🏷️ Basic Information

Make:

Land Rover

Model:

Range Rover Sport

Model Code:

L494

Production Years Covered:

2014-2016

Engine Variants Covered:

TDV6 (3.0L Diesel), V6 (3.0L Supercharged Petrol), V8 (5.0L Supercharged Petrol)

👋 Introduction

Vehicle Segment:

Luxury SUV, Performance SUV

Brand Philosophy:

Combines off-road capability with on-road luxury and performance.

Key Competitors:

Porsche Cayenne, BMW X5, Mercedes-Benz GLE, Audi Q7, Volvo XC90.

Chassis Architecture:

Monocoque chassis (lighter and stiffer than previous body-on-frame).

Off Road Capability:

Terrain Response 2, All-Terrain Progress Control (ATPC), sophisticated four-wheel-drive system, wading depth.

On Road Performance:

Powerful engine options, adaptive air suspension, dynamic handling.

📋 Manual Details

Coverage Scope:

Full Service & Repair

Target Audience:

Professional Mechanics, Technicians, Enthusiasts

Estimated Page Count:

Hundreds of pages (specific count not provided, but described as extensive)

Type:

Factory Service Repair Workshop Manual

Language:

English

Format:

PDF Download

Accessibility:

Printable (single page or entire manual)

Device Compatibility:

Computers, Tablets, Smartphones (Windows & MAC compatible)

Licensing Model:

Lifetime Use, No Expiry, No Renewal Fees

Multi Device Usage:

Yes, usable on unlimited devices

📖 Manual Coverage

Engine Mechanical:

Engine assembly, disassembly, cylinder head, pistons, connecting rods, crankshaft, timing systems (chain/belt), lubrication, cooling system.

Engine Management:

Fuel injection systems (direct and indirect), ignition systems, emissions control, sensors, actuators, ECU diagnostics.

Transmission Automatic:

ZF 8-speed automatic transmission (specific model likely applicable), transmission fluid changes, torque converter, valve body, mechatronics unit, electronic control.

Transmission Transfer Case:

Four-wheel drive system, electronically controlled transfer case operation, maintenance, and repair.

Suspension:

Air suspension system, adaptive dynamics, control arms, bushings, springs, shock absorbers, height sensors, troubleshooting.

Brakes:

Hydraulic brake system, ABS, EBD, DSC (Dynamic Stability Control), brake fluid, pads, rotors, calipers, parking brake system, hydraulic component testing.

Steering:

Power steering system (likely electric or electro-hydraulic), steering rack, column, tie rods, alignment specifications.

Electrical System:

Battery, charging system, starter motor, lighting systems (headlights, taillights, interior), fuses, relays, wiring diagrams, grounds.

Body Exterior:

Body panels, doors, hood, tailgate, bumpers, glass, seals, exterior trim, alignment, repair procedures.

Body Interior:

Seats, dashboard, door panels, trim, headliner, carpeting, climate control vents, interior lighting.

Climate Control:

HVAC system, refrigerant, compressor, condenser, evaporator, cabin filter, blower motor, controls, troubleshooting.

Infotainment Navigation:

Audio system, navigation system, touch screen interface, connectivity modules, component replacement, basic troubleshooting.

Safety Systems:

Airbag system (SRS), seat belt pre-tensioners, occupant classification sensors, safety system diagnostics.

Maintenance Scheduled:

Oil changes, filter replacements (oil, air, cabin, fuel), fluid checks and top-offs, tire rotations, brake inspections.

Troubleshooting:

Diagnostic procedures for common and complex issues, fault code interpretation, symptom-based diagnosis.

Repair Major Component:

Engine rebuilds, transmission overhauls, suspension component replacement, brake system repairs.

Repair Minor Component:

Component replacement (e.g., starter, alternator, sensors, pumps), fluid line repairs, gasket replacements.

Diagnostics:

Use of diagnostic tools (e.g., OBD-II scanner), reading and clearing DTCs, live data analysis.

Wiring Diagrams:

Detailed electrical schematics for all vehicle systems.

Specifications Torque Values:

Torque specifications for all critical fasteners and component installations.

Installation Replacement:

Step-by-step instructions for replacing major and minor components.

Depth Level:

Comprehensive (covers everything from basic maintenance to complete engine rebuilds and complex diagnostics).

Visual Content:

Hundreds of detailed photos and diagrams, including exploded views.

📊 Manual Specifications

File Type:

PDF

Printability:

High-resolution, suitable for professional printing.

Binding Method:

N/A (Digital Download - PDF)

Paper Quality:

N/A (Digital Download - PDF)

⚙️ Engine Specifications

Tdv6 Engine:

3.0L V6 Turbocharged Diesel (likely 90-degree V6)

Tdv6 Power:

Approximately 255-258 hp (depending on specific variant and market)

Tdv6 Torque:

Approximately 440-443 lb-ft (depending on specific variant and market)

V6 Supercharged Engine:

3.0L V6 Supercharged Petrol (Jaguar Land Rover EcoBoost-derived)

V6 Supercharged Power:

Approximately 340-380 hp (depending on specific variant)

V6 Supercharged Torque:

Approximately 332-339 lb-ft

V8 Supercharged Engine:

5.0L V8 Supercharged Petrol (Jaguar Land Rover AJ-V8 Gen III)

V8 Supercharged Power:

Approximately 510 hp

V8 Supercharged Torque:

Approximately 461 lb-ft

Diesel Fuel Type:

Diesel (Common Rail Direct Injection)

Petrol Fuel Type:

Unleaded Petrol (Supercharged models likely use direct injection for V6, multi-point for V8, or a combination)

🔧 Transmission

Gearbox:

ZF 8HP70 (8-speed automatic transmission) across all engine variants.

Optional Gearbox:

None offered for this generation/model.

Drive System:

Permanent Four-Wheel Drive with electronically controlled central differential and optional Active Rear Locking Differential.

Transmission Fluid:

Specific ZF Lifeguard fluid required (e.g., ZF Lifeguard 8). Refer to manual for exact specification and capacity.

📐 Dimensions

Length:

Approx. 4,850 mm (190.9 in)

Width Excluding Mirrors:

Approx. 1,983 mm (78.1 in)

Height:

Approx. 1,780 mm (70.1 in) (with standard suspension)

Curb Weight:

Varies by engine, typically ranging from approx. 2,100 kg (4,630 lb) for TDV6 to over 2,300 kg (5,070 lb) for V8 Supercharged.

🛡️ Safety Features

NHTSA Rating:

Typically 4 or 5 stars (specific year/market dependent, often 5-star Euro NCAP).

Stability Control:

Dynamic Stability Control (DSC), Roll Stability Control (RSC), Trailer Stability Assist (TSA).

Braking Assistance:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Emergency Brake Assist (EBA).

Driver Assistance:

Adaptive Cruise Control (ACC), Autonomous Emergency Braking (AEB), Lane Departure Warning (LDW), Blind Spot Monitoring (BSM), Surround Camera System, Park Assist.

Airbags:

Front airbags, side airbags, curtain airbags, driver's knee airbag (configuration may vary).

Seat Belts:

Front and rear seat belts with pre-tensioners and load limiters.

💡 Technology Features

Infotainment System:

Touchscreen infotainment system with Meridian audio options, navigation, Bluetooth connectivity, USB ports.

Terrain Response 2:

Advanced system that automatically adjusts vehicle settings for optimal traction on various surfaces (sand, mud, rock, grass/gravel, snow).

All Terrain Progress Control:

Low-speed cruise control system for maintaining steady progress on challenging terrain.

Adaptive Dynamics:

Continuously variable damping system that monitors wheel movement and body motion to optimize ride and handling.

Connectivity Options:

Bluetooth for phone and audio streaming, USB ports, optional Wi-Fi hotspot.

🔧 Maintenance

Oil Change Interval:

Typically 15,000 miles or 12 months, whichever comes first (refer to manual for specific engine variant and operating conditions).

Air Filter Replacement:

Every 30,000 miles or as per manual recommendations.

Cabin Filter Replacement:

Every 15,000 miles or 12 months.

Transmission Fluid Change:

ZF recommends fluid changes at around 100,000 miles, but for heavy-duty use or towing, more frequent changes are advised. Refer to manual for specific guidance.

Engine Oil Petrol:

Synthetic oil, likely meeting Jaguar Land Rover specifications such as STJLR.03.5004 (e.g., 0W-20).

Engine Oil Diesel:

Synthetic oil, likely meeting specifications such as STJLR.51.5122 (e.g., 5W-30 low SAPS).

Coolant:

OAT (Organic Acid Technology) coolant, typically pink or orange, meeting Jaguar Land Rover specifications (e.g., STJLR.651.5003).

Brake Fluid:

DOT 4 LV (Low Viscosity) brake fluid.

Tdv6 Diesel Issues:

Potential for cracked cylinder heads (pre-2015 models), intake manifold swirl flap issues, EGR valve problems, diesel particulate filter (DPF) regeneration issues.

Supercharged Petrol Issues:

Water pump failure on early 3.0L V6, potential for carbon buildup on intake valves (direct injection), thermostat issues.

Air Suspension:

Compressor failure, air spring leaks, sensor failures, control module issues.

Electronics:

Infotainment system glitches, electronic parking brake faults, door lock actuator failures.

📚 Vehicle History

Land Rover Legacy:

Long history of producing capable off-road vehicles, luxury SUVs with a focus on versatility and capability.

L494 Generation:

Second generation Range Rover Sport (L494), launched in 2013 for the 2014 model year. Significant redesign with lighter aluminum construction and advanced technology.

Manufacturing Location:

Solihull, West Midlands, United Kingdom.

🏆 Awards & Recognition

Popular Mechanics Editor Choice:

While not specified for this exact manual, the L494 Range Rover Sport has received numerous awards for its design, performance, and off-road capability from various automotive publications and organizations.

Safety Ratings General:

Consistently high safety ratings from independent crash test agencies globally.
