Target Audience:
Professional mechanics, DIY enthusiasts, and general car owners
Advantage:
Cost-effective alternative to expensive printed manuals; provides flexibility to print only necessary pages.
Feature 1:
Extensive coverage of repair and maintenance procedures.
Feature 2:
Detailed part layouts and part numbers.
Feature 3:
Inclusion of electrical system wiring schematics.
Cost Savings:
Enables users to perform repairs themselves, saving on labor costs and identifying necessary work before visiting a shop.
Engine:
Detailed repair and maintenance for the M111 engine family (e.g., M111.970 Supercharged Inline-4)
Transmission:
Service and repair for automatic transmissions (e.g., 722.6 '5G-Tronic')
Brakes:
Diagnostic and repair procedures for ABS and standard braking systems
Suspension:
Service and overhaul of front and rear suspension components, including struts, control arms, and bushings
Steering:
Repair and adjustment of power steering systems and steering components
Electrical System:
Comprehensive wiring schematics and diagnostic procedures for all electrical components and circuits
Climate Control:
Diagnosis and repair of HVAC system, including A/C compressor, blower motor, and climate control modules
Fuel System:
Service for fuel injectors, fuel pump, fuel filter replacement, and fuel pressure diagnostics
Exhaust System:
Repair and replacement of exhaust components, including catalytic converter and mufflers
Body And Frame:
Panel repair, dent removal, and structural component information
Interior Trim:
Removal and installation of interior panels, seats, and dashboard components
Maintenance:
Scheduled maintenance tasks, fluid changes, filter replacements, tune-ups
Repair:
Step-by-step repair instructions for major and minor component failures
Diagnostics:
Troubleshooting guides, symptom-based diagnostics, and fault code interpretation
Overhaul:
Complete engine, transmission, and differential overhaul procedures
Installation:
Instructions for installing new or replacement parts and accessories
Specifications:
Detailed torque specifications, clearances, and alignment data
Wiring Schematics:
Comprehensive and detailed electrical wiring diagrams
Depth Level:
Comprehensive: from basic maintenance to advanced engine and transmission rebuilds
Searchability:
Likely text-searchable within PDF (depending on OCR quality of original scans)
Print Capability:
Printable pages as needed
Binding:
N/A (Digital Format)
Paper Quality:
N/A (Digital Format)
Completeness:
Likely compiled from official manufacturer documentation or high-quality aftermarket sources
Structure:
Organized into over 75 separate PDF sections for modular access
Engine Code:
M111.970 (example for C230 Kompressor)
Engine Type:
Supercharged Inline 4-Cylinder
Displacement:
2.3 Liters (2295 cc)
Horsepower:
Approx. 192 hp @ 5300 rpm (for Kompressor models)
Torque:
Approx. 200 lb-ft @ 2500 rpm (for Kompressor models)
Fuel Delivery:
Electronic Fuel Injection (EFI)
Supercharger:
Roots-type supercharger
Coolant Type:
Mercedes-Benz specification coolant (e.g., MB 325.0 or equivalent)
Oil Type:
API SJ or higher, ACEA A2-96 or A3-02; viscosity typically 0W-30 or 5W-40 (refer to manual for exact specs)
Oil Capacity:
Approx. 5.5 Liters (5.8 US Quarts) with filter change (refer to manual)
Type:
5-speed Automatic (722.6 '5G-Tronic')
Type:
5-speed Manual (less common on C230 Kompressor in some markets)
Automatic Modes:
Comfort (C) and Sport (S) modes
Automatic Transmission Fluid:
MB 236.10 specification fluid (e.g., Shell ATF 134, Mobil ATF 134)
Length:
Approx. 4488 mm (176.7 in)
Width:
Approx. 1715 mm (67.5 in)
Height:
Approx. 1393 mm (54.8 in)
Wheelbase:
Approx. 2715 mm (106.9 in)
Curb Weight:
Approx. 1440 kg (3175 lbs) for Kompressor sedan (varies by body style/options)
Niosh Rating:
Specific NHTSA or IIHS ratings for 1998 models may not be readily available, but Mercedes-Benz typically prioritized safety.
Traction Control:
ASR (Anti-Slip Regulation) often standard or optional
Brake Assist:
BAS (Brake Assist System) may be available
Airbags:
Frontal airbags, side airbags (optional on some models)
Seatbelts:
Pretensioning seatbelts
Audio System:
Original Mercedes-Benz sound systems, potentially with cassette or CD players, and AM/FM radio.
Cruise Control:
Standard cruise control system.
Connectivity Features:
Limited by era; primarily focused on internal vehicle systems, not external connectivity.
Oil Change Interval:
Typically 10,000-15,000 miles or 12-24 months, whichever comes first, depending on driving conditions and oil used (refer to manual for precise intervals).
Transmission Service:
Recommended service interval for automatic transmission fluid and filter change is often around 40,000-60,000 miles.
Spark Plug Replacement:
Refer to manual; typically around 60,000-100,000 miles depending on plug type (e.g., platinum or iridium).
Coolant Capacity:
Approx. 7.5 Liters (7.9 US Quarts) (refer to manual)
Brake Fluid Type:
DOT 3 or DOT 4 (refer to manual for specific MB recommendation)
Issue 1:
Mass Air Flow (MAF) sensor failures
Issue 2:
Coolant leaks from plastic components (e.g., expansion tank, thermostat housing)
Issue 3:
Ignition coil pack failures
Issue 4:
Vacuum hose deterioration and leaks
Issue 5:
Headlight switch failure
Issue 6:
Oil cooler leaks (o-rings)
Heritage:
Mercedes-Benz has a long-standing reputation for engineering excellence, safety, and luxury.
Generation:
The W202 generation (1993-2000) was Mercedes-Benz's entry into the compact executive sedan market, aiming to compete with the BMW 3 Series.
C230 Introduction:
The C230 Kompressor model, introduced in 1995/1996 in most markets, offered a performance-oriented option with its supercharged engine.
Production Period:
1993-2000 for the W202 generation.
