Segment:
Mid-size Crossover SUV
Target Audience:
Families seeking spacious, stylish, and capable three-row seating.
Key Competitors:
Toyota Highlander, Honda Pilot, Ford Explorer, Chevrolet Traverse, Nissan Pathfinder.
Design Philosophy:
Mazda's Kodo Design language, emphasizing dynamic and elegant styling.
Driving Dynamics:
Focus on 'Jinba Ittai' (horse and rider as one) driving feel, agile handling for its class.
Scope:
Complete Workshop Service Repair Manual
Coverage Level:
All models and all repairs A-Z, specific to model
Page Count:
Extensive (typically 2000+ pages for comprehensive workshop manuals)
Type:
Workshop Service Repair Manual
Format:
Digital (likely PDF), potentially printable
Engine Systems:
Engine mechanical, fuel system, ignition system, cooling system, lubrication system, exhaust system, engine management (ECU), emissions control.
Transmission Systems:
Automatic transmission (ATX), driveline, transfer case, differentials, axles, driveshafts.
Braking Systems:
Brake system hydraulics, calipers, rotors, pads, ABS, DSC (Dynamic Stability Control), EBD (Electronic Brakeforce Distribution).
Suspension Steering:
Front suspension, rear suspension, shock absorbers, springs, steering gear, power steering system, wheel alignment.
Electrical Electronics:
Starting and charging system, lighting system, instrument cluster, HVAC controls, power windows, power locks, body control modules (BCM), infotainment system, wiring diagrams.
Body Chassis:
Body structure, exterior panels, interior trim, doors, glass, HVAC system, exhaust, fuel tank, bumpers.
Maintenance:
Routine maintenance procedures, oil changes, filter replacements, fluid checks and changes, spark plug replacement, belt replacement.
Diagnostics Troubleshooting:
Diagnostic trouble codes (DTCs), symptom-based troubleshooting guides, electrical diagnostic procedures, common fault diagnosis.
Repair Overhaul:
Engine component removal and installation, transmission overhaul, brake component replacement, suspension and steering component repair, body panel repair.
Special Tools:
Identification and usage of special tools required for specific repair operations.
Depth:
Comprehensive (from basic maintenance to complete engine and transmission rebuilds, including diagnostic procedures and wiring schematics).
Engine Type:
3.7L V6 Naturally Aspirated
Configuration:
V-6, 24-valve, DOHC (Dual Overhead Camshafts), S-VT (Suzuki Variable Valve Timing)
Bore X Stroke:
95.5 mm x 86.6 mm
Displacement:
3726 cc (227.3 cubic inches)
Horsepower:
273 hp @ 6250 RPM
Torque:
270 lb-ft @ 4000 RPM
Fuel Delivery:
Electronic Multi-Port Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline, 87 octane (minimum)
Emission Control:
Federal Tier 2 Bin 5 / California LEV II compliant
Length:
191.5 inches (4864 mm)
Width:
78.5 inches (1994 mm)
Height:
68.0 inches (1727 mm)
Wheelbase:
113.2 inches (2875 mm)
Ground Clearance:
7.5 inches (190 mm)
Passenger Volume:
Approximately 145.5 cubic feet
Cargo Volume Behind 3Rd Row:
Approximately 14.4 cubic feet
Cargo Volume Behind 2Nd Row:
Approximately 40.0 cubic feet
Cargo Volume Behind 1St Row:
Approximately 75.2 cubic feet
Curb Weight:
4,500 - 4,700 lbs (approximately, depending on drivetrain and trim)
Towing Capacity:
Up to 4,500 lbs (with optional Towing Package)
NHTSA Overall Rating:
Likely 4 or 5 stars (check specific model year reports)
Traction Control:
TCS (Traction Control System)
Stability Control:
DSC (Dynamic Stability Control) with rollover detection.
Braking Assistance:
ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution), Brake Assist.
Airbags:
Front airbags, front side-impact airbags, three-row side-curtain airbags.
Seat Belts:
Three-point seat belts with pretensioners and load limiters, LATCH (Lower Anchors and Tethers for Children) system.
Body Structure:
Advanced front and rear crumple zones, reinforced passenger compartment.
Display System:
Mazda Connect infotainment system with a 7-inch touchscreen (available on certain trims or as an option).
Audio Options:
Bose premium audio system (available), SiriusXM Satellite Radio, USB/iPod connectivity, Bluetooth hands-free phone and audio streaming.
Blind Spot Monitoring:
BLIS (Blind Spot Information System) - available on higher trims.
Rearview Camera:
Standard or available rearview camera.
Parking Assist:
Rear parking sensors (available).
Bluetooth:
Standard Bluetooth for hands-free calling and audio streaming.
Oil Change:
Every 5,000 to 7,500 miles or 6 months, whichever comes first (depending on driving conditions and oil type used).
Tire Rotation:
Every 7,500 miles or 6 months.
Engine Air Filter:
Inspect every 15,000 miles, replace as needed (typically every 30,000 miles).
Cabin Air Filter:
Inspect every 15,000 miles, replace as needed (typically every 15,000-30,000 miles).
Spark Plugs:
Replace every 75,000 miles (Long-life iridium type).
Transmission Fluid:
Inspect every 30,000 miles, replace at 60,000-100,000 miles depending on usage and manufacturer recommendation.
Engine Oil Type:
SAE 0W-20 (API SN or ILSAC GF-5 certified)
Engine Oil Capacity:
5.5 US quarts (5.2 liters) with filter.
Coolant Type:
Mazda Genuine Long Life Antifreeze (Blue) or equivalent HOAT coolant.
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid.
Common Wear Items:
Brake pads and rotors, tires, suspension components (bushings, ball joints), power steering components, catalytic converter (in high-mileage vehicles).
Engine Notes:
The 3.7L V6 is generally robust but can experience oil consumption if not maintained properly. Some reports of sticky throttle bodies.
Transmission Notes:
While generally reliable, some owners have reported occasional harsh shifts or hesitation. Regular fluid changes are crucial.
Electrical Notes:
Potential issues with infotainment system glitches, HVAC control module failures, and power accessory malfunctions are not uncommon in vehicles of this age.
Brand Focus:
Mazda is known for its focus on driving dynamics, innovative technology (e.g., SKYACTIV), and distinctive design.
First Generation:
The CX-9 was introduced for the 2007 model year as Mazda's first full-size crossover SUV.
2014 Update:
The 2014 model year received a mid-cycle refresh, including updated exterior styling (grille, headlights, taillights), revised interior, and improved features.
Assembly Location:
Ujina Plant No. 1, Hiroshima, Japan.
