🏷️ Basic Information

Make:

Lincoln

Model:

MKX

Year:

2016

Vehicle Type:

Mid-size Luxury Crossover SUV

Generation:

Second Generation (2016-2019)

Platform:

CD4 (shared with Ford Edge)

👋 Introduction

Market Position:

The 2016 Lincoln MKX occupied the mid-size luxury crossover segment, competing with vehicles like the Acura MDX, BMW X5, Audi Q7, and Lexus RX. It aimed to offer a blend of luxury, comfort, technology, and performance.

Competitive Analysis:

The second-generation MKX represented a significant step forward from its predecessor, with improved styling, a more premium interior, advanced technology, and the introduction of the 2.7L EcoBoost engine. This manual provides the specific technical data needed to maintain and repair this advanced vehicle, distinguishing it from generic repair guides.

Key Features:

Comprehensive, factory-specific repair data; detailed illustrations and diagrams; wiring schematics; step-by-step repair procedures; coverage of all major vehicle systems; digital format for easy access and printing.

📋 Manual Details

Coverage Areas:

All models, all repairs A-Z, specific to 2016 Lincoln MKX

Page Count:

Not specified, but described as comprehensive and complete.

Manual Type:

Factory Service and Repair Manual

Language:

English

Format:

PDF

📖 Manual Coverage

Systems Covered:

Maintenance, Engine, Control System, Mechanical, Fuel Service Specifications, Emission Control, Intake, Exhaust, Cooling, Lube, Ignition, Starting, Charging, Automatic Transmission, Clutch, Manual Transmission (if applicable), Transfer Case, Propeller Shaft, Drive Shaft, Differential, Axle, Suspension, Tire & Wheel, Brake Control, Brakes, Parking Brake, Steering Column, Power Steering, Air Conditioning, Supplemental Restraint System (SRS), Seat Belts, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Locks, Meter, Audio/Visual, Horn, Windshield/Glass/Mirrors, Instrument Panel, Seats, Engine Hood/Doors, Exterior & Interior Body, Electrical Systems, Multiplex/CAN Communication.

Procedures Included:

Step-by-step instructions for maintenance, servicing, diagnosis, and repair. Includes troubleshooting, diagnostics, component removal and installation, adjustments, specifications, and wiring schematics.

Technical Depth:

Factory-level detailed repair information, equivalent to what dealership technicians use. Covers basic to advanced repair and diagnostic procedures.

📊 Manual Specifications

File Format:

PDF

Print Quality:

High-quality, printable pages. Allows for enlarging images and printing specific sections.

Binding Type:

Digital (PDF format), no physical binding.

Paper Type:

N/A (Digital format). Printable on standard paper.

⚙️ Engine Specifications

Primary Engine:

3.7L Ti-VCT V6 Atkinson Cycle (for North American Market)

3.7L V6 Horsepower:

303 hp @ 6500 rpm

3.7L V6 Torque:

278 lb-ft @ 4000 rpm

2.7L Ecoboost V6 Horsepower:

325 hp @ 5500 rpm

2.7L Ecoboost V6 Torque:

375 lb-ft @ 3000 rpm

Optional Engine:

2.7L EcoBoost V6 Twin-Turbocharged

Fuel System:

Electronic Fuel Injection (EFI) with Port Fuel Injection (PFI) for 3.7L V6 and Direct Injection (DI) for 2.7L EcoBoost V6.

3.7L V6 Engine Code:

Cyclone 3.7L

2.7L Ecoboost Engine Code:

EcoBoost 2.7L V6

🔧 Transmission

Standard Transmission:

6F50 SelectShift Automatic Transmission

Optional Transmission:

N/A for this model year, only automatic available.

Transmission Features:

Available with front-wheel drive (FWD) or Intelligent All-Wheel Drive (AWD). Features SelectShift functionality for manual gear selection via paddle shifters.

📐 Dimensions

Wheelbase:

112.2 inches (2850 mm)

Length:

193.4 inches (4912 mm)

Width:

76.9 inches (1953 mm)

Height:

64.1 inches (1628 mm)

Curb Weight Minimum:

4,145 lbs (1880 kg) (FWD)

Curb Weight Maximum:

4,404 lbs (1998 kg) (AWD)

Cargo Volume Behind 2Nd Row:

34.0 cubic feet (963 liters)

Cargo Volume With 2Nd Row Folded:

60.8 cubic feet (1722 liters)

🛡️ Safety Features

NHTSA Overall Rating:

5-Star (for 2016 models)

IIHS Top Safety Pick:

Yes (when equipped with optional front crash prevention)

Active Safety Features:

Anti-lock Braking System (ABS), Electronic Stability Control (ESC), Traction Control System (TCS), Brake Assist, AdvanceTrac with Roll Stability Control, Tire Pressure Monitoring System (TPMS), available Adaptive Cruise Control, available Blind Spot Information System (BLIS), available Lane Keeping System, available Pre-Collision Assist with Pedestrian Detection.

Passive Safety Features:

Front airbags, front side impact airbags, Safety Canopy® side-curtain airbags with rollover protection, front seatbelt pretensioners, rear child seat anchors (LATCH).

💡 Technology Features

Infotainment System:

SYNC 3 with an 8-inch touchscreen display.

Infotainment Features:

Voice-activated navigation, Apple CarPlay, Android Auto compatibility, Bluetooth connectivity, SiriusXM Radio, dual USB ports.

Driver Assistance Features:

Available features include Adaptive Cruise Control, Blind Spot Information System (BLIS) with Cross-Traffic Alert, Lane-Keeping System, Pre-Collision Assist with Pedestrian Detection, Parallel Park Assist, and a 360-degree camera system.

Connectivity Options:

FordPass Connect with Wi-Fi hotspot capability (optional), smartphone integration via SYNC 3.

Comfort Convenience Features:

Available features like Revel® premium audio system, heated and ventilated front seats, heated rear seats, power-adjustable steering column, panoramic sunroof, hands-free liftgate.

🔧 Maintenance

Oil Change Interval:

Every 7,500 to 10,000 miles (12,000 to 16,000 km) or 12 months, whichever comes first, depending on driving conditions and oil type used. Refer to manual for specific recommendations.

Tire Rotation Interval:

Every 7,500 miles (12,000 km)

Engine Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed.

Cabin Air Filter Replacement:

Every 20,000 miles (32,000 km) or as needed.

Engine Oil Type 3.7L:

SAE 5W-30 Synthetic Blend (WSS-M2C946-B1 or equivalent)

Engine Oil Type 2.7L Ecoboost:

SAE 0W-30 Full Synthetic (WSS-M2C947-B1 or equivalent)

Coolant Type:

Ford Super High Performance Coolant (VC-3D1) or equivalent orange coolant, mixture of 50/50 with distilled water.

Transmission Fluid Type:

MERCON® LV Automatic Transmission Fluid (ATF)

Brake Fluid Type:

DOT 4 Motor Vehicle Brake Fluid

Known Issues:

Potential issues include occasional water pump leaks on the 2.7L EcoBoost, sporadic door handle illumination failures, and occasional infotainment system glitches. The manual provides diagnostic and repair procedures for these and other potential issues.

Oil Filter Part Number (Example 3.7L):

Motorcraft FL-500S or equivalent

Oil Filter Part Number (Example 2.7L Ecoboost):

Motorcraft FA-1927 or equivalent

📚 Vehicle History

Brand Heritage:

Lincoln, a division of Ford Motor Company, has a long-standing reputation for producing luxury vehicles, emphasizing comfort, quietness, and upscale amenities.

Model Evolution:

The 2016 MKX marked the debut of the second generation, a significant redesign. It moved to the Ford CD4 platform, which it shared with the Ford Edge. This generation introduced a more distinctive Lincoln design language, improved interior materials, and enhanced technology.

Production Location:

Oakville Assembly Plant, Ontario, Canada

🏆 Awards & Recognition

Recognitions:

The 2016 Lincoln MKX received positive reviews for its redesigned styling, comfortable interior, and the availability of the potent 2.7L EcoBoost engine. While specific awards for the 2016 model year might vary, it was generally well-regarded within its segment for offering a luxurious experience at a competitive price point.
