Mazda CX5 CX-5 Workshop Service Repair Wiring Manual

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Mazda Model: CX-5 Model Code: KE Product Name: Mazda CX-5 CX-5 Workshop Service Repair Wiring Manual Codes Applicable Years: 2013, 2014 👋 Introduction Market Position...

29 people are viewing this right now

类型: Car

斯库: 358753

标签: Car Cars CX Models CX-5 CX5 Featured Mazda

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Mazda

Model:

Model Code:

Product Name:

Mazda CX-5 CX-5 Workshop Service Repair Wiring Manual

Codes

Applicable Years:

2013, 2014

👋 Introduction

Market Position

Segment:

Compact Crossover SUV

Target Audience:

Families, individuals seeking versatility and a refined driving experience

Competitive Analysis

Key Competitors:

Honda CR-V, Toyota RAV4, Nissan Rogue, Ford Escape, Subaru Forester

Key Features

Driving Dynamics:

Mazda's 'Jinba Ittai' (horse and rider as one) philosophy, responsive handling, refined ride quality

Design:

Kodo design language, premium interior appointments

Engine Technology:

SKYACTIV-G engine technology focusing on efficiency and performance

📋 Manual Details

Coverage Areas

Scope:

Comprehensive workshop service, repair, and wiring

Additional Coverage:

Bodyshop procedures

Page Count

Estimated Pages:

Varies by specific edition, but expected to be extensive (typically 1000+ pages for full workshop manuals)

Manual Type

Type:

Workshop Service Repair Manual (including Wiring Diagrams)

Language

Language:

English

Format

Format:

Digital (likely PDF, potentially with searchability and hyperlinking)

📖 Manual Coverage

Systems Covered

Powertrain:

Engine mechanical, fuel system, ignition system, cooling system, exhaust system, engine control systems (ECU/PCM)

Drivetrain:

Transmission (automatic and manual), transfer case (if applicable for AWD), drive shafts, differentials, axles

Chassis:

Suspension (front and rear), steering system, braking system (including ABS and EBD)

Electrical:

Wiring diagrams (detailed, by circuit), lighting systems, audio system, power accessories, ignition switch, battery, alternator, starter

Body:

Exterior body panels, interior trim, doors, windows, locks, mirrors, windshield wipers, HVAC (heating, ventilation, air conditioning)

Safety Systems:

Airbag system, seatbelt pre-tensioners, active safety features (if applicable to the year/trim)

Procedures Included

Maintenance:

Routine service, oil changes, filter replacements, fluid checks and changes, spark plug replacement, belt inspection/replacement

Repair:

Engine overhaul, transmission repair/rebuild, suspension component replacement, brake caliper/rotor replacement, electrical component diagnosis and replacement

Diagnostics:

Troubleshooting guides, diagnostic trouble codes (DTCs) interpretation, symptom-based diagnostics

Installation:

Component removal and installation for major assemblies and sub-assemblies

Bodyshop:

Panel alignment, repair techniques, welding specifications, paint preparation and application guidance

Technical Depth

Depth:

Expert-level detail for professional technicians and advanced DIY enthusiasts

Diagnostic Tools:

Information on using diagnostic scan tools, multimeter usage, oscilloscope interpretation

Technical Specifications:

Torque specifications, clearances, alignment angles, electrical resistance values

📊 Manual Specifications

File Format

Digital Format:

Searchability:

Likely text-searchable PDF for quick information retrieval

Print Quality

Quality:

High-resolution for clear diagrams and text

Binding Type

Binding:

N/A (Digital Format)

Paper Type

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Primary Engine

Engine Code Gasoline:

PY-VPS (2.0L), PE-VPS (2.5L)

Displacement 2.0L:

1998 cc

Displacement 2.5L:

2488 cc

Performance

Horsepower 2.0L:

148 hp @ 6000 rpm

Torque 2.0L:

193 Nm (142 lb-ft) @ 4100 rpm

Horsepower 2.5L:

184 hp @ 5700 rpm

Torque 2.5L:

245 Nm (180 lb-ft) @ 4000 rpm

Fuel System

Injection Type:

Direct Injection (SKYACTIV-G)

Fuel Type:

Unleaded Gasoline

Engine Internals

Bore Stroke 2.0L:

83.5 mm x 91.2 mm

Bore Stroke 2.5L:

89.0 mm x 99.7 mm

Compression Ratio 2.0L:

13.0:1

Compression Ratio 2.5L:

13.0:1

🔧 Transmission

Standard

Transmission Type:

6-speed Automatic (SKYACTIV-DRIVE)

Optional

Transmission Type:

6-speed Manual (less common in North America)

Features

Automatic Features:

Lock-up torque converter, sport mode, manual shift mode (Activematic)

Fluid Specifications

Automatic Transmission Fluid Type:

Mazda Genuine ATF FZ (or equivalent)

Manual Transmission Fluid Type:

Mazda Genuine Gear Oil (e.g., 75W-90 GL-4)

📐 Dimensions

Exterior

Length:

4540 mm (178.7 in)

Width:

1840 mm (72.4 in)

Height:

1670 mm (65.7 in)

Wheelbase:

2700 mm (106.3 in)

Interior

Front Headroom:

Approx. 1000-1020 mm (39.4-40.2 in)

Rear Headroom:

Approx. 970-990 mm (38.2-39.0 in)

Cargo

Cargo Volume Seats Up:

Approx. 580 liters (20.5 cu ft)

Cargo Volume Seats Down:

Approx. 1560 liters (55.1 cu ft)

Weights

Curb Weight FWD:

Approx. 1520-1550 kg (3350-3417 lbs)

Curb Weight AWD:

Approx. 1580-1620 kg (3483-3571 lbs)

Towing Capacity:

Typically up to 1500 lbs (680 kg) with factory tow package

🛡️ Safety Features

Ratings

NHTSA Overall Rating:

5-Star (for models equipped with specific safety features)

IIHS Top Safety Pick:

Yes (for models with specific equipment/build dates)

Active Features

Brake Assist:

Standard

Electronic Stability Control:

DSC (Dynamic Stability Control) with TCS (Traction Control System) - Standard

All Wheel Drive:

Optional (i-ACTIV AWD system)

Blind Spot Monitoring:

Optional (BSM)

Lane Departure Warning:

Optional (LDW) - Not widely available on 2013-2014 models, more common in later updates

Passive Features

Airbags:

Front, side-impact, and curtain airbags

Seatbelts:

3-point front seatbelts with pretensioners and load limiters, 3-point rear seatbelts

Child Seat Anchors:

LATCH (Lower Anchors and Tethers for Children) system

💡 Technology Features

Infotainment

Display System:

7-inch touchscreen display (Mazda Connect system on higher trims)

Audio System:

Bose premium audio system available on select trims

Connectivity:

Bluetooth hands-free phone and audio streaming, USB/iPod input, Pandora/Stitcher integration (via smartphone)

Driver Assistance

Reverse Camera:

Standard on most trims for 2013-2014

Smart City Brake Support:

Optional (SCBS) - Available on higher trims, operates at lower speeds.

Connectivity

Navigation System:

Optional

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 7,500 miles (12,000 km) or 12 months, whichever comes first, under normal driving conditions. Consult manual for severe conditions.

Air Filter Replacement:

Inspect every 15,000 miles (24,000 km), replace as needed or at recommended intervals (e.g., 30,000 miles).

Cabin Air Filter Replacement:

Inspect annually, replace as needed (e.g., every 15,000-20,000 miles).

Spark Plug Replacement:

Typically around 75,000 miles (120,000 km) for iridium spark plugs.

Brake Fluid Change:

Recommended every 2-3 years or as per mileage intervals (e.g., 30,000 miles).

Fluid Specifications

Engine Oil Type:

SAE 0W-20, API SN or ILSAC GF-5 compliant (check manual for exact specification)

Engine Oil Capacity 2.0L:

Approx. 4.8 quarts (4.5 liters) with filter

Engine Oil Capacity 2.5L:

Approx. 5.0 quarts (4.7 liters) with filter

Coolant Type:

Mazda Genuine FL22 Long Life Antifreeze/Coolant (or equivalent Super Long Life Coolant)

Coolant Capacity:

Approx. 7.4-7.6 quarts (7.0-7.2 liters)

Known Issues

Common Complaints:

Reports of oil consumption in some 2.5L engines (may require specific piston ring upgrades), potential for exhaust manifold cracks on early models, infotainment system glitches.

Maintenance Tips:

Regularly check oil level, especially for the 2.5L engine. Ensure proper coolant mixture. Inspect drive belts for wear.

📚 Vehicle History

Brand Heritage

Manufacturer:

Mazda Motor Corporation, Japan

Model Evolution

First Generation Debut:

2012 (Globally), 2013 (North America)

First Generation Codes:

KE (2012-2016)

Facelift Updates:

Minor updates during the first generation, with a significant facelift in 2016 (post-2014 models covered here are pre-facelift).

Production

Assembly Locations:

Japan, Thailand, Malaysia, Vietnam, Colombia, Russia

🏆 Awards & Recognition

Recognitions

IIHS Award:

IIHS Top Safety Pick

Auto Theft Prevention:

Some models may have included immobilizer systems

Ratings

Consumer Reports Reliability:

Generally good to excellent reliability ratings from various automotive publications.

Certifications

Emission Standards:

Meets EPA and CARB emission standards for its model year.

📄 Wheel Tire

Wheel Specs

Wheel Size Standard:

17-inch alloy wheels

Wheel Size Optional:

18-inch or 19-inch alloy wheels

Bolt Pattern:

5x114.3 mm (5x4.5 inches)

Center Bore:

67.1 mm

Tire Specs

Standard Tire Size 17In:

225/65R17

Optional Tire Size 18In:

225/55R18

Optional Tire Size 19In:

225/55R19

Recommended Tire Pressure:

Typically 32-35 PSI, refer to vehicle placard.
