🏷️ Basic Information

Make:

Mercedes-Benz

Model:

560SL

Generation:

R107

Model Code:

C107 (Coupe) / R107 (Roadster)

Body Style:

2-door convertible roadster

Applicable Years:

1986, 1987, 1988, 1989

Chassis Code:

R107

👋 Introduction

Market Segment:

Luxury Grand Tourer (GT) convertible, positioned as a flagship model for Mercedes-Benz during its production run.

Competitors:

Competed with other high-end luxury convertibles of the era, such as the Jaguar XJS, Porsche 944 Cabriolet, and BMW 6 Series convertible.

Salient Features:

Robust V8 engine, exceptional build quality, comfortable ride, legendary Mercedes-Benz engineering, iconic styling, high level of luxury appointments.

Value:

Empowers owners and independent technicians with factory-level information, reducing reliance on dealerships, saving significant costs on maintenance and repairs, and enabling better informed discussions with mechanics.

Target Audience:

Car owners with basic mechanical skills, independent auto service professionals, and authorized dealer service departments.

📋 Manual Details

Coverage:

Comprehensive service, repair, and troubleshooting for the Mercedes-Benz 560SL models from 1986 to 1989.

Page Count:

Estimated 1000+ pages (typical for comprehensive factory-level manuals of this era, exact count not specified but implied by depth).

Manual Type:

Factory-authorized Service/Repair/Workshop Manual

Language:

English

Format:

PDF

Download Speed:

Speed Download enabled.

Printability:

Fully printable, allowing users to print specific sections or entire chapters for use in the workshop, avoiding damage to the digital file.

Completeness:

Stated to be complete and intact, with no missing or corrupt parts/pages, ensuring full coverage of all topics.

📖 Manual Coverage

Systems:

Engine Mechanical System, Engine Electrical System, Emission Control System, Fuel System, Clutch System, Manual Transaxle System, Automatic Transaxle System, Driveshaft and Axle, Suspension System, Steering System, Restraint System, Brake System, Body (Interior and Exterior), Body Electrical System, Heating, Ventilation, Air Conditioning (HVAC).

Procedures:

Step-by-step repair instructions, diagnostic procedures, troubleshooting guides, maintenance schedules, component removal and installation, adjustments, specifications, torque values, wiring diagrams.

Depth:

Factory-level, in-depth coverage suitable for professional mechanics and skilled DIY enthusiasts. Includes detailed diagrams and illustrations for complex procedures.

Diagnostic Information:

Includes guidance on using diagnostic tools and interpreting error codes (where applicable for the era's technology).

Wiring Schematics:

Detailed wiring schematics and diagrams for all electrical systems, crucial for troubleshooting.

📊 Manual Specifications

File Format Details:

Adobe PDF, viewable on PC, Mac, and most mobile/e-reader devices. Searchable text.

Print Quality:

High-resolution, suitable for printing individual pages or the entire manual. Preserves clarity of diagrams and text.

Binding Type:

Digital (PDF), printable pages allow for custom binding.

Paper Type Suitability:

Ideal for printing on standard A4 or Letter paper for workshop use.

Operating Systems:

Compatible with all versions of Windows and Mac operating systems.

⚙️ Engine Specifications

Engine Type:

SOHC V8

Displacement:

5.6 Liters (5547 cc)

Bore X Stroke:

94.5 mm x 98.5 mm

Compression Ratio:

8.0:1

Fuel Delivery:

Bosch K-Jetronic (CIS-E - Continuous Injection System - Electronic)

Horsepower:

227 hp @ 4750 rpm (US-spec)

Torque:

285 lb-ft @ 3250 rpm (US-spec)

Ignition System:

Electronic ignition with dual spark plugs per cylinder (for improved combustion efficiency).

Cooling System Type:

Water-cooled

Oil Capacity:

8.0 US quarts (7.6 Liters) with filter

Engine Code:

M117 (various sub-designations)

Emission Control Systems:

Catalytic converter, exhaust gas recirculation (EGR) system, and secondary air injection (depending on market).

🔧 Transmission

Transmission Type:

4-speed Automatic Transmission

Optional Transmission:

Not typically offered with manual transmission in the US market for the 560SL. The manual listed under 'Clutch System' and 'Manual Transaxle System' may be for other Mercedes models or to cover general mechanical principles that could apply broadly.

Transmission Features:

Lock-up torque converter for improved fuel efficiency at cruising speeds.

📐 Dimensions

Length:

4575 mm (180.1 in)

Width:

1790 mm (70.5 in)

Height:

1305 mm (51.4 in)

Wheelbase:

2460 mm (96.9 in)

Curb Weight:

1770 kg (3902 lbs)

Gross Vehicle Weight Rating:

2170 kg (4784 lbs)

Standard Wheel Size:

15 x 7.0 inches

Standard Tire Size:

205/65VR15

Wheel Bolt Pattern:

5 x 112 mm

🛡️ Safety Features

Safety Certification:

Designed to meet all applicable safety standards of its era. Specific crash test ratings from modern organizations are not directly comparable due to evolving standards.

Passive Safety Features:

Reinforced A-pillars and windshield frame, energy-absorbing steering wheel, padded dashboard and interior surfaces, three-point seatbelts.

Active Safety Features:

Four-wheel Anti-lock Braking System (ABS), power steering.

💡 Technology Features

Audio System:

Factory premium sound system, often with cassette player. Aftermarket upgrades are common.

Driver Aid Systems:

ABS (Anti-lock Braking System).

Climate Control:

Automatic Climate Control (often vacuum-controlled, requiring specific diagnostic procedures).

Seats:

Power-adjustable front seats with memory, heated seats (optional).

Cruise Control:

Standard

🔧 Maintenance

Oil Change Interval:

Typically every 5,000 miles (8,000 km) or 6 months, whichever comes first, depending on driving conditions. Manual will specify exact intervals.

Tune Up Interval:

Spark plugs typically every 30,000 miles (48,000 km). Air filter and fuel filter replacements at recommended intervals in the manual.

Engine Oil Type:

API SF or SG, SAE 15W-40 or 10W-40 (check manual for exact viscosity recommendations based on climate).

Transmission Fluid Type:

MB 236.1 specification Automatic Transmission Fluid (e.g., Dexron II or equivalent).

Coolant Type:

Ethylene glycol-based antifreeze mixture (50/50 with distilled water).

Brake Fluid Type:

DOT 3 or DOT 4.

Common Wear Items:

Fuel system components (especially injector seals and fuel distributor), vacuum lines, front suspension bushings, timing chain (though robust, it requires inspection), climate control system (often vacuum-actuated).

Body Concerns:

Rust can be a concern on older models, particularly in areas around the wheel arches, rocker panels, and convertible top well.

Transmission Fluid Capacity:

Approximately 8.5 US quarts (8.0 Liters) for fluid change, higher for complete rebuild/flush. Manual will provide precise figure.

Coolant Capacity:

Approximately 10.5 US quarts (9.9 Liters). Manual will provide precise figure.

📚 Vehicle History

Brand Essence:

Mercedes-Benz is synonymous with engineering excellence, luxury, safety, and durability, with a long history of innovation in automotive technology.

R107 Lineage:

The R107 chassis was produced from 1971 to 1989, making it one of the longest-produced Mercedes-Benz platforms. The 560SL, introduced in 1986, represented the most powerful and luxurious iteration of the SL roadster.

Production Period For 560Sl:

1986-1989

Manufacturing Location:

Sindelfingen, West Germany

🏆 Awards & Recognition

Brand Reputation:

Mercedes-Benz vehicles of this era are consistently recognized for their build quality, longevity, and engineering.

Collectible Status:

The 560SL is highly regarded by enthusiasts and collectors for its combination of performance, luxury, and timeless design, often appreciating in value.

📄 Suspension

Front Suspension Type:

Independent, double-wishbone with coil springs and telescopic shock absorbers.

Rear Suspension Type:

Independent, semi-trailing arm with coil springs and telescopic shock absorbers.

📄 Steering

Steering Type:

Recirculating ball power steering.
