🏷️ Basic Information

Make:

Mercedes-Benz

Model:

ML Class

Chassis Code:

W164

Model Year:

2010

Generation:

Second Generation (W164)

Generation Years:

2005-2011

👋 Introduction

Vehicle Segment:

Mid-size luxury SUV (Sport Utility Vehicle)

Brand Positioning:

Premium, known for luxury, comfort, advanced technology, and robust engineering.

Key Competitors:

BMW X5, Audi Q7, Lexus RX, Porsche Cayenne, Land Rover LR4.

Vehicle Highlights:

Spacious and luxurious interior, powerful engine options, advanced safety features, capable all-wheel drive (4MATIC), refined ride quality, high-quality materials.

Manual Value Proposition:

Enables owners and technicians to perform comprehensive maintenance and repairs, saving significant costs compared to dealership service, while ensuring proper vehicle upkeep and longevity.

📋 Manual Details

Coverage Scope:

Complete workshop service and repair

Model Variants Covered:

All models, engines, trim levels, and transmission types within the W164 ML Class for the 2010 model year.

Page Count Estimate:

Extensive (likely several thousand pages, typical for comprehensive workshop manuals)

Manual Type:

Workshop Service Repair Manual

Language:

English

Digital Format:

Downloadable PDF

📖 Manual Coverage

Powertrain Systems:

Engine mechanical, engine electrical, fuel system, lubrication system, cooling system, exhaust system, powertrain control module (PCM) diagnosis and repair.

Transmission Drivetrain:

Automatic transmission (e.g., 7G-TRONIC), transfer case, drive shafts, differentials, axles, CV joints, and related control systems.

Chassis Systems:

Brake system (including ABS, ESP), steering system (hydraulic/electric power steering), suspension system (AIRMATIC, independent suspension), wheels, and tires.

Electrical Electronics:

Body control module (BCM), comfort systems (seats, windows, sunroof, climate control), lighting systems (headlights, taillights, interior), infotainment, instrument cluster, diagnostic systems (OBD-II), CAN bus communication, wiring diagrams.

Body Interior:

Body repair, interior trim, upholstery, airbags, seat belts, doors, windows, body sealing, and paint repair.

Maintenance Procedures:

Routine maintenance schedules, fluid changes (engine oil, coolant, brake fluid, transmission fluid, differential fluid), filter replacements (oil, air, fuel, cabin), spark plug replacement, belt replacement, brake pad and rotor replacement.

Diagnostic Procedures:

Troubleshooting common symptoms, fault code diagnosis (DTCs), diagnostic tool usage, electrical system diagnostics, component testing.

Repair Procedures:

Component removal and installation (engine, transmission, suspension parts, brakes, electrical modules), engine overhaul, transmission overhaul, body panel replacement, interior component repair.

Specifications And Tolerances:

Torque specifications, clearances, fluid capacities, electrical component resistance/voltage values, alignment specifications.

Depth Of Coverage:

Comprehensive: from basic scheduled maintenance and fluid checks to advanced diagnostics and complete mechanical/electrical system overhauls and rebuilds.

📊 Manual Specifications

File Format:

PDF

Searchability:

Searchable text content

Print Quality:

High-resolution, suitable for clear printing of text and diagrams

Illustrations:

Step-by-step diagrams, exploded views, and photographic illustrations

Binding Type For Print:

N/A (Downloadable digital format)

Paper Type For Print:

N/A (Downloadable digital format)

Required Software:

Adobe Reader (or compatible PDF viewer)

⚙️ Engine Specifications

Engine Options 2010:

Likely includes: ML350 (3.5L V6), ML550 (5.5L V8), ML63 AMG (6.2L V8).

Ml350 Engine Code:

M272 (or M276 for later models, though 2010 likely M272)

Ml350 Horsepower:

Approx. 268 hp

Ml350 Torque:

Approx. 258 lb-ft

Ml550 Engine Code:

M273

Ml550 Horsepower:

Approx. 382 hp

Ml550 Torque:

Approx. 391 lb-ft

Ml63 Amg Engine Code:

M156

Ml63 Amg Horsepower:

Approx. 507 hp

Ml63 Amg Torque:

Approx. 450 lb-ft

Fuel Delivery:

Electronic fuel injection (EFI)

Fuel Type:

Premium Unleaded Gasoline

🔧 Transmission

Standard Transmission:

7-speed automatic transmission (7G-TRONIC)

Optional Transmission:

N/A (7G-TRONIC was standard across most models)

Transmission Features:

Selectable drive modes (Comfort, Sport), manual shift mode (TouchShift paddles or selector lever), electronic control.

Drivetrain:

4MATIC all-wheel drive (standard on most models)

📐 Dimensions

Length:

Approx. 189.1 inches (4803 mm)

Width:

Approx. 75.4 inches (1915 mm)

Height:

Approx. 71.0 inches (1803 mm)

Wheelbase:

Approx. 114.7 inches (2915 mm)

Curb Weight Ml350:

Approx. 4,707 lbs (2,135 kg)

Towing Capacity:

Up to 7,000 lbs (3,175 kg) with optional towing package

🛡️ Safety Features

NHTSA Front Crash Test:

5-Star Rating (for 2010 model year)

IIHS Top Safety Pick:

Yes (typically awarded for this generation)

Standard Safety Features:

ABS, Electronic Stability Program (ESP), Traction Control, Roll Stability Control, Tire Pressure Monitoring System (TPMS), daytime running lights.

Optional Safety Features:

Distronic PLUS adaptive cruise control, Parktronic parking assist, rearview camera, blind-spot monitoring.

Airbags:

Front dual-stage airbags, front side-impact airbags, side curtain airbags (front and rear), driver knee airbag.

💡 Technology Features

Infotainment System Name:

COMAND APS (Cockpit Management and Navigation)

Infotainment Features:

Navigation system, CD/DVD changer, AM/FM radio, Bluetooth connectivity, auxiliary audio input, optional Harman Kardon surround sound system.

Driver Assistance Features:

Optional Distronic PLUS (adaptive cruise control), Parktronic (parking sensors), rearview camera, optional Lane Keeping Assist, optional Blind Spot Assist.

Connectivity Options:

Bluetooth for hands-free calling and audio streaming, optional SiriusXM satellite radio.

🔧 Maintenance

Oil Change Interval Gasoline:

Every 10,000 miles or 1 year, whichever comes first (using synthetic oil). Check manual for specific model/engine variation.

Transmission Fluid Change:

Typically recommended around 60,000-80,000 miles or as per service indicator. Specific fluid and filter replacement is critical for 7G-TRONIC longevity.

Brake Fluid Change:

Every 2 years, regardless of mileage.

Engine Oil Specification:

MB 229.5 or MB 229.51 approved synthetic oil (e.g., SAE 0W-40, 5W-40, 0W-30, 5W-30 depending on climate and specific engine).

Engine Oil Capacity Ml350:

Approx. 8.5 quarts (8.0 liters)

Transmission Fluid Type:

MB 236.14 approved ATF (e.g., Pentosin ATF1)

Coolant Specification:

MB 325.0 or MB 326.0 approved coolant (e.g., ZEREX G-05)

Common Maintenance Items:

Spark plugs (M272 engine), ignition coils, serpentine belt and tensioner, balance shaft gear on M272 engines (pre-2008, though less common in 2010 models but worth checking), PCV valve, oil cooler seals, transmission conductor plate, electronic parking brake actuator.

Suspension Issues:

AIRMATIC suspension components (air springs, compressor, valve blocks) can be prone to leaks over time. Suspension bushings and ball joints.

📚 Vehicle History

Mercedes Benz Legacy:

Over a century of automotive innovation, luxury, and engineering excellence.

Ml Class Lineage:

First introduced in 1997 as the M-Class (W163), the ML Class established Mercedes-Benz's presence in the luxury SUV market. The W164 generation, launched for the 2006 model year, brought significant improvements in styling, interior refinement, and technology.

W164 Production Years:

2005-2011

Manufacturing Location:

Tuscaloosa, Alabama, USA

🏆 Awards & Recognition

Safety Awards:

Consistently recognized for safety with top crash test ratings from NHTSA and IIHS.

Design Awards:

Praised for its upscale design and luxurious interior appointments.

Reliability Ratings:

Generally good reliability, though specific model years and common issues are important to address via maintenance and repair as outlined in the manual.
