2006 Mercury Milan Service & Repair Manual Software

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Mercury Model: Milan Year: 2006 Codes Platform: Ford CD3 Platform Vin Code: W (8th digit) 👋 Introduction Market Position Positioning: Mid-size sedan, competing with models...

20 people are viewing this right now

类型: Car

斯库: 332071

标签: 2006 Car Cars Featured Mercury Milan

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Mercury

Model:

Milan

Year:

Codes

Platform:

Ford CD3 Platform

Vin Code:

W (8th digit)

👋 Introduction

Market Position

Positioning:

Mid-size sedan, competing with models like the Toyota Camry, Honda Accord, Chevrolet Impala, and Ford Fusion.

Competitive Analysis

Segment Strengths:

Offers a comfortable ride, stylish exterior design, and a range of powertrain options. Known for good value for money.

Key Features

Usb Ports:

Not standard on base models, but available on higher trims or as dealer-installed options.

Manual Benefit:

Provides access to factory-licensed repair data, enabling DIY repairs and saving on labor costs.

Manual Benefit

Convenience:

Online accessibility eliminates the need for bulky physical manuals and allows for instant information retrieval.

Data Source

Licensing:

Officially licensed, derived from OE (Original Equipment) materials.

📋 Manual Details

Coverage Areas

All Systems:

Page Count

Estimated Pages:

Thousands (digital format, comprehensive)

Manual Type

Type:

Service and Repair Manual Software

Language

Language:

English

Format

Format:

Online Software/Web-based Access

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Engine assembly, cylinder head, block, pistons, connecting rods, crankshaft, camshafts, timing systems, lubrication system, cooling system.

Engine Electrical:

Ignition system, fuel injection, emissions control, starter motor, alternator, battery, wiring diagrams, sensor testing.

Transmission:

Automatic Transmission (AX4N/AX4S), manual transmission (if applicable), clutch, torque converter, transmission control module (TCM).

Drivetrain:

Front-wheel drive (FWD) system, axles, CV joints, differentials.

Suspension:

Front suspension (struts, control arms, ball joints, sway bar), rear suspension (multi-link, shock absorbers, springs), alignment procedures.

Steering:

Power steering system (pump, rack and pinion, hoses), steering column, steering wheel, alignment.

Brakes:

Front and rear disc brakes, ABS system, parking brake, hydraulic system, bleeding procedures.

Body And Chassis:

Frame, body panels, doors, hood, trunk, bumpers, glass, interior trim.

HVAC:

Heating, ventilation, and air conditioning system components (compressor, condenser, evaporator, blower motor, climate controls).

Electrical System:

Lighting system (headlights, taillights, interior lights), power accessories (windows, locks, mirrors), fuse box, relays, body control module (BCM).

Diagnostics:

OBD-II diagnostic trouble codes (DTCs), diagnostic procedures, scan tool usage, component testing.

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, tire rotations, battery inspection.

Engine Repair:

Engine tune-ups, head gasket replacement, timing belt/chain service, piston and ring replacement, bearing replacement.

Transmission Service:

Fluid and filter changes, transmission rebuilds, torque converter replacement, solenoid replacement.

Brake Service:

Brake pad and rotor replacement, caliper service, brake line replacement, ABS bleeding.

Suspension Repair:

Strut and shock absorber replacement, control arm bushing replacement, ball joint replacement, tie rod end replacement.

Steering Repair:

Power steering pump replacement, rack and pinion replacement, steering linkage service.

Electrical Troubleshooting:

Wiring diagnosis, component testing, circuit repair, sensor replacement.

HVAC Repair:

Refrigerant charging, component replacement (compressor, condenser, evaporator), leak detection.

Body Repair:

Panel replacement, dent repair, glass replacement, trim installation.

Technical Depth

Depth:

Comprehensive, from basic maintenance to complete engine and transmission overhauls, including electrical diagnostics and component-level repair.

📊 Manual Specifications

File Format

File Format:

Web-based Access (Requires Internet Connection)

Print Quality

Print Quality:

N/A (Digital, but content is derived from OE factory materials)

Binding Type

Binding Type:

N/A (Digital)

Paper Type

Paper Type:

N/A (Digital)

Access Duration

Access Duration:

1 Year (with discounts for extensions)

Compatibility

Device Compatibility:

PC, Laptop, Smartphone, Tablet (via web browser)

⚙️ Engine Specifications

Primary Engine

Engine Name 1:

2.3L Duratec DOHC I4

Displacement 1:

2296 cc (139.9 cu in)

Horsepower 1:

156 hp @ 5750 rpm

Torque 1:

156 lb-ft @ 4500 rpm

Optional Engine

Engine Name 2:

3.0L Vulcan SOHC V6

Displacement 2:

2986 cc (182.3 cu in)

Horsepower 2:

194 hp @ 5750 rpm

Torque 2:

200 lb-ft @ 4250 rpm

Performance

Compression Ratio 2.3L:

9.7:1

Compression Ratio 3.0L:

9.3:1

Fuel System

Fuel Delivery 2.3L:

Electronic Fuel Injection (EFI) - Sequential Multi-Port Fuel Injection (MPI)

Fuel Delivery 3.0L:

Electronic Fuel Injection (EFI) - Sequential Multi-Port Fuel Injection (MPI)

Fuel Type

Required Fuel:

Unleaded gasoline (87 octane recommended)

🔧 Transmission

Standard

Transmission Type 2.3L:

5-speed Manual Transmission (M5HA)

Transmission Type 3.0L:

6-speed Automatic Transmission (AX4N - FWD)

Optional

Transmission Type Optional 2.3L:

4-speed Automatic Transmission (4F50N - FWD)

Features

Transmission Fluid Spec Ax4N:

Mercon V Automatic Transmission Fluid (ATF)

Transmission Fluid Spec 4F50N:

Mercon V Automatic Transmission Fluid (ATF)

📐 Dimensions

Exterior

Length:

191.7 in (4870 mm)

Width:

70.9 in (1801 mm)

Height:

57.0 in (1448 mm)

Wheelbase:

107.4 in (2728 mm)

Interior

Front Headroom:

38.7 in (983 mm)

Front Legroom:

42.0 in (1067 mm)

Rear Headroom:

37.6 in (955 mm)

Rear Legroom:

37.4 in (950 mm)

Cargo

Trunk Volume:

14.0 cu ft (396 L)

Weights

Curb Weight 2.3L Auto:

3307 lbs (1500 kg)

Curb Weight 3.0L Auto:

3395 lbs (1539 kg)

🛡️ Safety Features

Ratings

NHTSA Front Driver Side Impact 2006:

★★★★★

NHTSA Front Passenger Side Impact 2006:

★★★★★

NHTSA Side Driver Door 2006:

NHTSA Side Rear Passenger 2006:

IIHS Moderate Overlap Front 2006:

IIHS Side Impact 2006:

Active Features

Standard (4-wheel disc with ABS)

Traction Control:

Optional (Traction Control System - TCS)

Passive Features

Airbags Front:

Driver and front passenger airbags

Airbags Side:

Available front side-impact airbags

Seatbelts:

3-point front and rear seat belts, pretensioners.

💡 Technology Features

Infotainment

Audio System:

Standard AM/FM stereo with CD player; optional premium audio systems, Sirius satellite radio.

Driver Assistance

Cruise Control:

Standard

Parking Sensors:

Optional rear parking assist sensors.

Connectivity

Bluetooth:

Available as an option on higher trims with Ford's SYNC system (introduced later in the generation).

🔧 Maintenance

Service Intervals

Oil Change Interval Synthetic:

7,500 miles or 6 months (whichever comes first)

Oil Change Interval Conventional:

5,000 miles or 6 months (whichever comes first)

Air Filter Replacement:

15,000 - 30,000 miles (inspect every 15,000)

Cabin Air Filter Replacement:

15,000 - 30,000 miles (inspect every 15,000)

Coolant Flush Interval:

100,000 miles or 5 years

Transmission Fluid Change Interval:

100,000 miles (under normal driving conditions)

Fluid Specifications

Engine Oil Spec 2.3L:

SAE 5W-20 (API Certified)

Engine Oil Spec 3.0L:

SAE 5W-20 (API Certified)

Coolant Type:

Ford Gold Premium Engine Coolant (VC-6A) or equivalent (50/50 mix with distilled water)

Brake Fluid Type:

DOT 3

Known Issues

Idle Air Control Valve:

Can become dirty and cause rough idle or stalling, especially on the 2.3L engine.

Power Steering Pump Leaks:

Potential for leaks in the power steering system, particularly at hose connections.

Door Latch Actuator Failure:

Door locks may not function correctly due to failed actuators.

Transmission Hard Shifting:

Some reports of the automatic transmission exhibiting hard shifts or delayed engagement.

📚 Vehicle History

Brand Heritage

Mercury Legacy:

Mercury was an automotive brand established by Ford in 1939, intended to bridge the gap between Ford and Lincoln.

Model Evolution

Milan Introduction:

The Mercury Milan was introduced for the 2006 model year as a successor to the Mercury Mystique and was part of Ford's revitalization of the Mercury brand.

Platform Sharing:

Based on the global Ford CD3 platform, shared with the Mazda 6 and Ford Fusion.

Production

Manufacturing Location:

Flat Rock, Michigan, USA (Ford's AutoAlliance International plant)

Production Years

Production Span:

2006-2010

🏆 Awards & Recognition

Recognitions

IIHS Top Safety Pick:

The 2006 Milan received good ratings from IIHS, contributing to its appeal as a safe vehicle.
