:

Standard, includes Traction Control System (TCS), Dynamic Stability Control (DSC), Roll Stability Control (RSC).

Braking System:

Anti-lock Braking System (ABS), Electronic Brakeforce Distribution (EBD), Emergency Brake Assist (EBA), Hill Descent Control (HDC), Gradient Acceleration Control (GAC).

Off Road Systems:

Terrain Response System (e.g., Grass/Gravel/Snow, Mud/Ruts, Sand, Rock Crawl), Adaptive Dynamics.

Airbags:

Front airbags, front side airbags, full-length side curtain airbags. Optional front-seat side airbags for rear passengers.

Seatbelts:

Three-point seatbelts with pretensioners and load limiters for front seats. ISOFIX/LATCH child seat anchors.

Body Structure:

High-strength steel body structure, crumple zones.

💡 Technology Features

System Name:

Touchscreen Infotainment System (various iterations, often with navigation and premium audio options like Meridian Sound System)

Connectivity Options:

Bluetooth for phone and audio streaming, USB ports, auxiliary input.

Adaptive Cruise Control:

Optional, often with 'Adaptive Cruise Control with Forward Alert' and 'Queue Assist'.

Parking Aids:

Front and rear parking sensors, rearview camera, surround camera system (optional).

Blind Spot Monitoring:

Optional feature available on higher trims.

Keyless Entry Start:

Standard or optional keyless entry and push-button start.

Suspension System:

Adaptive Air Suspension with variable ride height and electronic damping control (Adaptive Dynamics).

All Wheel Drive System:

Advanced permanent 4WD with a two-speed transfer case (high/low range) and electronic center differential lock.

🔧 Maintenance

Oil Change Interval:

Typically 15,000 miles or 12 months, whichever comes first. Diesel engines may have different intervals. Consult manual for exact specifications.

Air Filter Replacement:

Every 30,000 miles or as needed based on driving conditions. Diesel engines may require more frequent checks.

Cabin Air Filter Replacement:

Every 15,000 miles or 12 months.

Transmission Fluid Change:

ZF recommends fluid and filter changes at 60,000 to 100,000 miles, or as per manufacturer's severe duty schedule. Consult manual for specific interval.

Coolant Replacement:

Initial fill for life, or specified interval (e.g., 10 years/150,000 miles) depending on coolant type. Refer to manual for specific type (e.g., Jaguar/Land Rover spec antifreeze).

Engine Oil Type:

API SN, ACEA C2/C3, SAE 5W-30 or 5W-40 (depending on specific engine and climate). Check manual for VIN specific requirements.

Engine Oil Capacity 3.0L V6 S/C:

Approx. 6.5 Liters (6.9 Quarts)

Engine Oil Capacity 5.0L V8:

Approx. 7.7 Liters (8.1 Quarts)

Coolant Type:

Jaguar/Land Rover Advanced Coolant (often a long-life pink/purple OAT coolant)

Brake Fluid Type:

DOT 4 LV (Low Viscosity) or equivalent

Air Suspension:

Potential for air spring leaks, compressor failure, or valve block issues over time. Common in many air-suspended vehicles.

Timing Chain Wear:

Early 5.0L V8 engines (especially the 'Ti' versions and some NA variants) were subject to timing chain stretch and tensioner wear, leading to rattling noises. Crucial to address promptly.

Supercharger Coupler Failure:

On supercharged models, the supercharger snout coupler can fail, leading to loss of boost and a distinctive whine or grinding noise.

Diesel Particulate Filter Issues:

Diesel models may experience DPF regeneration issues if not driven appropriately, potentially leading to clogged filters and warning lights.

Electrical Gremlins:

As with many complex luxury vehicles of this era, minor electrical issues or sensor faults can occur, often requiring specialized diagnostic tools covered by this manual.

Tsb Information Availability:

The factory service manual should contain references or detailed procedures for many Technical Service Bulletins (TSBs) issued by Land Rover.

📚 Vehicle History

Land Rover Legacy:

Land Rover has a long history of producing rugged, go-anywhere vehicles, with the Range Rover nameplate synonymous with luxury and off-road capability since its inception.

Range Rover Sport Origin:

The Range Rover Sport was introduced as a more sporting and agile alternative to the full-size Range Rover, based on the chassis of the LR3/Discovery 3.

L320 Generation Facelift:

The 2012-2014 models represent the L320 generation, which received a significant facelift for the 2010 model year, introducing updated styling, interior, and powertrain options. The 2012-2014 period represents the latter stages of this generation before the introduction of the L494.

Manufacturing Location:

Solihull, United Kingdom

Production Period:

L320 Generation: 2005-2013. The manual covers the final years of this generation.

🏆 Awards & Recognition

Off Road Capability Awards:

Consistently recognized for its off-road prowess and luxury credentials within the SUV segment.

Consumer Reports Ratings:

Ratings vary by model year and specific engine. Historically, Range Rover Sport has received mixed reviews regarding reliability but strong marks for performance and luxury. The manual helps mitigate reliability concerns.

Factory Standards:

This manual adheres to Land Rover's factory repair and maintenance standards, ensuring authenticity and accuracy.
