Mercedes Benz SL Class R129 1989-2001 Full Service & Repair Manual

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Mercedes-Benz Model: SL-Class Chassis Code: R129 Model Years Covered: 1989-2001 👋 Introduction Market Position Market Segment: Luxury Grand Tourer Convertible Target Audience: Owners and independent...

19 people are viewing this right now

类型: Car

斯库: 183131

标签: 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 Car Cars Featured Mercedes Mercedes-benz SL Class SL Class R129

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Mercedes-Benz

Model:

SL-Class

Chassis Code:

Model Years Covered:

1989-2001

👋 Introduction

Market Position

Market Segment:

Luxury Grand Tourer Convertible

Target Audience:

Owners and independent workshops specializing in Mercedes-Benz vehicles.

Competitive Analysis

Competitors General:

BMW 8 Series, Porsche 911, Jaguar XJS.

Key Features

Manual Value Proposition:

Comprehensive, factory-level information for DIY repairs and professional maintenance, saving significant costs.

Vehicle Appeal:

Iconic design, advanced engineering, luxurious interior, and powerful engine options synonymous with Mercedes-Benz.

📋 Manual Details

Coverage Areas

Primary Coverage:

Full Service & Repair

Secondary Coverage:

Troubleshooting, Servicing

Page Count

Estimated Pages:

Hundreds (specific number not provided, but indicated as extensive)

Manual Type

Type:

Factory Service Repair Workshop Manual

Language

Language:

English (implied by product description and common industry practice)

Format

Digital Format:

PDF Download

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Detailed overhaul, repair, and troubleshooting for all R129 engine variants.

Engine Management:

Ignition system, fuel injection (KE-Jetronic, LH-Jetronic, ME-Motronic depending on year/engine), emissions control, diagnostics.

Transmission:

Automatic transmission service, repair, and diagnostics (e.g., 4-speed 722.3/722.4, 5-speed 722.5/722.6).

Drivetrain:

Driveshaft, differential, rear axle components, and related systems.

Suspension:

Front and rear suspension systems, shock absorbers, springs, control arms, bushings, and power steering.

Brakes:

Hydraulic system, ABS (Anti-lock Braking System), brake calipers, rotors, pads, lines, and parking brake.

Steering:

Power steering system, steering gearbox, linkages, and column.

Electrical System:

Complete wiring diagrams, battery, charging system (alternator, starter), lighting, fuses, relays, and grounding.

Body Exterior:

Panel removal/installation, bodywork repair, convertible top mechanism and hydraulics, doors, hood, trunk, bumpers.

Body Interior:

Dashboard, seats, upholstery, trim panels, climate control system components, and interior electronics.

HVAC:

Air conditioning system, heating system, climate control unit, blower motor, evaporator, condenser, refrigerant.

Convertible Top System:

Hydraulic operation, motors, cylinders, seals, and control modules for the retractable hardtop.

Safety Systems:

Airbag system, seatbelt pre-tensioners, and related sensors and control units.

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection/replacement.

Diagnostic Procedures:

Troubleshooting guides, symptom-based diagnostics, fault code interpretation (where applicable).

Engine Repair:

Top-end rebuilds, bottom-end rebuilds, head gasket replacement, piston and ring replacement, valve adjustments.

Transmission Repair:

Torque converter replacement, clutch pack service, valve body repair, transmission fluid and filter changes.

Brake Repair:

Brake fluid flush and bleed, caliper rebuild, rotor and pad replacement, ABS component testing.

Suspension And Steering Repair:

Component replacement (ball joints, tie rods, control arms), alignment procedures, power steering pump and rack service.

Electrical Repair:

Component testing and replacement (alternator, starter, sensors), wiring harness repair, module diagnostics.

Bodywork And Trim Repair:

Dent removal, panel replacement, convertible top hydraulic system repair, interior trim panel installation.

HVAC Repair:

Refrigerant system service, blower motor replacement, climate control unit repair.

Technical Depth

Depth:

Comprehensive, covering everything from basic maintenance to complete engine and transmission overhauls, and advanced diagnostics.

Detail Level:

Step-by-step instructions, detailed photos, and exploded diagrams.

📊 Manual Specifications

File Format

Format:

Searchability:

Searchable text within the PDF (implied by professional manual standards).

Print Quality

Printability:

Printable (single page or entire manual).

Binding Type

Binding Type:

Digital Download (No physical binding)

Paper Type

Paper Type:

N/A (Digital Format)

Licensing

Licensing:

Lifetime Use, No Expiry, No Renewal Fees

Compatibility

Operating Systems:

Windows & MAC Compatible

Multi Device Use

Device Compatibility:

Usable on multiple computers/devices

⚙️ Engine Specifications

Primary Engine

Engine Variants Covered:

300 SL-24 (M104.980), 500 SL (M119.960), 600 SL (M120.980), SL320 (M104.992), SL500 (M119.982/M113.960), SL600 (M120.982/M275.950 - later models overlap).

Performance

Typical Horsepower Range:

228 hp (SL300) to 389 hp (SL600 V12).

Typical Torque Range:

201 lb-ft (SL300) to 410 lb-ft (SL600 V12).

Fuel System

Fuel Delivery:

Bosch KE-Jetronic (mechanical-electronic injection) and LH-Jetronic/ME-Motronic (electronic fuel injection) depending on model year and engine.

Fuel Type:

Premium Unleaded Gasoline (91+ Octane)

🔧 Transmission

Standard Transmission

Transmission Type:

4-speed and 5-speed automatic transmissions

Transmission Codes:

722.3, 722.4, 722.5, 722.6 (various versions)

Optional Transmission

Optional Transmission Type:

Manual transmission was very rare, primarily for specific performance variants or export markets, and not typical for the R129 in major markets.

Features

Transmission Features:

Electronic control (later models), hydraulic lock-up torque converter, sport/comfort modes on some variants.

📐 Dimensions

Exterior

Length:

Approximately 4500-4510 mm (177.2-177.6 in) depending on year and specific model.

Width:

Approximately 1810-1812 mm (71.3-71.3 in).

Height:

Approximately 1300-1318 mm (51.2-51.9 in).

Weights

Curb Weight:

Approximately 1750-2000 kg (3858-4409 lbs) depending on engine and equipment.

🛡️ Safety Features

Ratings

Safety Ratings General:

While specific crash test ratings from common agencies like NHTSA/IIHS for this era may vary, the R129 was engineered with advanced safety features for its time, including integrated roll-over protection.

Active Features

Active Safety Features:

Anti-lock Braking System (ABS), Acceleration Skid Control (ASR - optional or standard on later models).

Passive Features

Passive Safety Features:

Dual front airbags, reinforced A-pillars, side-impact protection, seatbelt pre-tensioners, pop-up roll-bar system.

💡 Technology Features

Infotainment

Infotainment Systems:

Early models featured basic analog radios with optional CD players. Later models saw upgrades to more integrated stereo systems, often with cassette or CD changers and improved speaker quality.

Driver Assistance

Driver Assistance Features:

Key features included cruise control, ABS, and ASR. Some later models might have incorporated early forms of electronic stability control depending on market and options.

Connectivity

Connectivity Features:

Limited by modern standards, primarily focused on audio system integration. No integrated Bluetooth or smartphone connectivity in the original design, but aftermarket solutions are common.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 7,500-10,000 miles (12,000-16,000 km) or annually, depending on driving conditions and oil type used. The manual will specify exact intervals based on model year and engine.

Major Service Interval:

Major services often recommended around 30,000 miles (48,000 km), including spark plugs, transmission service, brake fluid flush.

Fluid Specifications

Engine Oil:

API SJ or higher, SAE 0W-40 or 5W-40 synthetic recommended. (Specific MB 229.3 or 229.5 spec might apply to later models, check manual).

Transmission Fluid:

Specific ATF (Automatic Transmission Fluid) is critical. For 722.3/722.4, likely Dexron II/III. For 722.5/722.6, MB 236.10 or 236.14 (or equivalent) is essential. Manual will specify.

Coolant:

Mercedes-Benz Approved Antifreeze/Coolant (e.g., G05 or similar silicate-free formulation), mixed 50/50 with distilled water.

Brake Fluid:

DOT 4 Plus (or DOT 4) low-viscosity brake fluid.

Known Issues

Wiring Harness Degradation:

Cracking and failure of insulation on older wiring harnesses, particularly around the engine bay, due to heat and age. Requires inspection and potential replacement.

Convertible Top Hydraulics:

Leaking hydraulic cylinders, lines, and pump failure can lead to slow or non-functional top operation. Regular fluid checks and seal replacement are key.

Mass Air Flow Sensor Maf:

Failure of the MAF sensor can cause rough idling, poor acceleration, and fuel mixture issues, especially on M104 engines.

Interior Wood Trim:

Cracking or delamination of the burled walnut trim can occur due to age and UV exposure.

Window Regulator Motors:

Failure of power window regulators and motors, especially common in the earlier R129 models.

Distributor Cap And Rotor:

Wear and tear can lead to misfires and ignition problems on engines using distributor-based ignition systems.

📚 Vehicle History

Brand Heritage

Mercedes Benz Heritage:

Founded on innovation, engineering excellence, and luxury, Mercedes-Benz has a long history of producing high-performance and luxurious vehicles.

Model Evolution

R129 Introduction:

The R129 succeeded the iconic R107 SL and was a significant redesign, focusing on aerodynamics, safety, and technology.

R129 Key Updates:

Introduction of the M104 inline-six, M119 V8, and M120 V12 engines. Significant updates to electronics, suspension, and the convertible top system throughout its production run.

Production

Production Period:

1989-2001

Manufacturing Location:

Bremen, Germany

🏆 Awards & Recognition

Recognitions

Awards And Accolades:

The R129 SL-Class was consistently praised for its build quality, sophisticated engineering, and timeless design, often featured in 'best of' lists for luxury convertibles of its era.
